Miscellaneous (others) set mode
C C I I - - V V B B a a u u d d R R a a t t e e
This item sets the data transfer rate. 300, 1200, 4800,
9600, 19200 bps and "Auto" are available.
When "Auto" is selected, the baud rate is automati-
cally set according to the connected controller or re-
mote controller.
C C I I - - V V A A d d d d r r e e s s s s
To distinguish equipment, each CI-V transceiver has
its own Icom standard address in hexadecimal code.
The IC-756PROII's address is 64h.
When 2 or more IC-756PROII's are connected to an
optional CT-17 -
CI V LEVEL CONVERTER
ing dial to select a different address for each IC-
756PROII in the range 01h to 7Fh.
C C I I - - V V T T r r a a n n s s c c e e i i v v e e
Transceive operation is possible with the IC-
756PROII connected to other Icom HF transceivers
or receivers.
When "ON" is selected, changing the frequency, op-
erating mode, etc. on the IC-756PROII automatically
changes those of connected transceivers (or re-
ceivers) and vice versa.
C C I I - - V V w w i i t t h h I I C C - - 7 7 3 3 1 1
When connecting the IC-756PROII to the IC-735 for
transceive operation, you must change the operating
frequency data length to 4 bytes.
• This item must be set to "ON" only when operating trans-
ceiver with the IC-735.
(continued)
A A u u t t o o
Auto baud rate
(default)
6 6 4 4 h h
Address of 64h
(default)
, rotate the tun-
O O N N
Transceive ON
(default)
O O N N
4 bytes of frequency data
9

SET MODE

1 1 9 9 2 2 0 0 0 0
19200 bps
7 7 F F h h
Address of 7Fh
O O F F F F
Transceive OFF
O O F F F F
5 bytes of frequency data
(default)
75
