WellGate M4 GSM IP Gateway

User Guide

Version: 1.0
Date: September, 2014

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the WellGate M4 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for WELLTECH WellGate M4

Summary of Contents for WELLTECH WellGate M4

  • Page 1: User Guide

    WellGate M4 GSM IP Gateway User Guide Version: 1.0 Date: September, 2014...

  • Page 2: Table Of Contents

    1-3 Environmental ................5 1-4 Front Panel: LED Indicators ............. 5 1-5 Rear Panel: connections..............6 1-5-1 Accessories of WellGate M4 packing ........... 7 1-5-2 Typical application of GSM IP Gateway ........7 1-6 QUICK SETUP ................9 CH2 Device Settings ................13 2-1 Network Configuration ..............
  • Page 3 5-1 SIP ....................36 5-2 Audio ....................39 CH6 Dialing Plan ................. 40 6-1 General.................... 40 6-2 Dialing Rule ..................41 6-3 Digit Manipulation (DM) ............... 42 6-4 Phone Book..................43 CH7 CO Setting ..................45 7-1 CO line .................... 46 CH8 SIP Trunk ..................

  • Page 4: Ch1 Introduction

    CH1 Introduction WellGate M4 GSM SIP IP Telephony Gateway WellGate M4 is a 4 lines GSM (WellGate M4) VoIP gateway which includes 1-WAN and 1-LAN (management port) 10/100 base-T network environment. Field-proven quality of Voice communication and broadband access network to makes WellGate M4 to be an excellent solution for various VoIP applications with GSM network.

  • Page 5: Environmental

    1-3 Environmental Actual Dimension: 19-inch chassis, 1U high, 11 CM depth  Weight: 2.3kg (One unit with packing)  Operating Temp. & Humidity  - Temp.: 0℃～45℃ (32℉～113℉) - Humidity: 10％～85% relative humidity, non-condensing Storage Temp. & Humidity  - Temp.: 0℃～55℃ (32℉～131℉) - Humidity: 10％～95％...

  • Page 6: Rear Panel: Connections

    1. Please turn OFF electric 12Vdc power when you want to remove or insert SIM card from WellGate M4. 2. Once you insert SIM card to WellGate M4 while electric 12Vdc is still ON, please visit webpage configuration at CO Line  Select one CO Line ID (GSM) ...

  • Page 7: Accessories Of Wellgate M4 Packing

    1pcs 1-5-2 Typical application of GSM IP Gateway 1. WellGate M4 can integrate with IP-PBX to connect with local PSTN network via GSM cellular base station (CBS). For legend connection with PSTN network, fixed land lines were often used. Therefore, one FXO gateway or E1 gateway needs to install between local PSTN network and IP-PBX office.
  • Page 8 The alternative application of GSM gateway is to register to IP Telephony Service provider’s soft Switch in order to transit GSM incoming call to remote IP devices or international call.

  • Page 9: Quick Setup

    User Name root and user password is root). (See Password (the default user id is figure 1-6-1 web access) Figure 1-6-1 web access Step 2: After login, the screen shows the Home page of WellGate M4. (See figure 1-6-2 Network configure-1)
  • Page 10 Figure 1-6-2 Network configure-1 Change Default IP Network: Step 3: After successfully login to the system, we need to change the network configuration. Click Device Setting --> Network to setup the service network interface (WAN) parameters. Enter the IP address, subnet mask and default gateway or selected to “DHCP”...
  • Page 11 Figure 1-6-4 Time setting Modify SIP Account Parameter: Step 5: The next step is to add a SIP trunk for VOIP calling. For WellGate M4, it is necessary for VOIP calling. Click SIP trunk and new to create the SIP trunk in details.
  • Page 12 Figure 1-6-5 SIP Trunk Soft Reset WellGate M4: Step 6: After modify basic setting. It is required to restart WellGate M4. Click Maintenance --> Maintenance --> Quick-Reset or Reboot to take effect. Apply the change by clicking Apply button to save changes. (See Figure 1-6-6...

  • Page 13: Ch2 Device Settings

    CH2 Device Settings From this setting category, all devices related parameters can be found here. 2-1 Network Configuration > Network Figure 2-1 network setting Parameter Description: Setting:  IP Support: IPv6 or IPv4 stack to be supported. There are three options: IPv4 Only, IPv4/IPv6 or IPv6 Only.
  • Page 14  Netmask: The subnet mask IP of LAN port.  Bridge mode: At this mode, both WAN and LAN ports are configured to Switch/Hub features. When you want to access WellGate M4 via LAN port , please use WAN port IP address instead.

  • Page 15: Device Time Setting

    2-2 Device Time Setting WellGate M4 supports NTP time server with time zone and daylight saving. Device Setting --> Time Figure 2-2 Time setting Parameter Description: Current Time: Show up current time and date.  NTP Time Server To enter NTP time server IP address.
  • Page 16 - Apply Week (Day:01 to 05, Specifies the occurrence of day in the month; 01 = First occurrence of day, 02 = Second occurrence of day, ...and 05 = Last occurrence of day) - Hour: 00 to 23...

  • Page 17: Device Advance Setting

    2-3 Device Advance Setting --> Advance Figure 2-3 Advance setting Parameter Description:  HTTP Service: The HTTP Web service port (the default is 80).  HTTPS Service: The HTTPS web service port (the default is 443).  Telnet Service: The telnet service port (the default is 23). ...

  • Page 18: User Login Setting

     User: The user access right which only allows to setting some user related features.  User ID: Login User ID.  Password: Login Password.  Confirm Password: Confirm new password again.  Language: The web page language used when the account login. To add a customized local language, please contact Welltech.

  • Page 19: Debug Settings

    2-5 Debug Settings WellGate M4 provides the real time debug to syslog or through telnet interface. It generates the debug information based on debug level and modules. Since the generating debug consumes system resources, it is recommended to turn on only for debug period and under Welltech FAE’s instructions.

  • Page 20: Event Notice

     DSP Capture port: Syslog capture server service port (default is 50000) 2-6 Event Notice WellGate M4 can send Syslog Event Notice when it has the following cases: 1. Register Failure or re-registered. 2. SIM card is ready or not.

  • Page 21: Auto Provision

    2-7 Auto Provision -->Provision WellGate M4 offer configuration interface and allow manager to establish a HTTP auto provision server to configure this gateway automatically. Once you enable and select HTTP, the following fields are related to HTTP server security parameters.

  • Page 22: Snmp

    2-8 SNMP WellGate M4 offers SNMP agent for central sites to manage and provision. Figure 2-8 SNMP SNMP Agent:  SNMP Agent: Enable SNMP or not.  Read Only Community Name: The community name to read through SNMP protocol  Read Write Community Name: The community name to read and write through SNMP protocol.
  • Page 23  Subnet Mask: The network mask for a trusted peer when you specify an Subnet. SNMP Trap:  SNMP Trap: Enable SNMP trap or not  Destination: The IP address for SNMP manager to receive the SNMP trap  Community: The community name for sending the SNMP trap...

  • Page 24: Ch3 Nat Setting

    CH3 NAT Setting WellGate M4 can support NAT, 2 Ethernet ports (WAN and LAN) or Bridge mode. Here are the settings for NAT related services. 3-1 DHCP Ser. (DHCP server) Figure 3-1 DHCP server  DHCP Server: Enable DHCP server or not at LAN port.

  • Page 25: Upnp (Universal Plug And Play Server)

    3-2 UPnP (universal plug and play server) Figure 3-2 UPnP To enable UPnP server or not. 3-3 Bandwidth (Bandwidth Control) By using bandwidth control feature, the user can manage the data traffic based on their needs. Figure 3-3-1 Bandwidth control Bandwidth Control: ...
  • Page 26 Figure 3-3-2 Bandwidth control Specific: define maximum and Reserved bandwidth in Kbps for  download and upload. priority 1 – Download: highest priority download bandwidth  priority 2 – Download: normal priority download bandwidth  priority 3 – Download: low priority download bandwidth ...
  • Page 27 Figure 3-3-5 IP Target 2  Priority: Priority value for the target  Type: The target type was set up to IP  Configure Type: unique IP or a range of IP address Unique:  IP Address: the IP address to be set ...
  • Page 28 Application Target  Figure 3-3-7 Application Target  Priority: Priority value for the target  Type: Application  Application: the list for the application DSCP target  Figure 3-3-8 DSCP Target  Priority: Priority value for the target  Type: DSCP value ...

  • Page 29: Url Filter

    WellGate M4 supports firewall features as follows. 3-4 URL Filter Figure 3-4 URL Filter  URL Filter: the specified URL will be blocked. 3-5 IP Filter Figure 3-5 IP Filter IP Filter: The specified IP address to be blocked. ...

  • Page 30: App Filter

     using only 1 port, please set up the starting equal to stopping port. Protocol: TCP, UDP or both are used for port blocked.  3-9 Port Fwd WellGate M4 supports port forward feature as follows. Figure 3-9 Port Fwd...
  • Page 31  Port Fwd: enable port forward feature or not.  Port Range: Starting and stopping port to be forwarded. If you are using only 1 port, please set up the starting equal to stopping port.  Protocol: TCP, UDP or both are used for port forward. ...

  • Page 32: Ch4 Voip Setting

    - TOS: Type of Service which include IP precedence value and TOS.  Accept Proxy Only: If you select YES, only accept the call coming from the registered SIP proxy. WellGate M4 Do Not accept peer to peer call at this mode, neither accept from different SIP proxy. This configuration prevent from hacker attacking.

  • Page 33: Audio

    gateway can be configured to Peer to Peer mode. For P2P call, you also need to configure Phone book in order to dial remote site phone number to send IP address directly. Please refer to Chapter 6-4: Phone Book configuration. 4-2 Audio Figure 4-2 Audio setting ...
  • Page 34  G.711u Payload Size: G.711 u-Law payload size: 20ms and 40ms.  G.711a Payload Size: G.711 A-law payload size: 20ms and 40ms.  G.729 Payload Size: G.729A payload size: 20ms, 40ms, and 60ms.  GSMFR Payload Size: GSMFR payload size: 20ms, 40ms, and 60ms. ...

  • Page 35: Nat Traversal

    4-3 NAT Traversal WellGate M4 supports the following NAT traversal methods when it was installed behind private IP address. Figure 4-3 NAT Traversal  NAT Traversal: Disable: Disable NAT traversal features.  STUN (Type 1,2): Enable STUN for NAT traversal. Since ...

  • Page 36: Ch5 Voip Advance

    CH5 VOIP Advance 5-1 SIP Figure 5-1 SIP Parameter Description:  SIP Hold Type: SIP up on hold message sending method. - Send Only: Set the SDP media to send only when send an on-hold SIP message. - 0.0.0.0: Set up the SDP connection to 0.0.0.0 when send an on-hold SIP message.
  • Page 37 as defined in RFC3261. For example, when an unreliable transport protocol is used, general requests are retransmitted at an interval which starts at T1 and doubles until reaches T2. If a provisional response is received, retransmission continue but at an interval of T2. (Default Value: 4000ms) SIP T4 (msec): T4 represents the amount of time the network ...
  • Page 38 will wait for indefinitely for the final response.  First Response Timer (msec): When sending a request out, the User Agent waits for this timer for any response received from UAS. If timer is expired and not any SIP message is received, the User Agent will think the request is failed.

  • Page 39: Audio

     Max Jitter Buffer (msec): The Maximum delay time of Jitter buffer.  Max Echo Tail Length (G.168): Enable the echo cancellation feature. The default setting is 128ms.  Jitter Opt. Factor: Jitter buffer dynamic factor for optimize. Please set to 7 unless under Welltech’s instruction to change.

  • Page 40: Ch6 Dialing Plan

    CH6 Dialing Plan 6-1 General Figure 6-1 General setting  First Digit Time Out: Specify the maximum waiting time to dial the first digit once you hear dial tone. The range is 1~60 sec.  Inter Digit Time Out: Specify the interval time to wait for the next digit to enter before sending out.

  • Page 41: Dialing Rule

    6-2 Dialing Rule Figure 6-2 Dialing Rule setting Dialing rule is used to speed up the dialing procedure while you have dialed complete digits. Some users don’t like to use the end of dialing digit such as key, this GSM gateway can be configured to use dialing rule instead. The longest digits of prefix code will be selected first if it was matched.

  • Page 42: Digit Manipulation (Dm)

    City Call 6-3 Digit Manipulation (DM) The Digit Manipulation is to define outgoing call rule and will be processed based on prefix code and DM group after the DNIS is determined. Figure 6-3 Digit Manipulation setting  DM Group: Different DM group have different dial plan to be used. ...

  • Page 43: Phone Book

    3 seconds to dial remaining digits, 1234. 6-4 Phone Book Phone Book is used to send out SIP IP peer to peer call from WellGate M4. The limitation of maximum phone book is 100 records. Attention:...
  • Page 44  Import: To reload setting of phone book from your computer hard disk.

  • Page 45: Ch7 Co Setting

    CH7 CO Setting The CO Line setting contains the GSM related parameters. Figure 7-0 CO setting  Line ID: There are four GSM lines. Line ID indicates one of them (L1 to L4).  State: The GSM line is active or inactive. ...

  • Page 46: Co Line

    7-1 CO line Figure 7-1 CO setting  Line ID: There are four GSM lines. Line ID indicates one of them (L1 to L4).  Line Type: The line type is GSM.  Line State: To activate if you would like to use this line. Otherwise, inactive to disable this line.
  • Page 47 8 bits raw file. Attention: How to record your own greeting file ? WellGate M4 doesn’t provide any tool for you to record your own greeting file. You may use computer with recording program and install external microphone to record.
  • Page 48 “Reset” button to that GSM line in order to activate GSM module.

  • Page 49: Ch8 Sip Trunk

    WellGate M4 via SIP IP Trunk. WellGate M4 needs to be set up the SIP trunk for VOIP outgoing call from GSM line and incoming call from SIP Trunk to GSM line. There are up to 4 SIP trunk can be used for whole system.

  • Page 50: Create Sip Trunk

    Figure 8-1 SIP Trunk page  Trunk ID: SIP trunk ID.  Register Type: Whether this account need register or not. Register: When it was set up to register, WellGate M4 will send  REGISTER message to SIP proxy server (or IP-PBX server) for registration.
  • Page 51 SIP URL, the SIP FROM header’s URL will be GSM_Tel_NO@local_IP_address. Attention: The following guideline could be used for the most application cases: 1. If the WellGate M4 was registered at SIP proxy or IP-PBX and was configured as a gateway, Please enter “PSTN caller ID” at both Display Name and Caller ID field.
  • Page 52  Keep Alive: Enable or Disable it.  Keep Alive Time (sec): Specify of times in second to send SIP register message to proxy server or IP-PBX.  For DNIS is Registered TEL: This feature was used for SIP Trunk incoming call and outgoing to GSM line.

  • Page 53: Ch9 Route Plan

    CH9 Route Plan The core of WellGate M4 is the routing policy. The policy is based on incoming call type/target, length and prefix to determinate the outgoing call process. For VOIP incoming call, it can send to GSM interface and vice versa.

  • Page 54: Create Route Plan

    9-1 Create Route Plan Click Route Plan and Click new to create a new routing policy. Figure 9-1 Route Plan setting  Incoming Call Type: Incoming call type VOIP: The incoming call from SIP Trunk VoIP. It can only  route to GSM.
  • Page 55 the routing list order one by one (01 is the first priority and 04 is the lowest priority). Cyclic Ring: The outgoing call will be hunted based on  the cyclic basis from 01 to 04 and repeat. This is the recommended method.

  • Page 56: Ch10 Status

    CH10 Status WellGate M4 shows out the current system status here. Figure 10-0 Device Status 10-1 Device Status See the figure 10-0 Device Status  Model: The model number, WellGate M4.  MAC-Address: The MAC address of WellGate M4  Network Type: The Network Interface Type Settings ...

  • Page 57: Sip Trunk Status

    is unknown or undetected.  IMEI: It indicates International Mobile Station Equipment Identity. Which is a number, usually unique to identify 3GPP (i.e., GSM, UMTS and LTE) and iDEN mobile phones, as well as some satellite phones.  IMSI: It shows International Mobile Subscriber Identity which is used to identify the user of a cellular network and is a unique identification...

  • Page 58: Ch11 Maintenance

    CH11 Maintenance WellGate M4 can be managed by this management page for upgrading firmware or reset. Figure 11-0 Maintenance  Backup: Backup the system settings to your Computer for restoring purpose.  Restore (*.ini): Restoring the backup setting back to WellGate M4.

  • Page 59: Appendix A --- System Recovery

    Start the WellGate M4 and to check the STATUS LED is up or not. If STATUS LED is ON, please press the reset button for 5 seconds to reset to default. After all LED are light up, the system is back to factory settings.
  • Page 60 download the firmware into tftp data directory In the telnet terminal, do the following command 1. __dmctw 2. cd /config_fs 3. rm -f wg26*.bin 4. tftp –g –r wg26.1.01_1DSP_1.0.bin 192.168.123.111 4. copy firmware successfully 5. reboot Check whether the system was recovered or not...

  • Page 61: Appendix B --- Http Auto Provision

    Appendix B --- HTTP auto provision Get the http provision packet from Welltech and start the provision as follows: Step 1: build mac list for mass configuration file generation For GSM> WellGate M4 MAC.csv contains most frequent changed parameters as follows: MACAddress: WellGate M4 MAC Address Siptk1.displayname ~ siptk4.displayname: display name for each GSM...
  • Page 62 Step 5: Put the “*.cfg” file into http or ftp directory. Set up the provision settings in WellGate M4 and reboot to test it. You can use the hfs for http file server. It can be downloaded from http://www.rejetto.com/hfs/. Note: please link it to download provision file. More information please refer to “wgM4 Parameter.txt”.
