Racelogic VBOX 3iSL User Manual page 44

VBOX 3iSL User Guide
01/12/2011
Connector 1 POWER
PIN In/Out Description
1 I Power +
2 I Ground
Connector 2 AD 1
PIN In/Out Description
1 O Analogue 1 Output
2 O Digital 2 Output
3 I Ground
Connector 3 AD 2
PIN In/Out Description
1 O Analogue 2 Output
2 O Digital 1 Output
3 I
Connector 4 D IN
PIN In/Out Description
1 I Ground
2 I Digital Input 2. Start/Stop Logging
3 I Digital Input 1. Brake Trigger
Type Lemo 2 pin
Range
7V to 30V
0V
Type Lemo 3 pin
Range
0V to 5V
0V to 5V
Type Lemo 3 pin
Range
0V to 5V
0V to 5V
Type Lemo 3 pin
Range
0V to 5V (14v
tolerant)
0V to 5V (14v
tolerant)
Page 44 of 49
