XX111
MODEL VM6093
9-INCH COLOR MONITOR
Copyright © 2002 Vicon Industries Inc. All rights reserved.
Product specifications subject to change without notice.
Vicon and its logo are registered trademarks of Vicon Industries Inc.
VICON INDUSTRIES INC., 89 ARKAY DRIVE, HAUPPAUGE, NEW YORK 11788
TEL: 631-952-CCTV (2288) FAX: 631-951-CCTV (2288) TOLL FREE: 800-645-9116
24-Hour Technical Support: 800-34-VICON (800-348-4266)
UK: 44/(0) 1489-566300 INFOFAX: 800-287-1207 WEB: www.vicon-cctv.com
Vicon part number 8009-8111-00-00
Rev 602 Section 3
LCT1275-001A-H
1
02.08.06, 3:06 PM
Advertisement
Table of Contents
Related Manuals for Vicon VM6093
Summary of Contents for Vicon VM6093
- Page 1 Copyright © 2002 Vicon Industries Inc. All rights reserved. Product specifications subject to change without notice. Vicon and its logo are registered trademarks of Vicon Industries Inc. VICON INDUSTRIES INC., 89 ARKAY DRIVE, HAUPPAUGE, NEW YORK 11788 TEL: 631-952-CCTV (2288) FAX: 631-951-CCTV (2288) TOLL FREE: 800-645-9116 24-Hour Technical Support: 800-34-VICON (800-348-4266) UK: 44/(0) 1489-566300 INFOFAX: 800-287-1207 WEB: www.vicon-cctv.com...
- Page 2 LCT1275-001A-H 02.08.06, 3:06 PM...
- Page 3 We stand behind the quality and dependability of every product with an industry leading Beneficial Use warranty. If you are not satisfied with a Vicon product or service, I would like to know. Your complete satisfaction is the mission of every Vicon employee.
-
Page 4: Safety Precautions
CAUTION: Changes or modification not approved by VICON could void the user's authority to operate the WARNINGS equipment. To prevent fire or shock hazard, do not expose this NOTE: This equipment has been tested and found to monitor to rain or moisture. -
Page 5: Table Of Contents
POWER CONNECTION The power supply voltage rating of this product is AC 120 V (for U.S.A. and Canada only) and AC 230 V (for European countries or United Kingdom), the power cord attached conforms to the following power supply voltage and countries. Use only the power cord designated to ensure Safety and EMC regulations of each countries. -
Page 6: Controls And Features
CONTROLS AND FEATURES FRONT VIEW <Front Panel> POWER CHROMA CONTRAST VOLUME/SELECT MENU INPUT SELECT PHASE BRIGHT POWER CHROMA CONTRAST VOLUME/SELECT MENU PHASE BRIGHT INPUT SELECT Chroma/Phase button Input A (VIDEO) button [INPUT SELECT A] CHROMA/ PHASE] Selects the video and audio signals input to the VIDEO A and AUDIO A terminals on the rear panel. -
Page 7: Rear View
REAR VIEW <Rear Panel> VIDEO A VIDEO A VIDEO B VIDEO B AUDIO A AUDIO B AUDIO A INPUT ASPECT REMOTE AUDIO B INPUT ASPECT REMOTE Video A terminals [VIDEO A IN/OUT] Audio B terminals [AUDIO B IN/OUT] Video signal input (IN) and output (OUT) terminals. Input (IN) and output (OUT) terminals for the audio The output terminal is bridge-connected. - Page 8 CONTROLS AND FEATURES (cont’d) REAR VIEW <Rear Panel> VIDEO A To AC outlet VIDEO B (120 VAC, For U.S.A. and Canada 50 Hz/60 Hz) AUDIO A To AC outlet AUDIO B (230 VAC, 50 Hz/60 Hz) INPUT ASPECT REMOTE For Europe For the United Kingdom AC inlet [AC IN] Power cord...
-
Page 9: How To Handle Basic Operations
HOW TO HANDLE BASIC OPERATIONS BASIC OPERATION STATUS indication (PAL or NTSC) 1. Press the POWER switch to turn on the power. gON : Power turns ON. (Power indicator: lit) POWER GOFF : Power turns OFF. (Power indicator: unlit) 2. Press the INPUT SELECT buttons to choose input. Select video/audio signals input to terminals on the rear panel. -
Page 10: How To Use The Menu Functions
HOW TO USE THE MENU FUNCTIONS DISPLAY AND SELECTION IN THE <MENU> SCREEN MODE (SETTING) <MENU> screen You can set the following menu items. Set them depending on your needs. < MENU > ‰ SHARPNESS • SHARPNESS • ASPECT RATIO : +03 COLOR SYSTEM : AUTO... - Page 11 DISPLAY AND SELECTIONS IN THE <SET-UP MENU> MODE (SETTING) <SET-UP MENU> screen You can set the following set-up menu items. • H. POSITION • CONTROL LOCK • INPUT REMOTE <SET-UP MENU> • WHITE BALANCE • STATUS DISPLAY • ASPECT REMOTE ‰...
- Page 12 HOW TO USE THE MENU FUNCTIONS (cont’d) Set-up menu items Purpose Settings H. POSITION Adjusts the horizontal position of the screen (+ : Horizontal position –05 –04 • • • • • • –01 +01 • • • • • • +04 shifts to the right/–: Horizontal position shifts to the left) WHITE BALANCE...
-
Page 13: How To Initialize The Setting
HOW TO INITIALIZE THE SETTING SCREEN DISPLAY AND SELECTIONS IN THE <SET-UP MENU> RESET MODE You can set <MENU> and <SET-UP MENU> screen items, picture adjustment items and <SET-UP MENU> RESET screen the volume level to their factory-set (initial) values. <SET–UP MENU>... -
Page 14: Basic Connection Example
BASIC CONNECTION EXAMPLE Notes: • Before connecting your system, make sure that all units are turned off. • The illustration below shows some examples of different connections. Terminal connections may differ depending on the components connected. Be sure to refer to the instructions provided with the unit(s) you are connecting. •... -
Page 15: Troubleshooting
TROUBLESHOOTING Solutions to common problems related to your monitor are described here. If none of the solutions presented here solves the problem, unplug the monitor and consult VICON Technical Support for assistance. Problems Points to be checked Measures (Remedy) No power supply. -
Page 16: Specifications
SPECIFICATIONS Audio power output : 1 W (monaural) Type : Color video monitor Built-in speaker : 80 mm round x 1 Color system : NTSC (3.58), PAL impedance of 8 Ω Picture tube : 9-7/8" (250 mm) measured Environmental diagonally, conditions : Operation temperature: 90°... - Page 17 Dimensions Unit : inch (mm) < Side View > < Front View > 12-1/2" (316.3) 12" (304.8) 8-3/4" (222) 1/16" (1.5) 7-1/8" (178) * CHROMA CONTRAST VOLUME/SELECT MENU POWER PHASE BRIGHT INPUT SELECT 6-1/2" (164) 2-1/2" (63.5) 8-3/4" (222) ø7/8" (ø22) * Asterisks ( ) are used to indicate front panel dimensions.
-
Page 18: Shipping Instructions
Shipping Instructions Use the following procedure when returning a unit to the factory: 1. Call or write Vicon for a Return Authorization (R.A.) at one of the locations listed below. Record the name of the Vicon employee who issued the R.A. - Page 19 1000 (300) 1600 (500) Best picture 400 (120) 530 (160) 820 (250) * Longer cable runs may produce a dim, faint picture. Use a Vicon Video Amplifier to obtain a usable picture for long cable runs. LCT1275-001A-H 02.08.06, 3:06 PM...
- Page 20 Copyright © 2000 Vicon Industries Inc. All rights reserved. Product specifications subject to change without notice. Vicon and its logo are registered trademarks of Vicon Industries Inc. Vicon Part No. 8009-1000-00-00 Rev 801 VICON INDUSTRIES INC., 89 ARKAY DRIVE, HAUPPAUGE, NEW YORK 11788...
-
Page 21: Fcc Notice
Copyright © 2000 Vicon Industries Inc. All rights reserved. Product specifications subject to change without notice. Vicon and its logo are registered trademarks of Vicon Industries Inc. Vicon Part No. 8009-1000-00-00 Rev 801 VICON INDUSTRIES INC., 89 ARKAY DRIVE, HAUPPAUGE, NEW YORK 11788... - Page 22 MEMO MEMO LCT1275-001A-H 02.08.06, 3:06 PM...
- Page 23 MEMO MEMO LCT1275-001A-H 02.08.06, 3:06 PM...
- Page 24 Vicon Industries Inc. Corporate Headquarters 89 Arkay Drive Hauppauge, New York 11788 631-952-CCTV (2288) 800-645-9116 Fax: 631-951-CCTV (2288) Infofax: 800-287-1207 Vicon Europe Headquarters Brunel Way Fareham, PO15 5TX United Kingdom +44 (0) 1489 566300 Fax: +44 (0) 1489 566322 Brussels Office...
