Wellgate 5260 V6.0 JSP Upgrade Procedure
Prior to start the upgrade procedure, please make sure the latest 6.2.0 firmware is
installed correctly. Please do the upgrade in local area network and make sure the
Wellgate 5260 will not be restarted during the upgrade. Otherwise, Wellgate 5260 might
not boot correctly after upgrade.
Step 1. Identify the Wellgate 5260 Hardware version:
System > License: H/W Version 2.0
Note:
This release can only support hardware version 2.0. Please check the
H/w Version in license before upgrade.
Setp2. Backup old configuration for unexpected upgrade result or
downgrade
Create backup directory:
cd D:\
mkdir 5260bak
cd 5260bak
mkdir dbfile
mkdir binfile
mkdir cdr
FTP Backup Command:
ftp xxx.xxx.xxx.xxx
prompt off
binary
cd d:\ap\binfile
Advertisement
Related Manuals for WELLTECH 5260 V6.0 JSP - UPGRADE PROCEDURE
Summary of Contents for WELLTECH 5260 V6.0 JSP - UPGRADE PROCEDURE
- Page 1 Wellgate 5260 V6.0 JSP Upgrade Procedure Prior to start the upgrade procedure, please make sure the latest 6.2.0 firmware is installed correctly. Please do the upgrade in local area network and make sure the Wellgate 5260 will not be restarted during the upgrade. Otherwise, Wellgate 5260 might not boot correctly after upgrade.
- Page 2 lcd d:\5260bak\binfile mget * cd d:\ap\dbfile lcd d:\5260bak\dbfile mget * cd d:\ap\cdr lcd d:\5260bak\cdr mget * cd d:\ lcd c:\5260bak get wgos.sdi (Backup Example) C:\>ftp 192.168.19.175 Connected to 192.168.19.175. 220 Server ready User (192.168.19.175:(none)): root 331 Password required for root. Password: 230 User root logged in.
- Page 3 226 File sent ok ftp: 1251173 bytes received in 1.27Seconds 988.29Kbytes/sec. 200 Port command successful. 150 Opening data connection for tgbin.bin. 226 File sent ok ftp: 4249896 bytes received in 4.33Seconds 981.95Kbytes/sec. 200 Port command successful. 150 Opening data connection for voxfile.bin. 226 File sent ok ftp: 1540466 bytes received in 1.61Seconds 957.41Kbytes/sec.
- Page 4 226 File sent ok ftp: 125 bytes received in 0.00Seconds 125000.00Kbytes/sec. 200 Port command successful. 150 Opening data connection for ntpreg.reg. 226 File sent ok ftp: 908 bytes received in 0.00Seconds 908000.00Kbytes/sec. 200 Port command successful. 150 Opening data connection for sipconfig.ini. 226 File sent ok ftp: 3370 bytes received in 0.00Seconds 3370000.00Kbytes/sec.
- Page 5 ftp> mget * 200 Type set to I. 200 Port command successful. 150 Opening data connection for REPT20090221.log. 226 File sent ok ftp: 1080 bytes received in 0.00Seconds 1080000.00Kbytes/sec. 200 Port command successful. 150 Opening data connection for REPT20090222.log. 226 File sent ok ftp: 1080 bytes received in 0.00Seconds 1080000.00Kbytes/sec.
- Page 6 220 Connected to FTPD User (192.168.19.175:(none)): root 331 Password required for root. Password: 230 User root logged in. ftp> del wgos.sdi 250 DELE command successful. ftp> Local directory now C:\5260JSP. ftp> 200 Type is set to I. ftp> put wgos.sdi 200 PORT command successful.
- Page 7 C:\5260JSP\binfile>ftp 192.168.19.175 Connected to 192.168.19.175. 220 Connected to FTPD User (192.168.19.175:(none)): root 331 Password required for root. Password: 230 User root logged in. ftp> cd d:\ap\binfile 250 CWD command successful. ftp> Local directory now C:\5260JSP\binfile. ftp> 200 Type is set to I. ftp>...
- Page 8 226 [Bytes: 1479275][Time: 1.95 s][Speed: 730.84 K/s] ftp: 6150161 bytes sent in 8.19Seconds 751.12Kbytes/sec. ftp> Setp7. Reboot Wellgate 5260 and Check Service Status After Reboot Wellgate 5260, You can see the Application: Version: 6.3.0...
- Page 9 Wellgate 5260 V6.3.0 JSP Downgrade to V6.3 ASP Procedure You need to have the backup files from V6.3.0 JSP Upgrade Procedure Step 2. Otherwise, you cannot do the downgrade procedure. Step 1: Reload the backup OS image. Microsoft Windows XP [Version 5.1.2600] (C) Copyright 1985-2001 Microsoft Corp.
- Page 10 drwxrwxrwx 1 owner group 0 Feb 25 14:57 TempFolder -rw-rw-rw- 1 owner group 165303190 Feb 25 16:55 wgos.sdi 226 [Bytes: 197][Time: 0.01 s][Speed: 19.24 K/s] ftp: 197 bytes received in 0.00Seconds 197000.00Kbytes/sec. ftp> Step 2: Restore the backup firmware and configuration Microsoft Windows XP [Version 5.1.2600] (C) Copyright 1985-2001 Microsoft Corp.
- Page 11 ftp: 1251173 bytes sent in 2.08Seconds 602.10Kbytes/sec. 200 PORT command successful. 150 Opening BINARY mode data connection for tgbin.bin. 226 [Bytes: 4249896][Time: 6.28 s][Speed: 660.77 K/s] ftp: 4249896 bytes sent in 6.08Seconds 699.23Kbytes/sec. 200 PORT command successful. 150 Opening BINARY mode data connection for voxfile.bin. 226 [Bytes: 1540466][Time: 2.23 s][Speed: 673.09 K/s] ftp: 1540466 bytes sent in 2.20Seconds 699.26Kbytes/sec.
- Page 12 Setp4. Reboot Wellgate 5260 and Check Service Status After Reboot Wellgate 5260, You can see the Application Version: 6.3.0...
