Premio Computer Athena system System Manual page 113

2-Channel Analog Audio Output
1 Line Out (Front channels)
2 Line In
3 MIC
4-Channel Analog Audio Output
1 Line Out (Front channels)
2 Line In
3 MIC
4 Optical SPDIF jack
5 Coaxial SPDIF jack
6 Line Out (Center and Subwoofer channel)
7 Line Out (Rear channels)
Back Panel
1
2
Using 4- or 6-Channel Audio Function
1
Description:
Connect two speakers to back panel’s Line Out
connector and two speakers to one Line Out
connector of S-Bracket.
3
4
5
A-5
Back Panel
2
S-Bracket
6
3
7
