    Dear customer! Thank you for purchasing our product. For safety, it is strongly recommended to read this manual carefully before connecting, operating and/or adjusting the product and keep the manual for reference in the future. Table of contents Table of contents ............................2 Important safeguards ............................3 Installation/Connections ..........................4 Panel controls..............................8...

  • Page 3: Important Safeguards

    Important safeguards Using the device at temperature below -10º may cause the breakage of the device. BEFORE USING PLEASE HEAT UP THE PASSENGER COMPARTMENT TO THE RECOMMENDED TEMPERATURE! Read carefully through this manual to familiarize yourself with this high-quality sound system. Disconnect the vehicle's negative battery terminal while mounting and connecting the unit.

  • Page 4: Installation/Connections

    Installation/Connections First complete the electrical connections, and then check them for correctness. If you are not confident working with electrical wiring, removing and reinstalling interior panels, carpeting, dashboards or other components of your vehicle, please call your dealer in order to have the unit professionally installed. Before the installation IMPORTANT: Remove two screws before installation.

  • Page 5: Electrical Connections

    NOTE: Outer trim frame, hook, and mounting sleeve are not used for this installation. This is only intended as a general guide; contact the vehicle's manufacturer for specific instructions. This method of installation uses the screw holes at the sides of the unit and the holes of the existing vehicle mounting bracket.
  • Page 7 Using the ISO Connector 1. If your car is equipped with the ISO connector, then connect the ISO connectors as illustrated. 2. For connections without the ISO connectors, check the wiring in the vehicle carefully before connecting, incorrect connection may cause serious damage to this unit.

  • Page 8: Panel Controls

    Panel controls Front panel 1. VOLUME-UP/DOWN, PUSH SEL MENU 2. LCD (LIQUID CRYSTAL DISPLAY). 3. FM STEREO/MONO 4. EQ/LOUDNESS 5. LOCAL/MENU BUTTON 6. CLOCK BUTTON 7. APS/SUB BUTTON 8. BAND/NP BUTTON. Press it repeatedly to select your desired radio band during RADIO mode. 9.
  • Page 9 10. OPEN BUTTON. Press it to flip down the front panel and you can insert the disc into the compartment or press the EJ button to eject the disc from the disc compartment. 11. PREVIOUS/NEXT BUTTONS 12. IR SENSOR 13. PRESET STATION [1-6] AND RPT, RDM BUTTONS. 1.
  • Page 10 Back of the front panel Press the button to open the panel and press to eject the disc. Disc eject Disc slot: insert a disc for playback here Reset hole Panel status indicator Note: Pressing the RESET hole will erase the clock setting and stored stations. Panel status indicator lights up when you slide the panel down;...
  • Page 11 ISO connector PLEASE USE ONLY ORIGINAL CONNECTOR WHICH GOES WITH SET. Note: In spite of having any kinds of speaker system, must use 4 ohms impedance of speaker to reduce the distortion during high volume level.

  • Page 12: Remote Control

    Remote control 1. MODE button 2. Power on/off 3. UP button 4. BAND/SYS button 5. ENTER button 6. LEFT button 7. STOP button 8. ST/PROGRAM button 9. AMS/RPT button 10. SEEK - / PREVIOUS button 11. LOC/RDM button 12. OSD button 13.

  • Page 13: Battery Information Of Remote Controller

    25. SELECT button (to select basic sound setting options) 26. SEEK + / NEXT button 27. VOLUME + button 28. AUDIO button 29. GOTO button Battery information of remote controller 1. Press the catch and at the same time pull out the battery tray. 2.

  • Page 14: Glossary

    Glossary PBC (PlayBack Control) PlayBack Control is a menu recorded on the disc with SVCD or VCD2.0 format. For the discs contained PBC, it can playback interactive software with the menu displayed on TV. And if the disc contains still images, it can playback high definition of still image.

  • Page 15: Features

    Features Fully compatible Fully compatible with the most popular discs formats such as DVD, CD, CD-R (containing MP3, JPEG), CD-RW represented in the market. Upgrade intelligently Support the function of upgrading the software for playing discs of new formats to keep up with the market competition.

  • Page 16: Compatible Discs

    Compatible discs DVD Video DVD disc include video and audio data. The data can contained by the 12 cm diameter of DVD disc is 7 times of one can contained by the common CD-R disc. Its maximum continuous playback time can be up to 2 hours (one of double-sided disc can be up to 4 hours).
  • Page 17 Picture-CD Compatible with Picture-CD disc. Do not need setting the additional software. Picture-CD is a disc format that stores photo with electronic file format developed by Kodak company. Photo-CD Compatible with Photo-CD disc. Do not need setting the additional soft ware. Photo-CD is a disc format that stores photo with electronic file format developed by Konica company.

  • Page 18: General Operation

    General operation Power button Press POWER button on the front panel or any other button on the panel except EJECT to turn on the unit. Press POWER to switch the set to POWER OFF. When you switch off the system or car ignition, the settings, tuner presets and the volume level will be retained in the unit s memory.

  • Page 19: Adjusting Clock

    Loudness control Press and hold EQ/LUD to select LOUDNESS on or off. LOUD ON or LOUD OFF appears on the display. Press it again to cancel Adjusting clock Setting the clock time 1. Press and hold CLK for more than 3 seconds to select the hour setting. Hour digits will blink. 2.

  • Page 20: Digital Tuner

    Digital tuner Choose Radio Band Press the MODE Button to access the radio function. The unit comes with five bands- three FM Bands (FM1, FM2, and FM3) and two AM Bands (MW1, and MW2). Each of the five bands can store up to six preset stations, for a total of 30 preset memory stations.
  • Page 21 Save Your Preset Stations There are six numbered preset buttons which can store and recall stations for each band. While listening to a radio station you would like to save as a pre-set, press and hold one of the buttons numbered 1-6 until you hear a beep. The button you pressed is now the pre-set button for that station.

  • Page 22: Dvd/Vcd/Cd/Mp3/Cd-R

    DVD/VCD/CD/MP3/CD-R Discs for playback This set can play all digital audio CD, HDCD, CD-R/RW, MP3,WMA, VCD, SVCD, DVD, DVD-ROM. The following file types are supported: Audio files: MP3 (*.mp3) WMA (*.wma) Video files: MP4 (*.avi, DIVX3.11/4.0/5.0/6.XX and XVID) MPEG 2(*.vob) MPEG 1(*.dat) Picture file: JPEG (*.jpg) ISO 9660 or ISO 9660 +Joliet format - Max.
  • Page 23 Note: if your CD disc includes several folders with MP3, JPEG files, then you should operate with this CD only having TV monitor. You can see folders names on the screen of the monitor. OSD (Display information) Press the OSD button (by pressing and holding button 1 on the front panel, or pressing the OSD button on the remote control) so that the OSD will be display on the monitor.
  • Page 24 Button 1: Left + Display OSD The number 1-6 buttons contains dual fuctions during Disc play. After pressing the Setup button (button 6 on the headunit), the setup menu will be prompted. Then the number button is for navigating and confirming the commands.

  • Page 25: Audio Selection

    Button 6: SETUP + Play/Pause Press the No.6 Button to call the setup menu. The menu will show in the display so that functions such as system, language, video, audio and digital can be set. Use the button 1-5 to navigate and confirm the commands. Press again to turn off the setup menu.

  • Page 26: Slow Motion

    Slow Motion Press the SLOW button on the remote control to perform slow montion of the video play. SF 1/2 up to 1/8 will be shown, according to the slowness. Cycle back to normal playback of press the Play/Pause button to resume. Multi-Angle View Press the ANGLE button on the remote control to perform multiangle playback.

  • Page 27: Mixed-Disc Operation

    Mixed-disc operation While you are playing mixed disc, which contains MP3, WMA, JPG or DIVX formats, just insert the disc into the CD slot and the menu on the right hand side will be promted. The unit will directly play the audio files. However, you can use the navigation and Enter keys to select the format that you would like to view/listen to.
  • Page 28 Press the SEEK |<< Button to go to a previous track. Track numbers will be shown on the display. Press and hold the SEEK |<< Button to fast reverse. Disc will play normally when the SEEK >>| or SEEK |<< Button is released. On the Remote Control, use the |<<...

  • Page 29: Vcd/Cd Operation

    VCD/CD operation Insert/Eject CD Insert a disc into CD slot with label side up. The disc will be automatically loaded into the unit, even when it is off or at radio mode. The word LOAD will show on the display and the disc will play automatically. Press the EJECT Button to eject the disc from the slot.
  • Page 30 Audio Selection Press the MO/ST button on the headunit, or the AUDIO button on the remote control, in order to choose the audio language. The audio languages available differ from Disc to Disc. You can also use the setup menu to confirm. Refer to the packing of the Disc for details.

  • Page 31: Aux In, Rca Out, Sub Out&Video Out

    AUX IN, RCA OUT, SUB OUT&Video OUT Auxiliary Input The Auxiliary Input Jack is on the rear of unit. Insert the RCA plugs into the AUX IN jack on the rear of the unit. Route the other end of the RCA to the any external audio device such as walkman and discman. Press and hold the Mode button to choose AUX.

  • Page 32: Menu Operation

    Menu operation Press SETUP button on the remote control to display setup screen, use ENTER buttons to select the desired item: System, Language, Audio, Video, Digital. System setup TV system Select the TV system in the setting menu. Screen saver The screen saver appears if disc stop last more than 3 minutes.
  • Page 33 Video output mode Original setting: INTERLACE-YUV. Setting TV type Select TV type to watch wide screen movies. 4:3 Pan Scan: For 4:3 TV, left and right edges will be cut. 4:3 Letter Box: For 4:3 TV, black bars will appear on top and bottom. 16:9: For 16:9 wide screen TV.
  • Page 34 Note: The rating can be selected only under the password unlocked status, and the limits can be worked only under the password locked status. Load default If this item is selected, the unit will return to original setting. Language setup Setting the on-screen display language Select the language to be used for the on-screen display.
  • Page 35 Setting the subtitle language Select the language to be used for the Subtitles. You can select a preferred subtitle from those included in the DVD Video disk. (The screen on your player may have difference with the screen shown here) Setting the menu language Select the language to be used for the Menu.
  • Page 36 Setting volume Setup the volume with the buttons. Video setup Brightness Set the brightness of the video output with Contrast Set the contrast of the video output with...
  • Page 37 Set the hue of the video output with Saturation Set the saturation of the video output with Sharpness Set the sharpness of the video output with...

  • Page 38: Digital Setup

    Digital setup Output mode Select the output mode: LINE OUT: Compress the input signal. The volume is small. RF REMOD: The volume is large. Dynamic range When you select the compressed mode as line out , select it to adjust the compression proportion and get the different compressed effect.

  • Page 39: Anti-Theft System

    Anti-theft system Removing the panel 1. Press POWER button to switch off the power of the unit. 2. Press EJECT button to flip down the panel. 3. Hold the middle of the panel. Take off one end, and then take off the other end. 4.

  • Page 40: Handling Discs

    Handling discs Dirty, scratched or warped discs may cause skip ping or noise. Handle the disc only by the edges. To keep clean do not touch its surface. Discs should be stored in their cases after use to avoid scratches. Do not expose discs to direct sunlight, high humidity, high temperature or dust.

  • Page 41: Troubleshooting Guide

    Troubleshooting guide Cause Solution Symptom The car ignition is not on. If the power supply is properly connected to the car General No power The fuse is blown. accessory switch the ignition key to ACC . Replace the fuse. Presence of disc inside the player. Remove the disc in the player then put a new Disc Disc cannot be loaded.

  • Page 42: Specification

    Specification General. Power supply: 12V DC Current consumption/Fuse: max. 15A/ 15 A Maximum power output: 50Wx4 channels Dimensions (W x H x D) 178 x 50 x 165 mm Working temperature range: -20º - +60º FM Stereo Radio. Frequency range: 65.0 74.0/87.5 - 108.0 MHz Usable sensitivity/ I.F.
  • Page 43 ................................43 ...........................44 ...........................45 ............................49 ...............................53 .........................54 ..........................55 ..........................56 ........................57 ............................59 ..............................61 DVD/VCD/CD/MP3/CD-R..........................63 ...............................74 ............................81 ............................82 ..............................83 ....................84 ..........................85...
  • Page 44 -10º...
  • Page 45 4,75 5,56...
  • Page 48 ISO, (+)--- (-)--- (+)--- 12 (+)/ (-)--- (+)--- ((-)--- ACC+/ (+)--- (-)---...
  • Page 49 STEREO/MONO. EQ/LOUDNESS ( LOCAL/MENU (CLOCK) APS/SUB (BAND/NP) RADIO. OPEN...
  • Page 50 1. Disc playback: Set/Play/ Pause. 2. Disc playback: Stop 3. Disc playback: Track random play. 4. Disc playback: Intro play (10 seconds). 5. Disc playback: Track repeat play. 6. Display OSD menu MUTE POWER...
  • Page 53 MODE UP ( BAND/SYS (ENTER) LEFT ( STOP ST/PROGRAM AMS/RPT LOC/RDM PLAY/PAUSE MUTE TITLE RIGHT ( SETUP ANGLE SLOW VOLUME - ( ZOOM...
  • Page 54 SELECT ( VOLUME + ( AUDIO GOTO CR 2025 3 , +...
  • Page 55 PBC ( PBC, DVD-...
  • Page 56 DVD, CD, CD-R ( MP3, JPEG), CD-RW, icture CD, Photo CD icture CD Photo CD (Screen Saver) (Screen Saver). Screen Saver.
  • Page 57 DVD Video DVD- CD-R DVD- SVCD SVCD MPEG2. VCD. . SVCD VCD2.0 VCD1.1 VCD2.0 VCD2.0, VCD1.1 Picture CD VCD1.1 ( ) 74 DVCD DVCD. DVCD . DVCD CDDA CD-DA. CD-DA CD-DA ) 74 MP3/JPEG CD-R/CD-RW/CD-ROM MP3/JPG,...
  • Page 58 Picture-CD Picture-CD . Picture-CD Kodak. Photo-CD Photo-CD . Photo-CD Konica. CD-R/CD-RW CD-R/CD-RW ISO9660, 3, JPG, JPEG, Ac3, PCM, MP4, MPEG. DVD+/-R DVD+/-R UDF, 3, JPG, JPEG, Ac3, PCM, MP4, MPEG4, DivX (3.11/4.0/5.0/6.XX). MPEG4: DivX 3.11, DivX 4.0, DivX5.0, DivX6.XX DivX...
  • Page 59 POWER EJECT, POWER, MODE MODE RADIO ( DISC PLAY ( MODE AUX. VOL, VOL/BAS/TRE/BAL/FAD, VOLUME VOL. BASS ( TREBLE ( BALANCE FADER...
  • Page 60 LOUD EQ/LUD, LOUD ON LOUD OFF. VOL, EJECT, RESET, EQ/LUD CLASS POP ROCK OFF FLAT...
  • Page 61 MODE FM (FM1, FM2 FM3) AM (MW1 MW2). Seek +/- Tune up Tune down MON/ ST ST ON , LOC ON ; _DX_ .
  • Page 62 3 FM...
  • Page 63 DVD/VCD/CD/MP3/CD-R CD, HDCD, CD-R/RW, MP3,WMA, VCD, SVCD, DVD, DVD-ROM. : MP3 (*.mp3) WMA (*.wma) : MP4 (*.avi, DIVX3.11/4.0/5.0/6.XX and XVID) MPEG 2(*.vob) MPEG 1(*.dat) : JPEG (*.jpg) ISO 9660 ISO 9660 + Joliet - 448. - 99 44,1 : 32 - 320 : *.ACC, *.DLF, *.M3U, *.PLS, MP3 PRO, DRM.
  • Page 64 EJECT, LOAD, EJECT, MP3, JPEG, LOC/MENU TITLE...
  • Page 65 SEEK >>| SEEK >>| SEEK |<< SEEK |<< SEEK >>| SEEK |<< + OSD Setup ( RPT". Button 3: INT".
  • Page 66 RDM . 6: SETUP + MO/ST AUDIO Sub-T...
  • Page 67 GOTO ENTER ZOOM SLOW 1/8. Play/Pause. ANGLE INVALID KEY . BND/NP : NTSC, PAL, PAL60, AUTO. AUTO.
  • Page 68 PROG Enter PROG DVD 5...
  • Page 69 MP3, WMA, JPG DIVX, WMA. MP4, MPEG4 DivX (*.avi). DivX 3.11 6.XX. SEEK >>| SEEK >>|...
  • Page 70 SEEK |<< SEEK |<< SEEK >>| SEEK |<< 1-6,...
  • Page 71 VCD/CD EJECT, LOAD, EJECT, MP3, JPEG, SEEK >>| SEEK >>| SEEK |<< SEEK |<< SEEK >>| SEEK |<<...
  • Page 72 1-6 (OSD, INTRO, REPEAT, RANDOM, STOP & PLAY/PAUSE) VCD/CD MO/ST AUDIO VCD: AUDIO )--> ( )--> ( )--> ( )--> ( AUDIO )--> ( )--> ( VCD2.0 VCD 10 CD - 40 MP3 - 120...
  • Page 73 AUX, RCA, AUX IN. Mode AUX. RCA. ( RCA. AUX, BAND/P/N NTSC.
  • Page 74 SETUP ENTER,...
  • Page 75 : INTERLACE-YUV. 4:3 PS: 4:3. 4:3 LB: 4:3, 16:9: 16:9. 0000.
  • Page 77 SPDIF/ RAW: SPDIF/ PCM:...
  • Page 80 LINE OUT: RF REMOD: line out , Full , Off ,...
  • Page 81 POWER, EJECT,...
  • Page 84 RESET.
  • Page 85 12 , 15 / 15 178 50 165 -20º - +60º : 65.0 74.0/87.5 - 108.0 / 10.7 522-1620 DVD/SVCD/VCD/MP4/MP3/WMA/CD/HDCD/DVDAudio/MPEG4/D ivX/Picture-CD/Photo-CD/CD-R/CD-RW/DVD±R/JPEG NTSC/PAL / 24 0 - +/-30 16:9 4:3 1.0 , 75 RMS (+/-3 (A-vtd)/ . 2000...
