XX171-00-00
VM617 AND VM619 FLAT PANEL
LCD MONITORS
Copyright © 2005 Vicon Industries Inc. All rights reserved.
Product specifications subject to change without notice.
Vicon and its logo are registered trademarks of Vicon Industries Inc.
VICON INDUSTRIES INC., 89 ARKAY DRIVE, HAUPPAUGE, NEW YORK 11788
TEL: 631-952-CCTV (2288) FAX: 631-951-CCTV (2288) TOLL FREE: 800-645-9116
24-Hour Technical Support: 800-34-VICON (800-348-4266)
UK: +44 (0) 1489-566300
WEB: www.vicon-cctv.com
Vicon part number 8009-8171-00-00
Section 6 Rev 1105
Advertisement
Table of Contents
Related Manuals for Vicon VM617
Summary of Contents for Vicon VM617
- Page 1 Copyright © 2005 Vicon Industries Inc. All rights reserved. Product specifications subject to change without notice. Vicon and its logo are registered trademarks of Vicon Industries Inc. VICON INDUSTRIES INC., 89 ARKAY DRIVE, HAUPPAUGE, NEW YORK 11788 TEL: 631-952-CCTV (2288) FAX: 631-951-CCTV (2288) TOLL FREE: 800-645-9116...
- Page 5 TO PREVENT ELECTRIC SHOCK, DO NOT USE THIS POLARIZED PLUG WITH AN EXTENSION CORD RECEPTACLE OR OTHER OUTLET UNLESS THE PRONGS CAN BE FULLY INSERTED INTO THE OUTLET TO PREVENT ANY EXPOSURE OF THE PRONGS ON THE POLARIZED PLUG. Explanation of Graphical Symbols • 1 XX171-00-00 Rev 1105 VM617/VM619 Flat Monitors...
- Page 6 If your hands or clothes have touched it, wipe them with alcohol and a cleaning cloth and then wash them well. 2 • Explanation of Graphical Symbols XX171-00-00 Rev 1105 VM617/VM619 Flat Monitors...
- Page 7 RGB In (15-Pin D-Sub) 2 Video In/Out (BNC) 2 Stereo Audio In/Out S-Video In VESA Standard Wall and Arm Mountable Built-In Stereo Speaker Components LCD Color Monitor Accessories Power Cord User Manual • 3 XX171-00-00 Rev 1105 VM617/VM619 Flat Monitors...
-
Page 8: Front Panel Description
Select input signal from AV1, AV2, S-Video or VGA (PC). POWER: Monitor power ON/OFF. At OFF mode, monitor is at standby status. Green Light: ON Mode Orange Light: Standby Mode (AV1, AV2, S-Video) Red Light: OFF Mode 4 • XX171-00-00 Rev 1105 VM617/VM619 Flat Monitors... - Page 9 Composite signal Input for VIDEO 2 VIDEO 1 OUT Video looping output for VIDEO 1 VIDEO 1 IN Composite signal Input for VIDEO 1 PC AUDIO IN Signal VGA IN 100 VAC ~240 VAC Input • 5 XX171-00-00 Rev 1105 VM617/VM619 Flat Monitors...
- Page 10 BNC cables provide better connection and picture performance. NOTE: Audio Cable To prevent equipment damage, do not plug in any power cords S-Video until you have finished connecting BNC Connector all equipment. 6 • XX171-00-00 Rev 1105 VM617/VM619 Flat Monitors...
-
Page 11: Monitor Setup
Configure Video Signal Brightness, Contrast, Color, Tint, Sharpness, Video System, Scan Mode, Color Temperature, Default and Exit. VGA Setup: Configure VGA Signal Auto, Brightness, Contrast, Color Temperature, White Balance, H-Position, V-Position, Clock, Phase, Default and Exit. EXIT: Exit the on-screen menu. • 7 XX171-00-00 Rev 1105 VM617/VM619 Flat Monitors... - Page 12 VIDEO LOSS SETUP: Controls monitor luminance when video is not detected. V-LOSS SLEEP TIME: Controls video loss count down timer. VOLUME: To adjust the built-in speakers’ output volume EXIT: Exit the on-screen menu. 8 • XX171-00-00 Rev 1105 VM617/VM619 Flat Monitors...
- Page 13 SMALL: Permits the displaying picture to approximately match the actual size of displaying area. COLOR TEMP: Selects color temperature of either 6500°K or 9300°K. DEFAULT: Sets the monitor to the original factory setting. Original factory setting (General Setup, Video Setup). EXIT: Exits the on-screen menu. • 9 XX171-00-00 Rev 1105 VM617/VM619 Flat Monitors...
-
Page 14: Vga Setup
When the phase is not adjusted properly, the picture will be unclear. Therefore this value should be carefully adjusted. DEFAULT: Sets the monitor to the original factory setting. Original factory setting (VGA Setup). EXIT: Exits the on-screen menu. 10 • XX171-00-00 Rev 1105 VM617/VM619 Flat Monitors... -
Page 15: Lcd Monitor Mounting Guide
Mounting the monitor on the rack Rack Mount Note: When adjusting to a rack, an optional rack mount is needed for the back side of the LCD monitor. Optional rack mounts sold separately. • 11 XX171-00-00 Rev 1105 VM617/VM619 Flat Monitors... -
Page 16: Connecting Device
Although this monitor supports above RGB signals, any resolutions not matched by this monitor (SXGA) will be expanded or shrunk, which will affect image quality. To view high-quality images, it is recommended that the PC's resolution should be set to SXGA (1280x1024) resolution. 12 • XX171-00-00 Rev 1105 VM617/VM619 Flat Monitors... -
Page 17: Troubleshooting
● Try pressing Volume Up button in the Menu. Poor color, sound OK ● Check cable connections. ● Adjust Video set up menu. Poor color or no color ● Adjust Color and/or Tint (NTSC only). • 13 XX171-00-00 Rev 1105 VM617/VM619 Flat Monitors... - Page 18 (∗2) It is not guaranteed for all the specified range. (∗3) Use the supplied power supply cord at 120 VAC or less. Design and Specifications are subject to change without notice. 14 • XX171-00-00 Rev 1105 VM617/VM619 Flat Monitors...
-
Page 19: Lcd Color Monitor Dimensions
LCD Color Monitor Dimensions • 15 XX171-00-00 Rev 1105 VM617/VM619 Flat Monitors... - Page 20 Shipping Instructions Use the following procedure when returning a unit to the factory: 1. Call or write Vicon for a Return Authorization (R.A.) at one of the locations listed below. Record the name of the Vicon employee who issued the R.A.
-
Page 21: Vicon Standard Equipment Warranty
Software supplied either separately or in hardware is furnished on an “As Is” basis. Vicon does not warrant that such software shall be error (bug) free. Software support via telephone, if provided at no cost, may be discontinued at any time without notice at Vicon’s sole discretion. -
Page 22: Corporate Headquarters
Vicon Industries Inc. Corporate Headquarters 89 Arkay Drive Hauppauge, New York 11788 631-952-CCTV (2288) 800-645-9116 Fax: 631-951-CCTV (2288) Vicon Europe Headquarters Brunel Way Fareham, PO15 5TX United Kingdom +44 (0) 1489 566300 Fax: +44 (0) 1489 566322 Brussels Office Planet II - Unit E...
