PCI Interrupt Request Routing

The IRQ, abbreviation of interrupt request line and pronounced I-R-Q,
are hardware lines over which devices can send interrupt signals to the
microprocessor. The "AGP/PCI/Promise" IRQ pins are typically connected to
the PCI bus INT A# ~ INT D# pins as follows:
PCI Slot 1
PCI Slot 2
PCI Slot 3
PCI Slot 4
PCI Slot 5
AGP
Promise ATA 133
The mainboard supports PCI Slot 1~5 Bus Master.
Order 1 Order 2
INT A# INT B#
INT B# INT C#
INT C# INT D#
INT D# INT A#
INT B# INT C#
INT A# INT B#
INT D#
2-29
Hardware Setup
Order 3 Order 4
INT C# INT D#
INT D# INT A#
INT A# INT B#
INT B# INT C#
INT D# INT A#
