To Hardmount In A 19-Inch 4-Post Rack - Sun Oracle Sun Netra T5440 Installation Manual

FIGURE 3-1
Figure Legend
1
2
19-inch 4-Post Rackmount Screw Kit Contents
TABLE 3-1
Number Description
8 M5 x 8 mm Phillips flathead screws
6 M5 x 8 mm Phillips panhead screws
12 M5 x 12 mm screws
12 M6 x 12 mm screws
12 M6 square clip nuts
12 10-32 x 0.5 in. combo head screws
12 12-24 x 0.5 in. combo head screws

▼ To Hardmount in a 19-Inch 4-Post Rack

1. Get the front hardmount brackets from the rack kit (
2. Using eight of the supplied M5 x 8 mm flathead Phillips screws (four screws for
each bracket), secure the front hardmount brackets to the sides of the server
(
FIGURE 3-2
Contents of the Hardmount 19-Inch 4-Post Kit
Side brackets
Screws
).
3 Rear plates
4 Rail guides
Where Used
8 for hardmount brackets
4-6 for rear mount brackets (depending on rack depth)
12 for rack, if appropriate
12 for rack, if appropriate
12 for rack, if appropriate
12 for rack, if appropriate
12 for rack, if appropriate
Chapter 3 Installing a Sun Netra T5440 Server Into a Rack
).
FIGURE 3-1
