1
DP 80F / 85F
Instruction manual
Dear Reader.
Thank you for your interest in a Toshiba Fax machine!
To allow you to get your fax machine up and running as soon
as possible, this manual only covers the most important criteria.
Complete operating instructions can be found on the CD-ROM
included with the accessories.
All items documented on the CD are highlighted in grey
both in the table of contents.
Please refer to the corresponding references on the CD for
further information
(IBM
-compatible format).
®
