  • Page 1 H- CMD7079 DVD RECEIVER WITH BLUETOOTH DVD- C BLUETOOTH Instruction manual...

  • Page 2: Table Of Contents

    Dear customer! Thank you for purchasing our product. For safety, it is strongly recommended to read this manual carefully before connecting, operating and/or adjusting the product and keep the manual for reference in the future. Table of contents Table of contents ............................2 Important safeguards ............................3 Installation/Connections ..........................4 Panel controls..............................9...

  • Page 3: Important Safeguards

    Important safeguards Using the device at temperature below -10º may cause the breakage of the device. Before using please heat up the passenger compartment to the recommended temperature! Read carefully through this manual to familiarize yourself with this high-quality system. Disconnect the vehicle's negative battery terminal while mounting and connecting the unit.

  • Page 4: Installation/Connections

    Installation/Connections First complete the electrical connections, and then check them for correctness. If you are not confident working with electrical wiring, removing and reinstalling interior panels, carpeting, dashboards or other components of your vehicle, please call your dealer in order to have the unit professionally installed. Before the installation 1.
  • Page 5 Installation method A WARNING: Disconnect negative battery terminal from battery before starting installation. Consult the vehicle’s owner’s manual for proper instructions. Remove two transport screws from the top of the unit before installation. 1. After removing the old unit and mounting sleeve, insert supplied mounting sleeve in the opening. 2.
  • Page 6 Installation method B Note: Outer trim frame, hook, and mounting sleeve are not used for this installation. This is only intended as a general guide; contact the vehicle's manufacturer for specific instructions. This method of installation uses the screw holes at the sides of the unit and the holes of the existing vehicle mounting bracket.

  • Page 7: Electrical Connections

    Electrical connections Speaker Wiring Notes Follow the above wiring diagram to install the head unit with new or existing speakers. This unit is designed for use with four (4) speakers with the impedance between 4 Ohms to 8 Ohms. An impedance load of less than 4 Ohms could damage the unit.
  • Page 8 Never bridge or combine the speaker wire outputs. When not using four speakers, use electrical tape to tape the ends of the unused speaker outputs to prevent a short circuit. Never ground the negative speaker terminals to chassis ground. Using the ISO Connector 1.

  • Page 9: Panel Controls

    Panel controls Front panel 1. REL button 2. POWER button 3. PREVIOUS button 4. NEXT button 5. BD/NP/SUB button 6. APS button 7. MODE button 8. PHONE button 9. AUX IN 10. Numeric pad 11. MIC in 12. USB slot 13.
  • Page 10 14. SD slot 15. EJECT button 16. LCD display 17. Remote control sensor 18. DISC slot 19. ANSWER button 20. VOL/SEL knob 21. END CALL button Back of the front panel 1. Disc loading slot 2. Connector 3. RESET button 4.

  • Page 11: Remote Control (Rc)

    Remote control (RC) 1. POWER button 2. MODE button 3. BND/SYS button 4. Cursor (LEFT/RIGHT/UP/DOWN)/ ENTER button 5. STOP button 6. AMS/RPT button 7. ST/PROG button 8. LOC/RDM button 9. PREVIOUS/SEEK - button 10. MENU/PBC button 11. OSD button 12. MUTE button 13.
  • Page 12 23. VOL+/VOL-/SEL buttons 24. AUDIO button 25. Numeric pad 26. CLOCK DISPLAY/END CALL button 27. PHONE button Battery information of RC 1. Press the catch and at the same time pull out the battery tray. 2. Insert the 1 x lithium battery, type CR 2025 3V battery with the stamped (+) mark facing upward.

  • Page 13: Glossary

    Glossary PBC (PlayBack Control) PlayBack Control is a menu recorded on the disc with SVCD or VCD2.0 format. For the discs contained PBC, it can playback interactive software with the menu displayed on TV. And if the disc contains still images, it can playback high definition of still image.

  • Page 14: General Operations

    General operations Reset the unit Operating the unit for the first time or after replacing the car battery, you must reset the unit. Press RESET button to restore the unit to the original factory settings. Power button Press POWER button to turn on the unit. Press POWER to switch the power off. When you switch off the system or car ignition, the settings, tuner presets and the volume level will be retained in the unit’s memory.
  • Page 15 ROCK => FLAT. Keep pressing SEL/VOL knob for 2 seconds to select the RDS function: TA SEEK/ALARM => RETUNE L/S => MASK DPI/ALL. TA (Traffic Announcement) mode To determine what action will the radio take if the newly tuned station does not receive TP (Transport Program) information for 5 seconds.

  • Page 16: Adjusting Clock

    To mask only the AF with different PI. - MASK ALL To mask both PI and strong signal non-RDS station. Mute Press the MUTE button to activate the Mute function. Press it again or use the VOL/SEL knob on the panel or press the VOL+/VOL- buttons on the RC to cancel.

  • Page 17: Radio Operations

    Radio operations Note: RDS (Radio Data System) service availability varies with areas. Please understand if RDS service is not available in you area, the following service is not available, either. Choose Radio Band Press BND/SYS button on the RC or BD/NP/SUB button on the panel to select a band. The unit has with five bands: FM1, FM2, FM3, MW1 and MW2.
  • Page 18 Save Your Preset Stations There are six numbered preset buttons, which can store and recall stations for each band. If while listening to a radio station you would like to save the station as a pre-set, press and hold one of the numeric buttons 1-6 until you hear a beep.
  • Page 19 so that you do not have to re-tune the stations when driving between different transmitter coverage areas. When AF is on, it means RDS information is received; when AF is flashing, it means RDS information is not yet received. TA - TRAFFIC ANOUNCEMENT Press 8/TA numeric button on the panel so that the unit will be activated for reception of traffic announcement from local radio stations.

  • Page 20: Dvd Operations

    DVD operations Insert/Eject disc Insert a disc into disc slot with label side up. The disc will be automatically loaded into the unit, even when it is off or in radio mode. The word “LOAD” will show on the display and the disc will play automatically. Press EJECT button to eject the disc from the slot.
  • Page 21 Panel Numeric Pad functions The number 1-6 buttons contain dual functions during disc play. After pressing SETUP button (button 6 on the panel), the setup menu will be prompted. Then the number buttons are for navigating and confirming the commands. Button 1: Left/Display OSD Press the button 1 to navigate the setup menu leftward.

  • Page 22: Audio Selection

    Button 5: ENTER/Stop Press the button 5 as the ENTER button for confirming the commands on the setup menu. Press and hold the button for 3 seconds to stop the disc. The unit will be idle until further command is given. Press and hold the button 6 to play the disc again.

  • Page 23: Slow Motion

    Slow Motion Press SLOW button on the RC to perform slow motion of the video play. Slow motion speed within 1/2 up to 1/8 will be shown, according to the slowness. Cycle back to normal playback of press PLAY/PAUSE button to resume. Multi-Angle View Press ANGLE button on the RC to perform multi-angle playback.

  • Page 24: Mixed-Disc Operations

    Mixed-disc operations While you are playing mixed disc, which contains MP3, WMA, JPG or DivX formats, just insert the disc into the CD slot and the menu on the right hand side will be prompted. The unit will directly play the audio files. However, you can use the cursor buttons and ENTER button to select the format that you would like to view/listen to.
  • Page 25 Button 1-6 The functions of button 1-6 also apply to the mixed-disc play (See “DVD Operations” above). Return to the menu If you would like to go back to the playlist menu to choose the other file to view/listen to, press and hold button 5 to stop the playback.

  • Page 26: Vcd/Cd/Mp3 Operations

    VCD/CD/MP3 operations Insert/Eject CD Insert a disc into CD slot with label side up. The disc will be automatically loaded into the unit, even when it is off or at radio mode. The word “LOAD” will show on the display and the disc will play automatically. Press EJECT button to eject the disc from the slot.
  • Page 27 Audio Selection Press AUDIO button on the RC to choose the audio language. The audio languages available differ from disc to disc. You can also use the setup menu to confirm. VCD: Press AUDIO button during playback. It is possible to switch the sound between mono and stereo sound. The sequence is as follows: Left Vocal -->...

  • Page 28: Aux In, Rca Out, Sub Out, Video Out And Usb/Sd Operations

    AUX in, RCA out, SUB out, Video out and USB/SD operations Auxiliary Input The Auxiliary input jack is on the front of unit. Use the stereo jack wire (included) and connect to the stereo plug of the unit. Route the other end of the wire to the any external audio device. Press and hold the MODE button to choose AUX in.
  • Page 29 USB and SD Card Insert USB flash drive or SD memory card in corresponding slot on the panel. The unit will automatically detect and play files. Following file types are supported by the unit: MP3, MP4, DivX, JPG. Press MODE button on the panel or RC to change current mode.

  • Page 30: Menu Operations

    Menu operations Press SETUP button on the RC to display setup screen, use cursor LEFT/RIGHT and ENTER buttons to select the desired item: System, Language, Audio, Video, Digital. System setup TV system Select the TV system in the setting menu. Screen saver The screen saver appears if disc stop last more than 3 minutes.
  • Page 31 Video output mode Original setting: INTERLACE-YUV. Setting TV type Select TV type to watch wide screen movies. 4:3 Pan Scan: For 4:3 TV, left and right edges will be cut. 4:3 Letter Box: For 4:3 TV, black bars will appear on top and bottom. 16:9: For 16:9 wide screen TV.
  • Page 32 Setting rating The rating of the disc is from 1 to 8: (1) with the most limits when playing. (8) with the least limits when playing. Original setting: 8 Note: The rating can be selected only under the password unlocked status, and the limits can be worked only under the password locked status.
  • Page 33 Setting the audio language Select the language to be used for the audio. You can select a preferred audio from those included on the DVD video disk. (The screen on your player may have difference with the screen shown here). Setting the subtitle language Select the language to be used for the Subtitles.
  • Page 34 Audio setup Digital output Select digital output format. SPDIF/OFF: There is no signal output from coaxial or optical output. SPDIF/RAW: When the unit is connected with the amplifier by coaxial or optical connecter, please select this mode. SPDIF/PCM: When the unit is connected with the two-channel digital stereo amplifier, please select this mode.
  • Page 35 Contrast Set the contrast of the video output with UP/DOWN cursor buttons. Set the hue of the video output with UP/DOWN cursor buttons. Saturation Set the saturation of the video output with UP/DOWN cursor buttons.

  • Page 36: Digital Setup

    Sharpness Set the sharpness of the video output with UP/DOWN cursor buttons. Digital setup Output mode Select the output mode: LINE OUT: Compress the input signal. The volume is small. RF REMOD: The volume is large. Dynamic range When you select the compressed mode as “line out”, select it to adjust the compression proportion and get the different compressed effect.
  • Page 37 Dual mono Select the audio channel from STEREO, MONO L, MONO R and MIX MONO.

  • Page 38: Bluetooth Operations

    Bluetooth operations Pairing First, make sure the bluetooth function in your headset is set to “ON”. Then press and hold PHONE button until “PAIRING” blinks on the display waiting for the bluetooth device to connect. At this time, please run the bluetooth search and connect function in your cell phone.
  • Page 39 Answering call on the front panel When there is an incoming call, press ANSWER button to receive a call in your unit. You can perform this function on the front panel or on the RC. Ending call on the front panel When you have finished a call, or you do not want to answer it, press END CALL button anytime to hang up.
  • Page 40 speakers. Note: It is highly recommended that A2DP mode should not be used simultaneously with Phone mode. Please quit A2DP mode before attempting to make any phone call, otherwise unexpected results would occur, depending on different cell phone models.

  • Page 41: Handling Discs

    Handling discs Dirty, scratched or warped discs may cause skip ping or noise. Handle the disc only by the edges. To keep clean do not touch its surface. Discs should be stored in their cases after use to avoid scratches. Do not expose discs to direct sunlight, high humidity, high temperature or dust.

  • Page 42: Troubleshooting Guide

    Troubleshooting guide Cause Solution Symptom General The car ignition is not on. If the power supply is properly connected to the car No power accessory switch the ignition key to “ACC”. The fuse is blown. Replace the fuse. Disc Presence of disc inside the player. Remove the disc in the player then put a new upward.

  • Page 43: Specification

    Specification General Power supply: 12V DC Fuse: 10 A and 1 A Maximum power output: 50W x 4 Dimensions (W x H x D): 178 x 51 x 178 mm ESP function 10 sec. for Audio-CD, 120 sec for MP3 FM stereo radio Frequency range: 87.5 –...
  • Page 44 Frequency response: 20 Hz to 20 KHz S/N ratio (A-vtd)/Separation: 80dB/50dB Line out Output: 2 channels RCA line-out (2V) Bluetooth Bluetooth compatibility V 1.2/2.0 Specifications are subject to change without notice. Dimensions are approximate.
  • Page 45 ................................45 ...........................46 ...........................47 ............................52 ) .......................54 ..........................56 ............................57 ...............................60 DVD ..............................63 ..................68 VCD/CD/ 3........................70 AUX in, RCA, SUB out, USB/SD ...............72 ...............................74 ............................84 ..............................85 ....................86 ..........................88...
  • Page 46 -10º...
  • Page 51 ISO, (+)--- (-)--- (+)--- 12 (+)/ (-)--- (+)--- ((-)--- ACC+/ (+)--- (-)---...
  • Page 52 POWER PREVIOUS NEXT BD/NP/SUB MODE PHONE 12. USB Bluetooth...
  • Page 53 14. SD EJECT 16. LCD ANSWER VOL/SEL END CALL RESET 4. LED...
  • Page 54 POWER MODE BND/SYS ENTER STOP AMS/RPT ST/PROG LOC/RDM PREVIOUS/SEEK - MENU/PBC MUTE ANSWER GOTO PLAY/PAUSE SUB-T TITLE SETUP SLOW ANGLE ZOOM NEXT/SEEK +...
  • Page 55 VOL+/VOL-/SEL AUDIO CLOCK DISPLAY/END CALL PHONE CR 2025 3 , +...
  • Page 56 PBC ( – PBC, – DVD- –...
  • Page 57 RESET, POWER, POWER, MODE – RADIO, DISC PLAY, USB, SD Card AUX. VOL/SEL VOL+/VOL- VOL/SEL, : VOL => BAS => TRE => BAL => FAD => LOUD OFF => LOC OFF => STON => EQ OFF. VOLUME ( VOL/SEL VOL+/VOL- BASS ( ), TRE LE ( ), BALANCE (...
  • Page 58 FADER ( VOL/SEL, LOUD: VOL/SEL, LOUD ON ( LOUD OFF ( LOC: VOL/SEL, : LOCAL ON LOCAL OFF ( STEREO: VOL/SEL, : STEREO ON STEREO OFF. VOL/SEL, : OFF ( .) => CLASSIC => POP => ROCK => FLAT. VOL/SEL RSD: TA SEEK/ALARM =>...
  • Page 59 - RETUNE L: TA SEEK 90 Retune TA SEEK. MASK : MASK DPI MASK ALL. VOL/SEL - MASK DPI: - MASK ALL: RDS. MUTE, VOL+/VOL- VOL+/VOL- CLOCK DISPLAY VOL/SEL, VOL/SEL, VOL/SEL, CLOCK DISPLAY...
  • Page 60 RDS ( BND/SYS BD/NP/SUB FM1, FM2, FM3, MW1 MW2. NEXT/SEEK+ PREVIOUS/SEEK- PREVIOUS/NEXT ST/PROG «ST ON», LOC/RDM «LOC ON»,...
  • Page 61 «LOC OFF» (1-6) (1-6). EON (...
  • Page 62 AF ( 7/AF (ON) (OFF) AF ON ON ( TA ( 8/TA «TA SEEK». VOL/SEL SEEK TA ALARM; TA SEEK 8/TA; TA ALARM TA/TP PTY - PROGRAM TYPE ( 9/PTY (1-6), 9/PTY (1-6),...

  • Page 63: Dvd

    «LOAD», EJECT, 1/OSD PBC/MENU TITLE NEXT NEXT...
  • Page 64 PREVIOUS PREVIOUS PREVIOUS/SEEK- NEX/SEEK+ SETUP ( «RPT». (Intro) “INT". Intro...
  • Page 65 «RDM». 6: SETUP/ AUDIO SUB-T...
  • Page 66 GOTO ENTER ZOOM SLOW 1/8. PLAY/PAUSE. ANGLE «INVALID KEY». BND/SYS : NTSC, PAL, PAL60, AUTO. AUTO.
  • Page 67 ST/PROG Enter ST/PROG (ESP) (ESP) DVD– 5...
  • Page 68 MP3, WMA, JPG DivX, ENTER ENTER ENTER MP4, MPEG4 DivX (*.avi). NEXT NEXT PREVIOUS PREVIOUS...
  • Page 69 PREVIOUS/SEEK- or NEXT/SEEK+...

  • Page 70: Vcd/Cd

    VCD/CD/ «LOAD», EJECT, NEXT NEXT PREVIOUS PREVIOUS PREVIOUS/SEEK- or NEXT/SEEK+...
  • Page 71 AUDIO VCD: AUDIO ) --> ( )--> ( )--> ( )--> ( AUDIO ) --> ( )--> ( VCD2.0 MENU/PBC (ESP) (ESP) VCD, CD - 10 MP3 - 120...

  • Page 72: Aux In, Rca, Sub Out, Usb/Sd

    AUX in, RCA, SUB out, USB/SD AUX IN. MODE AUX. VOL/SEL RCA ( RCA. AUX. AUX.
  • Page 73 BND/NP/SUB NTSC. USB SD : MP3, MP4, DivX, JPG. MODE...
  • Page 74 SETUP ENTER, « ».
  • Page 75 : INTERLACE-YUV. 4:3 PS: 4:3. 4:3 LB: 4:3, 16:9: 16:9. 0000.
  • Page 78 SPDIF/ RAW: SPDIF/ PCM:...
  • Page 80 LINE OUT: RF REMOD: «line out», «Full», «Off»,...
  • Page 81 Bluetooth PHONE, «PAIRING». bluetooth «BT car stereo». «0000» bluetooth; PHONE ANSWER, END CALL. bluetooth ANSWER PHONE VOL/SEL “DIS CONN”. SEL,...
  • Page 82 ANSWER, END CALL «Hang up». bluetooth bluetooth bluetooth ANSWER, Melody ( PHONE, VOL/SEL, MELODY 1. VOL/SEL, PHONE VOL/SEL “MELODY”, VOL/SEL, «TEL»...
  • Page 83 A2DP « bluetooth». “BT PLAY” A2DP A2DP...
  • Page 86 “ ”. RESET.
  • Page 88 10 A 1 A 178 x 51 x 178 mm ESP: CD/120 c 87.5 - 108.0 – 1620 DVD/SVCD/VCD/HDCD/MP3/MPEG 4/WMA/CDDA/JPEG/DVD Audio/USB/SD/MMC DVD±R/±RW/CD/CD-R/CD-RW NTSC/PAL/NTSC/24 16:9 1,0 /75 (+/-3...
  • Page 89 - 20 RCA- (2V) Bluetooth Bluetooth V 1.2/2.0...
