Vicon VM-642LCD-2 Installation & Operation Manual

Flat panel lcd monitor

Advertisement

Quick Links

XX204-30-00
VM-642LCD-2
Flat Panel LCD Monitor
Vicon Industries Inc. does not warrant that the functions contained in this equipment will meet your
requirements or that the operation will be entirely error free or perform precisely as described in the
documentation. This system has not been designed to be used in life-critical situations and must not
be used for this purpose.
Copyright © 2009 Vicon Industries Inc. All rights reserved.
Product specifications subject to change without notice.
VICON INDUSTRIES INC., 89 ARKAY DRIVE, HAUPPAUGE, NEW YORK 11788
TEL: 631-952-CCTV (2288) FAX: 631-951-CCTV (2288) TOLL FREE: 800-645-9116
24-Hour Technical Support: 800-34-VICON (800-348-4266)
UK: 44/(0) 1489-566300 WEB: www.vicon-cctv.com
Vicon Part No. 8009-8204-30-00
Rev 1209

Advertisement

Table of Contents
loading

Summary of Contents for Vicon VM-642LCD-2

  • Page 1 VM-642LCD-2 Flat Panel LCD Monitor Vicon Industries Inc. does not warrant that the functions contained in this equipment will meet your requirements or that the operation will be entirely error free or perform precisely as described in the documentation. This system has not been designed to be used in life-critical situations and must not be used for this purpose.
  • Page 3 SAFETY INSTRUCTION ………………………………………………………………….. 2 ~ 3 CAUTIONS ………………………………………………………………......FCC RF INTERFERENCE STATEMENT ……………………………......CONNECTING WITH EXTERNAL EQUIPMENT ………………………………………. REMOTE FUNCTIONS ……………………………………………………………………. CONTROLS AND FUNCTIONS ………………………………………………………….. 8 ~ 31 MOUNTING GUIDE ……………………………………………………………………….. D-SUB CONNECTOR PIN ASSIGNMENTS ……………………………………………. POWER MANAGEMENT …………………………………………………………………. SPECIFICATIONS …………………………………………………………………………. TROUBLE SHOOTING GUIDE …………………………………………………………...
  • Page 4: Important Safeguards - Indoor Use

    The product shows a significant change in performance. 2. Retain Instructions - Retain all safety and operating 18. Replacement Parts - Use only Vicon specified replacement instructions for future reference. parts or an approved equivalent to prevent unit damage and 3.
  • Page 5 Important Safeguards – Indoor Use (Cont) 22. For Rack-Mounted Units Only – The following precautions apply to all rack-mounted units. Elevated Operating Ambient - If installed in a closed or multi- unit rack assembly, the operating ambient temperature of the rack environment may be greater than room ambient.
  • Page 6 CAUTION The power supply cord is used as the main disconnect device, ensure that the socket-outlet is located/installed near the equipment and is easily accessible. ATTENTIONN Le cordon d`alimentation est utillsé comme interrupteur général. La prise de courant doit être située ou installée à...
  • Page 7: Fcc Notice

    FCC Notice Note: Complies with Federal Communications Commission Rules & Regulations Part 15, Subpart B for a Class A digital device. WARNING This equipment generates and uses radio frequency energy and if not installed and used properly, that is, in strict accordance with the manufacturer’s instruction, may cause interference to radio and television reception.
  • Page 8: Back Panel Control

    A. BACK PANEL CONTROL 1. HDMI IN 2. DVI IN 3. PC VGA IN 4. PC STEREO IN 5. AUDIO OUT 6. COMPONENT IN 7. COMPONENT AUDIO L/R IN 8. Trigger Input 9. AV 1 IN Composite signal input for AV 1 10.
  • Page 9: Remote Controller (Option)

    B. REMOTE CONTROLLER (Option) 1. POWER( Turn the power ON or OFF. There will be a few seconds delay before the display appears. 2. SOURCE Select pc or video(AV1/AV2/S-Video/Component/HDMI/DVI/PC) sources. 3. AUTO Auto geometry adjustment in PC Source. 4. HOLD Stop the Trigger &...
  • Page 10: Power Led

    C. FRONT KEY CONTROL 1. SOURCE/SELECT Select PC or video. Select On Screen Display menu. 2. MENU Activate and exit the On Screen Display. 3 / 4. These buttons allow user to enter the sub-menu of the activated function. The up( ) button is HOLD function and stop the Trigger & Auto switching functions. 5 / 6.
  • Page 11 OSD MENU DESCRIPTION A: CUSTOM MENU (Only Video Input) 1) Press the MENU button and then press the up( ) or down( ) button to select the Custom. 2) Press the up( ) or down( ) button to select the sub menu. 3) Press right( ) button to adjust the picture setting.
  • Page 12 B. Picture / Sound Menu (Only Video Input) 1. Picture Mode 1) Press the MENU button and then press the up( ) or down( ) button to select the Picture / Sound. 2) Press the right( ) or SOURCE/SELECT button. 3) Press the up( ) or down( ) button to select the Picture Mode.
  • Page 13 3. Mute Press the up( ) or down( ) button to select the Mute. 2) Press the right( ) or SOURCE/SELECT button. 3) Press the up( ) or down( ) button to select the On or Off. 4) Press the MENU button to save. 4.
  • Page 14 5. Size 1) Press the up( ) or down( ) button to select the Size 2) Press the right( or SOURCE/SELECT button. 3) Press the up( ) or down( ) button to select the Size option. 4) Press the MENU button to save. 6.
  • Page 15 7. 3D Comb 1) Press the up( ) or down( ) button to select the 3D Comb. 2) Press the right( or SOURCE/SELECT button. 3) Press the up( ) or down( ) button to select the On or Off. 4) Press the MENU button to save. B.
  • Page 16 2-1. Color Tone 1) Press the up( ) or down( ) button to select the Color Tone. 2) Press the right( or SOURCE/SELECT button. 3) Press the left( or SOURCE/SELECT button again. 4) Press the up( ) or down( ) button to select the Color Tone option. 5) Press the MENU button to save.
  • Page 17 2-2. Color Tone (Custom) 1) Press the up( ) or down( ) button to select the Custom in the Color Tone. 2) Press the 3) Press the up( ) or down( ) button to select the Red(R), Green(G) or Blue(B). 4) Press the right( 5) Press the MENU button to save.
  • Page 18 3. Size 1) Press the up( ) or down( ) button to select the Size. 2) Press the right( or SOURCE/SELECT button. 3) Press the up( ) or down( ) button to select the Size option. Input 4. PC control (Only PC 1) Press the up( ) or down( ) button to select the PC.
  • Page 19 C. PIP MENU (Only Video Input) 1) Press the MENU button and then press the up( ) or down( ) button to select the PIP. 1. PIP 1) Press the right( ) or SOURCE/SELECT button. 2) Press up( ) or down( ) button to select the On or Off. 3) Press the MENU button to save.
  • Page 20 2. Input Source 1) Press the up( ) or down( ) button to select the Input Source. 2) Press the right( ) or SOURCE/SELECT button. 3) Press the up( ) or down( ) button to select the Source option. 4) Press the MENU button to save. 3.
  • Page 21 4. Position 1) Press the up( ) or down( ) button to select the Position. 2) Press the right( ) or SOURCE/SELECT button. 3) Press the up( ) or down( ) button to select the Position option. 4) Press the MENU button to save. 5.
  • Page 22 5. Sound Select 1) Press the up( ) or down( ) button to select the Sound Select. 2) Press the right( ) or SOURCE/SELECT button. 3) Press the up( ) or down( ) button to select the Sound Select option. 4) Press the MENU button to save.
  • Page 23: Setup Menu

    D. SETUP MENU 1) Press the MENU button and then press the up(▲) or down(▼) button to select the Setup. 1. Reset 1) Press the right( ) or SOURCE/SELECT button 2) Press the right( ) or SOURCE/SELECT button again. 3) Press SOURCE/SELECT button to execute the reset. Reset: All settings go to the factory initialization.
  • Page 24 2. Language 1) Press the up(▲) or down(▼) button to select the Language. 2) Press the right( ) or SOURCE/SELECT button. 3) Press the up(▲) or down(▼) button to select language. 4) Press the MENU button to save. 3. OSD Tone 1) Press the up(▲) or down(▼) button to select the OSD Tone.
  • Page 25 4. Blue Screen 1) Press the up(▲) or down(▼) button to select the Blue Screen. 2) Press the right( ) or SOURCE/SELECT button. 3) Press the up(▲) or down(▼) button to select the On or Off. 4) Press the MENU button to save. 5.
  • Page 26 6. Trigger 1) Press the up(▲) or down(▼) button to select the Trigger. 2) Press the right( ) or SOURCE/SELECT button. 6-1. Trigger Enable 1) Press the up(▲) or down(▼) button to select the Trigger Enable. 2) Press the right( ) or SOURCE/SELECT button. 3) Press the up(▲) or down(▼) button to select the On or Off.
  • Page 27 6-2. Trigger Input 1) Press the up(▲) or down(▼) button to select the Trigger Input . 2) Press the right( ) or SOURCE/SELECT button. 3) Press the up(▲) or down(▼) button to select the Trigger Input option. 4) Press the Menu button to save. 6-3.
  • Page 28 6-4. Trigger Time 1) Press the up(▲) or down(▼) button to select the Trigger Time. 2) Press left( ) or right( ) button to adjust Trigger Time setting. 3) Press the MENU button to save. 6-5 Trigger Option 1) Press the up(▲) or down(▼) button to select the Trigger Option. 2) Press the right( ) or SOURCE/SELECT button.
  • Page 29 6-6. Display Type 1) Press the up(▲) or down(▼) button to select the Display Type. 2) Press the right( ) or SOURCE/SELECT button. 3) Press the up(▲) or down(▼) button to select the Display Type option. 4) Press the Menu button to save. PIP &...
  • Page 30 7. Auto switching 1) Press the up(▲) or down(▼) button to select the Auto switching. 2) Press the right( ) or SOURCE/SELECT button. 7-1. Auto switching On/Off 1) Press the right( ) or SOURCE/SELECT button. 2) Press the up(▲) or down(▼) button to select the On or Off . 3) Press the Menu button to save.
  • Page 31 7-2. Auto switching Inputs enabled 1) Press the up(▲)or down(▼) button to select the Inputs enabled. 2) Press the right( ) or SOURCE/SELECT button. 3) Press the up(▲) or down(▼) button to select the Input. 4) Press the right( ) or SOURCE/SELECT button. 1) Press the up(▲) or down(▼) button to select the On or Off.
  • Page 32 7-3. Auto switching Time 1) Press the up(▲) or down(▼) button to select the Time. 2) Press the left( ) or right( ) button to adjust the Time setting. 3) Press the MENU button to save. 8. Image Rotation 1) Press the up( ) / down( ) button to select the Image Rotation. 2) Press the right( ) or ENTER button.
  • Page 33 8-1. Image Rotation On/Off 1) Press the right( ) or SOURCE/SELECT button. 2) Press the up(▲) or down(▼) button to select the On or Off . 3) Press the Menu button to save. 8-2. Image Rotation Min(Time control) 1) Press the up(▲) or down(▼) button to select the Time. 2) Press the left( ) or right( ) button to adjust the Time setting.
  • Page 34 Using the wall mount design and the (130x130)x634 hole pattern on the back panel to install the LCD monitor to the wall. Wall-mount Installation (Option) 1. The Monitor fixing bracket to the monitor using the fixing screws provided. 2. The monitor fixing bracket assembled with monitor 32 …………………………………………………………………….
  • Page 35 PIN ASSIGNMENTS Pin 1 RED VIDEO GREEN VIDEO SIGNAL CABLE DETECT BLUE VIDEO GROUND GROUND SDA(for DDC) GROUND H-SYNC.(or H+V SYNC.) RED GROUND V-SYNC. GREEN GROUND SCL(for DDC) BLUE GROUND ACCESSORIES 1. Power cord 2. User’s manual 3. PC cable 4.
  • Page 36: Led Indicator

    This monitor features a power management system to “power down” upon receipt of the VESA DPMS(The display power management signaling) from a VESA DPMS video card. The VESA DPMS-compliant video card performs this signaling system through not sending horizontal, vertical, or sync signal. This monitor enters an appropriate mode through identifying each of the three modes of the signaling system.
  • Page 37: Electrical Ratings

    42’’ WUXGA 42˝ Diagonal AM-TFT(Active-Matrix) Pixel pitch(mm) : 0.4845mm(H) x 0.4845mm(V) BRIGHTNESS: 500cd/㎡(Typical) LCD-Type CONTRAST RATIO: 1300:1(Typical) VIEWING ANGLE: 178°/178°(H/V) RESPONSE TIME: 5msec(G-to-G) RESOLUTION (H x V) 1920X1080 @60Hz FREQUENCY HORIZONTAL: 31~80KHz, VERTICAL: 56~75Hz VIDEO(2ch input 1.0Vp-p, 75Ω terminated, loop-through out) S-VIDEO(1ch input (Y/C), loop-through out) COMPONENT(Y,Pb,Pr, Sound L/R) DVI D(Digital Video Interface)
  • Page 38: Weee Symbols

    WEEE Symbols Correct Disposal of This Product (Waste Electrical & Electronic Equipment) (Applicable in the European Union and other European countries with separate collection systems) This marking shown on the product or its literature, indicates that it should not be disposed with other household wastes at the end of its working life.
  • Page 39 Vicon Security Management Systems (SMS) All Models: All hardware is warranted for two years from date of original retail purchase. Any product sold as “special” or not listed in Vicon’s commercial price list: One year from date of original retail purchase.
  • Page 40 Vicon Industries Inc. Corporate Headquarters 89 Arkay Drive Hauppauge, New York 11788 631-952-CCTV (2288) 800-645-9116 Fax: 631-951-CCTV (2288) Vicon Europe Headquarters Brunel Way Fareham, PO15 5TX United Kingdom +44 (0) 1489 566300 Fax: +44 (0) 1489 566322 Vicon Germany Kornstieg 3...
