- Page 1 USER GUIDE & INSTALLATION INSTRUCTIONS Classic 110 Dual Fuel Toledo 110 Dual Fuel Australia...
-
Page 3: Table Of Contents
Contents Before You Start... Installation Installation and Maintenance Service and Spares Peculiar Smells Dear Installer If You Smell Gas Provision of Ventilation Ventilation Location of Cooker Personal Safety Conversion Cleaning Positioning the Cooker Moving the Cooker Cooker Overview Fitting the Stability Bracket and Chain Hotplate Burners Fitting the Restraining Chain Wok Burner... -
Page 5: Before You Start
1. Before You Start... This User Guide covers a number of different models. Ventilation Although some of the illustrations will look different to CAUTION: The use of a gas cooking appliance results your particular model the functions will be the same. We in the production of heat and moisture in the room hope the meaning is clear. -
Page 6: Cleaning
Cooking high moisture content Foods for frying should be as dry as possible. Frost on frozen foods can create a ‘steam burst’ foods or moisture on fresh foods can cause hot fat to bubble when an oven door is opened. When up and over the sides of the pan. -
Page 7: Cooker Overview
2. Cooker Overview DocNo.020-0013 - Overview - 110DF - Classic, RM & Toledo lidded Fig.2-1 ArtNo.212-0002 - 110 Classic ceramic front view The 110 dual fuel cooker (Fig.2-1) has the following features: Fig.2-2 5 hotplate burners including a warmer and wok burner A control panel A grill Main conventional oven... -
Page 8: Wok Burner
The igniter should spark and light the gas. Keep holding the Fig.2-3 knob pressed in to let the gas through to the burner for about ten seconds. If, when you let go of the control knob, the burner goes out, then the FSD has not been bypassed. -
Page 9: The Wok Cradle (Optional Extra)
The Wok Cradle (optional extra) Fig.2-9 The wok cradle is designed to fit a 35 cm wok. If you use a different wok, make sure that it fits the cradle. Woks vary very widely in size and shape. It is important that the wok sits down on the pan support –... -
Page 10: Warmer
Warmer Fig.2-15 On the right of the hob is the warmer (Fig.2-15). Use the warmer for keeping food warm while the final touches are put to a meal. Turn the control knob counter-clockwise to the ‘On’ position. For best results, preheat a covered serving dish for 10 minutes before adding food to it. -
Page 11: The Ovens
The Ovens Fig.2-19 The clock must be set to the time of day before the ovens will work. See the following section on ‘The Clock’ for instructions on setting the time of day. References to ‘left-hand’ and ‘right-hand’ ovens apply as viewed from the front of the appliance. -
Page 12: The Clock
The Clock Fig.2-21 You can use the timer (Fig.2-21) to turn the ovens on and off. The clock must be set to the time of day before the ovens will work. Setting the Time of Day ArtNo.302-0002 - 6BC annotated When the clock is first connected the display flashes ( 0.00 ) ... -
Page 13: Key Lock
AUTO is Showing, You Want to Reset to Manual Fig.2-31 Fig.2-32 Cooking To return to manual cooking from any automatic setting, the ‘cook period’ must be cancelled. Press and hold the [] button and then press the [–] button until the display reads ArtNo.302-0009 - Activating ArtNo.302-0008 - the key lock 2... -
Page 14: Accessories
Accessories Fig.2-36 Oven Shelves Shelf guard The oven shelves (Fig.2-36) can be easily removed and refitted. Pull the shelf forward until the back of the shelf is stopped by the shelf stop bumps in the oven sides (Fig.2-37). Front Lift up the front of the shelf so the back of the shelf will pass under the shelf stop and then pull the shelf forward (Fig.2-38). -
Page 15: Cooking Tips
3. Cooking Tips Tips on Cooking with the Timer General Oven Tips If you want to cook more than one dish, choose dishes that The wire shelves should always be pushed firmly to the back require approximately the same cooking time. However, of the oven. -
Page 16: Cooking Table
4. Cooking Table DocNo.031-0004 - Cooking table - electric & fan single cavity The oven control settings and cooking times given in the table below are intended to be used Top (T) AS A GUIDE ONLY. Individual tastes may require the temperature to be altered to provide a preferred result. -
Page 17: Cleaning Your Cooker
5. Cleaning Your Cooker Isolate the electricity supply before carrying out any Fig.5-1 thorough cleaning. Allow the cooker to cool. NEVER use paint solvents, washing soda, caustic cleaners, biological powders, bleach, chlorine based bleach cleaners, coarse abrasives or salt. DO NOT mix different cleaning products – they may react together with hazardous results. -
Page 18: Grill
Grill Fig.5-5 The grill pan and trivet should be washed in hot soapy water. Alternatively, the grill pan can be washed in a dishwasher. After grilling meats or any foods that soil, leave to soak for a few minutes immediately after use. Stubborn particles may be removed from the trivet using a nylon brush. -
Page 19: Cleaning Table
Cleaning Table Removing the Main Oven Linings Some of the lining panels can be removed for cleaning. Cleaners listed (Table 5-1) are available from supermarkets or electrical retailers as stated. If you wish to clean the enamel interior of the oven, you will need to remove the shelves before removing the ‘Cook For enamelled surfaces use a cleaner that is approved for use &... -
Page 20: Troubleshooting
6. Troubleshooting Hotplate ignition or cooktop burners faulty If there is an installation problem and I don’t get my original installer to come back to fix it who pays? Is the power on? You do. Service organizations will charge for their call Are the sparker (ignition electrode) or burner holes outs if they are correcting work carried out by your blocked by debris? - Page 21 Oven not coming on Fig.6-1 Is the power on? If not there may be something wrong with the power supply. Is the cooker supply on at the circuit breaker? ArtNo.324-0005 Oven light bulb Have you set a cooking function? Oven temperature getting hotter as the cooker gets older If turning the knob down has not worked or only worked for a short time then you may need a new Fig.6-2...
-
Page 22: Installation
INSTALLATION Check the appliance is electrically safe and gas sound when you have finished. 7. Installation Service and Spares Firstly, please complete the appliance details below and keep them safe for future reference – this information will enable us to accurately identify the particular appliance and help us to help you. Filling this in now will save time and inconvenience if you later have a problem with the appliance. -
Page 23: Dear Installer
INSTALLATION Check the appliance is electrically safe and gas sound when you have finished. Dear Installer Provision of Ventilation Before you start your installation, please complete the details This appliance is not connected to a combustion products below, so that, if your customer has a problem relating to evacuation device. - Page 24 INSTALLATION Check the appliance is electrically safe and gas sound when you have finished. Checking the Parts: You will need the following equipment to complete the cooker installation satisfactorily: 3 pan supports Griddle plate • Flexible gas hose. • Gas pressure tester/manometer. •...
-
Page 25: Positioning The Cooker
INSTALLATION Check the appliance is electrically safe and gas sound when you have finished. Positioning the Cooker Fig.7-1 The diagram (Fig.7-1) shows the minimum recommended distance from the cooker to nearby surfaces as given in AS 5601. *Any splashback must be fitted in accordance with the manufacturers instructions. -
Page 26: Moving The Cooker
INSTALLATION Check the appliance is electrically safe and gas sound when you have finished. Moving the Cooker Fig.7-3 On no account try and move the cooker while it is plugged into the electricity supply. The cooker is very heavy, so take great care. We recommend that two people manoeuvre the cooker. -
Page 27: Fitting The Stability Bracket And Chain
INSTALLATION Check the appliance is electrically safe and gas sound when you have finished. Fitting the Stability Bracket and Chain Fig.7-6 Stability bracket A stability bracket and chain MUST be fitted when the cooker is connected to a flexible gas supply. Unless properly installed, the cooker could be tipped by Cooker leaning on the door. -
Page 28: Levelling
INSTALLATION Check the appliance is electrically safe and gas sound when you have finished. Levelling Fig.7-9 You are recommended to use a spirit level on a shelf in one of the ovens to check for level. Place the cooker in its intended position taking care not to twist it within the gap between the kitchen units as damage ArtNo.215-0026 - Handle gaskets fixed may occur to the cooker or the units. -
Page 29: Pressure Testing
INSTALLATION Check the appliance is electrically safe and gas sound when you have finished. Gas Connection Fig.7-12 Must be in accordance with the relevant standards. The gas supply needs to terminate with a down-facing threaded fitting ½” connection. The inlet connector is located just below the hotplate level at the rear of the cooker. -
Page 30: Electrical Connection
INSTALLATION Check the appliance is electrically safe and gas sound when you have finished. Electrical Connection Fig.7-13 This appliance must be installed by a qualified electrician to comply with the relevant regulations (AS/NZS 60335.2.6) and also the local electricity supply company requirements. -
Page 31: Final Checks
INSTALLATION Check the appliance is electrically safe and gas sound when you have finished. Final Checks Fig.7-17 Note: The clock must be set before the ovens will work. See ‘The Clock’ section for instructions on setting the time of day. Hotplate Check Check each burner in turn. -
Page 32: Conversion To Propane Gas
WARNING – SERVICING TO BE CARRIED OUT ONLY BY AN AUTHORISED PERSON Disconnect from electricity and gas before servicing. Check appliance is safe when you have finished. 8. Conversion to LP Gas Conversion from Natural Gas (1.0 kPa) Fig.8-1 to LPG X Propane (2.54 kPa) A suitably competent person must perform the conversion. - Page 33 WARNING – SERVICING TO BE CARRIED OUT ONLY BY AN AUTHORISED PERSON Disconnect from electricity and gas before servicing. Check appliance is safe when you have finished. Set the Governor Fig.8-4 Unscrew the governor’s brass top. In the base of the brass top is a plastic snap-in converter device (Fig.8-4).
-
Page 34: Hotplate
WARNING – SERVICING TO BE CARRIED OUT ONLY BY AN AUTHORISED PERSON Disconnect from electricity before servicing. Check appliance is safe when you have finished. 9. Servicing BEFORE SERVICING ANY GAS CARRYING Fig.9-1 COMPONENTS TURN OFF THE GAS SUPPLY Check the appliance is gas sound after completion of service. - Page 35 WARNING – SERVICING TO BE CARRIED OUT ONLY BY AN AUTHORISED PERSON Disconnect from electricity before servicing. Check appliance is safe when you have finished. 2.5 To Replace a Hotplate Burner Right-hand tray From the rear remove the screws securing the flue grill DISCONNECT FROM THE ELECTRICITY SUPPLY.
- Page 36 WARNING – SERVICING TO BE CARRIED OUT ONLY BY AN AUTHORISED PERSON Disconnect from electricity before servicing. Check appliance is safe when you have finished. Assemble the new switch to the bezel by lining up the Fig.9-4 key sections and pushing home. Fit the new button by pushing in from the front.
-
Page 37: Ovens
WARNING – SERVICING TO BE CARRIED OUT ONLY BY AN AUTHORISED PERSON Disconnect from electricity before servicing. Check appliance is safe when you have finished. Carefully lift the elements out and disconnect the leads Fig.9-5 from the element terminals, noting their position. If it is not possible to disconnect the leads in this way, pull cooker forwards to gain access to the rear. -
Page 38: Doors
WARNING – SERVICING TO BE CARRIED OUT ONLY BY AN AUTHORISED PERSON Disconnect from electricity before servicing. Check appliance is safe when you have finished. The cut-out is located on the earth plate beside the Fig.9-6 oven element connections. Disconnect the cut-out wiring. - Page 39 WARNING – SERVICING TO BE CARRIED OUT ONLY BY AN AUTHORISED PERSON Disconnect from electricity before servicing. Check appliance is safe when you have finished. Reassemble in reverse order, making sure that the Fig.9-11 gasket is fitted between the hinge arm and the front of Centreline of hinge pin the grill chamber.
-
Page 40: Circuit Diagram
10. Circuit Diagram P095199 P025635 P093292 The connections shown in the circuit diagram are for single-phase. The ratings are for 230 V 50 Hz. Code Description Code Colour Code Description Grill control Blue Warmer control Grill element left-hand side Brown Warmer Grill element right-hand side Black... -
Page 41: Technical Data
11. Technical Data DocAUS.101-0024 - Technical data - DF 110 - Classic-Toledo This cooker is designed for use on Natural Gas, although a conversion for LP (LPG X Propane (2.54 kPa)) gas is packed with the cooker. INSTALLER: Please leave these instructions with the user. DATA BADGE LOCATION: Cooker back, serial number repeater badge below oven door opening. - Page 44 Clarence Street, Royal Leamington Spa, Warwickshire, CV31 2AD, England. Tel: +44 (0) 1926 457400 Fax: +44 (0) 1926 450526 E-mail: consumers@falconappliances.co.uk...
