WARNING: TO REDUCE THE RISK OF FIRE OR ELECTRIC SHOCK, DO NOT EXPOSE THIS PRODUCT TO RAIN OR MOISTURE. DO NOT INSERT ANY METALLIC OBJECT THROUGH VENTILATION GRILLS. CAUTION: CAUTION CAUTION RISK OF ELECTRIC SHOCK DO NOT OPEN CAUTION: TO REDUCE THE RISK OF ELECTRIC SHOCK. DO NOT REMOVE COVER(OR BACK).
FCC COMPLIANCE STATEMENT FCC INFORMATION : THIS EQUIPMENT HAS BEEN TESTED AND FOUND TO COMPLY WITH THE LIMITS FOR A CLASS A DIGITAL DEVICE, PURSUANT TO PART 15 OF THE FCC RULES. THESE LIMITS ARE DESIGNED TO PROVIDE REASONABLE PROTECTION AGAINST HARMFUL INTERFERENCE WHEN THE EQUIPMENT IS OPERATED IN A COMMERCIAL ENVIRONMENT.
IMPORTANT SAFEGUARDS READ INSTRUCTIONS -- All the safety and operating POWER CORDS -- Do not allow anything to rest on the instructions should be read before the appliance is operated. power cord. Do not locate video monitor or equipment where the cord will be abused by persons walking on it.
MONITOR SETTINGS / CONTROLS 1. GENERAL This section defines the procedures for making adjustments to the monitor. This section is provided to assist the installer and operator in maintaining an optimum picture on the monitor. In order to prevent overheating, ensure that the ventilation openings in the monitor are not covered.
A. OSD MENU IN/OUT CONTROL This control is used to enter and exit the OSD CONTROL MENU. The user controlled OSD DATA is saved when the user exits the OSD MENU or there is no user control for 40 seconds. OSD MENU OPTIONS : Volume : This control is used to control the sound volume for the...
Page 7
D. ADJUSTMENT DOWN CONTROL This control is used to decrease the selected MENU adjustment. E. ADJUSTMENT UP CONTROL This control is used to increase the selected MENU adjustment. F. VIDEO INPUT SELECTION CONTROL This control selects the video and audio input signals. To change the input signal, press this button.
3. MONITOR CONNECTIONS The following connections are located on the monitor (see Figure3. for connection locations) : VIDEO LINE AUDIO LINE VIDEO A VIDEO B POWER Y/C VIDEO FIGURE 3. MONITOR CONNECTION LOCATIONS A. AC IN The supplied power cord should be plugged into this port. 120 Volt alternating current (ac) 60Hz grounding outlet or 230 Volt ac 50Hz can be used.
S-VHS PIN DESCRIPTION (Separated Y/C signal IN/OUT) PIN No. DESCRIPTION Y Signal IN or OUT C Signal IN or OUT Note : The impedance is automatically set to 75 ohm by the input of a signal on the input connector while operating in a single connection mode. However, if a cable is connected to the output connector, the connection is placed into the open status by the multiple connection and high impedance automatically selected.
CONNECTION SINGLE CONNECTION Video camera from Video output MULTIPLE CONNECTION Video camera from Video output Up to 3 monitors can be connected using the loop-through feature of this unit. When this monitor is connected to additional monitors, the same picture can be obtained on all the connected monitors.
