  • Page 1 100 Series™ Installation and User’s Manual April 2012 Edition - Version 5.1...

  • Page 2: Table Of Contents

    Contents Introduction ........................3 Customer Service........................ 4 Terms and Conditions ......................5 Before you Begin ........................ 6 Temperature Control ....................6 Deadbands ....................... 7 Setpoints ........................7 Ramping ........................7 Control Strategy........................9 Setpoint and Staging Worksheets ................9 Hardware Installation ....................... 10 Content Inspection ....................10 Recommended Tools ....................10 Mounting the iGrow Series 100™ ................10 iGrow Series 100™ Overview .
  • Page 3 System Setup ........................40 Equipment Setup ....................41 General Type ....................44 Energy Type ....................50 Assign Stages ....................55 Temperature Stages..................56 Humidity Stages ..................58 Reset Runtime ..................... 60 Save & Restore ....................... 61 Save & Restore Configurations ..............62 Save Log Files ....................64 Sensor Setup ......................66 Map Sensors ....................67 Calibrate Sensors ..................68 Self Test Set Up .

  • Page 4: Introduction

    Introduction Welcome to iGrow Series 100™, Link4’s Intelligent Greenhouse Environmental Controller. The iGrow Series 100™ represents the latest in greenhouse environmental control auto- mation. iGrow Series 100™ enables you to control and integrate a variety of equipment in your greenhouse. Your heating, cooling, venting, shading, humidity, CO2, and lighting needs are linked together into one flexible, easy-to-use system. Link4 can offer reliable service because we are staffed by the designer and engineers that developed the iGrow Series 100™. In designing the iGrow Series 100™ it was our purpose to design a controller specifically for the demands and cost concerns for small to mid size growers and no other controller has a better feature to price ratio than iGrow Series 100™. Your greenhouse control system should improve the quality and efficiency of your opera- tion. iGrow Series 100™ offers quick installation, and dynamic programming flexibility for easier and more accurate greenhouse management giving you the freedom for you to focus on plants and profits. The reason why we stand out from others is because of our Link4 Promise: Our passion is to provide growers with intelligent control solutions. We understand controlling your growing environment is critical to your success. Therefore, our commitment is to build outstanding controllers and to provide excellent support so that you can know with confi- dence that the iGrow Series 100™ system is right for you. iGrow Series 100 Manual...

  • Page 5: Customer Service

    Customer Service Link4 has a well-trained customer support staff that is ready to help. Our customer service center is committed to your greenhouse business 24/7 through our web site or service line for access to solutions for your controller needs. Before you contact us, please write down the model number and serial number located inside the iGrow Series 100™ enclosure so that we can serve you better. Address: Link4 Corporation 22725 La Palma Ave Yorba Linda, CA 92887 Telephone: SUPPORT 866.755.LINK (5465) Web: www.link4corp.com E-mail: SALES sales@link4corp.com SERVICE support@link4corp.com There is extensive online support for all Link4 products for registered users at www.link4corp.com. Registration is provided at no charge. iGrow Series 100 Manual...

  • Page 6: Terms And Conditions

    Moreover, any description of the goods contained in this contract is for the sole purpose of identify- ing them, is not part of the basis of the bargain, and does not constitute a warranty that the goods will conform to that description. The use of any sample or model in connection with this contract is for illustrative purposes only, is not part of the basis of the bargain, and is not to be construed as a warranty that the goods will conform to the sample or model. No affirmation of fact or promise made by Link4, whether or not in this contract, will constitute a warranty that the goods will conform to the affirmation or promise. Link4 shall not be responsible for replacement(s) or repair(s) which become defective from user neg- ligence, modification, abuse and/or any types of improper usage. Nonconformance to any of the specifications in the product manual will void the warranty. Furthermore, our liability to the goods sold, whether on warranty, contract, or negligence, will be released upon the expiration of the war- ranty period when all such liability shall terminate. Link4 shall not be responsible for any loss or claims due to consequential damages afford by the Buyer. Link4 also reserves the right to make any necessary changes to features and specifications to condition or warranty. Returns Merchandise cannot be returned without a Return Merchandise Authorization (RMA) number from Link4. Requests for permission to return defective items must be made within (14) fourteen days after receipt of shipment. A Link4 RMA # for approved returns must appear on both the customer’s shipping carton and the related receipt memo. Parts under warranty will be repaired at no charge. Other returned items will be subjected to the following restocking charges: 20% for no value added items, 40% for value added items, and 75% for custom designed or built to specification items. Repair A repair order must also have a Link4 Return Merchandise Authorization (RMA) number. Repairs that are not covered by the warranty will be billed on a material and labor basis. Items returned for repair...

  • Page 7: Before You Begin

    Before you Begin Temperature Control With the iGrow Series 100™ you can program a cooling temperature target called a “Cool Setpoint” and a heating temperature target called a “Heat Setpoint”. The temperature range between these two targets is called the “Normal” temperature range or stage. If the greenhouse temperature is within the Normal temperature band usually none of the cooling or heating equipment is on. However, some circulation fans (often called horizon- tal air flow (HAF) fans) may be active to maintain air movement within the greenhouse environment. Whenever the temperature within the greenhouse moves above the cool setpoint, or below the heat setpoint (falls outside the Normal temperature range) the iGrow Series 100™ will enter cooling or heating stages to bring it back in line. With the iGrow Series 100™ you can program up to six cooling and two heating stages. These stages go from Cool 1 to Cool 6 and Heat 1 to Heat 2. Cool 1 and Heat 1 are the least aggressive with Cool 6 and Heat 2 the most aggressive. In your program you will determine what equipment you want to be active in each of the stages. When the air temperature in the greenhouse rises above the Cool Setpoint, the system enters the first stage of cooling, referred to as Cool 1. If the temperature continues to rise, the system will enter the second stage, Cool 2, then the third stage, Cool 3 and so forth. At each increasing cooling stage, more cooling will be brought to attempt to bring the air temperature below the cool setpoint and within the target “Normal” temperature range. Heating works the same way. In considering the difference between each heating and cooling stage there is a variable in the program which is the number of degrees between each heating and cooling stage called the “Stage Separation” or ‘Stage Width”. Whenever the temperature rises above the cool setpoint, the iGrow Series 100™ will activate the appropriate equipment to bring the greenhouse to the normal temperature range. If the stage width is 1 degree and the temperature rises 1.1 degrees above the cool setpoint, then the controller will be active in C2 cooling stage. The same goes for the heating stage when the temperature drops below...

  • Page 8: Deadbands

    Deadbands If the temperature is below the cool setpoint and rises into the first stage of cooling, some cooling equipment will be turned on. This may then lower the temperature and bring it into the normal range. In order to keep the equipment from oscillating, a “Deadband” is employed when the temperature is between stages. In Figure 1.1 the dead band is set at 1 degree so that when the greenhouse is attempting to return to Normal temperature from C4 to C3 the controller will use a deadband of 1 degree to keep the equipment from oscillating off and on. Now, when the temperature drops below the cool setpoint, the system remains in the Cool 1 stage until the temperature drops below the Cool Deadband. The concepts that we described for cooling operate in the same manner for heating. Setpoints You will be able to use up to 3 setpoints in a 24 hour time period. Within each twenty- four hour period Setpoints are based on time and temperature to produce the deisred environment. By placing setpoints during different times of the day you can regulate the temperature within a range for target temperatures and humidity (humidity sensor sold seperately). When a setpoint is in effect at a certain time length the controller will acti- vate the necessary equipment in heating and cool stages to bring the environment back to Norm. The same applies when the humidity rises or falls beyond the target low/high setpoint. When one or more setpoints are used the second or subsequent setpoints will become the active setpoint at the start time and the previous setpoint will end. Ramping In addition, you have the option of a temperature ramp between the setpoints. Each set- point time period begins with a Ramp time. The benefit of ramping allows you to make smooth transitions within the greenhouse so that the plants don’t experience tempera- ture shock. Ramping also saves energy, which translates directly into lower operating costs. In the example on the following page (Figure 1.1), the start time is 8:00am with a 60 min- ute ramp time. The ramp time enables a smooth transition of the target temperatures between the setpoint time periods. Of course, the ramp times can be set to 0 and in this case there will be an immediate step transition in the set points. Figure 1.1 also shows a...
  • Page 9 RAMP SET POINTS START TIME TEMPERATURE TIME HUMIDITY Low Set Pt. High Set Pt. Low Set Pt. High Set Pt. (°F/°C) (°F/°C) (min) 6:00 AM NIGHT 7:00 PM NOT USED SAMPLE WORKSHEET FOR ON/OFF & VENT ONLY EQUIPMENT HEAT OUTPUTS NAME STAGES COOLING STAGES...

  • Page 10: Control Strategy

    Control Strategy Prior to installing and programming the iGrow Series 100™ it is important to determine an overall strategy to control the environment in the greenhouse. The iGrow Series 100™ is an extremely flexible and powerful device, thus additional care and planning are required. In order to aid you with the process, Link4 has provided several worksheets in the follow- ing pages. It is assumed that you already possess a general understanding of greenhouse controls. If not, please review this section carefully. It is recommended that you make copies of these sheets before using them. They will be useful in the future should your control needs change. Setpoint and Staging Worksheets RAMP SET POINTS START TIME TEMPERATURE TIME HUMIDITY Low Set Pt. High Set Pt. Low Set Pt. High Set Pt. (°F/°C) (°F/°C) (min) NIGHT FOR ON/OFF & VENT ONLY...

  • Page 11: Hardware Installation

    Hardware Installation Content Inspection The package should come complete with an iGrow Series 100™ unit, a 12 VDC power sup- ply, a temperature sensor probe with 50’ of cable attached, and 4 – Self Drilling Screws. Upon arrival, check the contents with the packing list for damaged or missing components (If you have the Integrated iGrow 100 Series Model, simply mount the panel using the mounting feet provided). Additional accessories such as digital temperature/humidity sensor, outside temperature sensor, light sensor, wind and rain sensors can be purchased and added at any time. Make sure you have all items, all associated hardware, and necessary tools before you begin installation. If there is any visible damage or missing parts, please contact our cus- tomer service at support@link4corp.com or 1-866-755-LINK or fax us at 714.558.9782. 1. iGrow Series 100™ unit 2. 12 VDC external Power Supply 3. Temperature probe with 50ft. cable 4. 4 pcs – Philips Head Self Drilling Screws 5. 4 pcs – 3/8” Drive, Hex Head Self Drilling Screws (integrated option only) Recommended Tools 1. Drill 2. 1/8” high speed steel drill bit 3. Phillips head screwdriver 4. Level (optional) 5. Pencil Mounting the iGrow Series 100™ 1. First, find a secure location to mount the iGrow Series 100™ controller. The area should be away from direct sunlight, condensing humidity, water, rain, or extreme temperatures. It should be mounted in an easily accessible location at the user’s...
  • Page 12 3. The iGrow Series 100™ comes with a 12V DC wall mount power supply. Make sure there is a power outlet within approximately 6 feet. It is recommended that the outlet is not switched and is on a circuit that is independent of any noisy, high power equipment. The use of a sealed outlet is recommended if the power output is ex- posed to moisture. 4. Identify what type of surface you will be mounting the iGrow Series 100™ to. In- cluded are 4 self-drilling screws for mounting to beam or wood panel. 5. There are 4 mounting points on the inside of the iGrow Series 100. Using the appro- priate tools depending on your surface, mount the iGrow Series 100™. Refer to the figure below (2.1) for a visual picture.

  • Page 13: Igrow Series 100™ Overview

    iGrow Series 100™ Overview Now that the iGrow Series 100™ has been mounted, take some time to look over the front panel. The iGrow Series 100™ has many features to help give you the growing advantage. Figure 2.2 below gives an overview of the main components that the iGrow Series 100™ has to offer. Figure 2.2 Front View of iGrow Series 100™ Opening the iGrow Series 100™ Open the hinged door by simultaneously depressing on the two side ejector buttons with your thumbs, while using your middle and index fingers for support. Figure 2.3 Proper finger positions for door opening iGrow Series 100 Manual...

  • Page 14: Internal Layout

    Internal Layout Figure 2.4 shows how the iGrow Series 100™ looks on the inside. Take notice of the board and familiarize yourself with the internal layout before beginning the wiring process. Figure 2.4 Internal Layout of the iGrow Series 100™ PCB iGrow Series 100 Manual...

  • Page 15: Wiring The Igrow Series 100

    Wiring the iGrow Series 100™ Warning: Do Not Plug-in the Power while wiring the iGrow Series 100™ and keep the manual override switches in the OFF position. It is recommended that all connections be made through liquid tight connectors at the bottom of the iGrow Series 100™. These glands compress around the cables to form a watertight seal. Making any additional holes in the top, sides, or back of the enclosure can result in water condensation inside the unit, causing damage to the controller. Failure to install to Link4’s specification will void the warranty. In preparation for the control wiring you should decide the iGrow Series 100™ output as- signments and control strategy. For more information on output assignment and control strategies, please refer to the Control Strategy section and the appropriate worksheets for this manual. Power Supply Installation 1. If you want to navigate through the iGrow Series 100™ to see some of the features and to familiarize yourself with how it works, begin by installing the power supply.

  • Page 16: Output Installation

    8. Now, if needed, you can plug in the power to navigate through the iGrow Series 100™. If you continue to install different outputs or inputs remember to keep the power supply unplugged. Figure 3.1 Wiring the Power Supply Output Installation The general installation strategy for this section is to install the output equipment in the greenhouse first and then the inputs to keep the cables organized in the iGrow Series 100™. It is assumed that at this point you have already planned the channel assignment.

  • Page 17: Control Relays & Contactors

    Control Relays & Contactors Your iGrow Series 100™ has 4 or 8 output relays that are provided as dry contacts, i.e. switch closures. If an output is activated to ON, the switch is “closed” (shorted); and if it is activated to OFF, the switch is “open” (no continuity between the positive and negative terminals). The board mounted relays are intended as “pilot” relays. For most loads you will want the iGrow Series 100™ outputs to control a load relay or contactor that is connected to the motor. However, in some cases such as irrigation valves that are 24 VAC, you can drive them directly assuming that you are wiring only one or two valves per relay. The maxi- mum run current recommended for each of the iGrow Series 100 relays is 1 amp. “Dry” Contact Design “Dry” contact installation design is used when a user wants to isolate equipment and use transformers for every piece of equipment. Figure 3.2 Output Wiring Example iGrow Series 100 Manual...

  • Page 18: Indoor Air Temperature Probe Installation

    The iGrow Series 100™ is shipped with a standard temperature probe. This sensor in- cludes 50-feet of sensor cable. Normally you will want to hang the sensor near the crop level close to the center of the controlled environment. It is important to keep the sensor away from irrigation emitters, unit heaters, etc. that will effect the accuracy of the sensor. 1. First, open up the front door, as shown in Figure 2.3. 2. Find a central location in the greenhouse and let it hang relatively close to the height of where the plants will be. 3. Run the free end of the sensor cable to the controller unit. 4. You may extend the sensor cable as needed, but make sure to use an adapter and wire approved by Link4 to make any extensions (the wire and adapter can be pur- chased from Link4). It should be noted that the controller is calibrated for a 50 ft. temperature probe. If additional wires are added or removed, software calibration will be necessary to ensure proper temperature measurement accuracy. 5. Carefully insert the cable through the right most watertight fitting at the bottom of the enclosure. It is easy to strip insulation and/or break wires when pulling cable. If you want to bundle wires tighter, use UV protected “tie wraps” (typically blue or black), and do not over-tighten. Note: If any splices are needed to extend cable length, make certain they are WATERTIGHT. Water or fertilizer infiltration WILL cause unstable sensor readings.
  • Page 19 Figure 3.3 Wiring iGrow 100 Series Sensors   iGrow Series 100 Manual...

  • Page 20: Programming

    Programming Before You Begin Before the iGrow Series 100™ is programmed, it is recommended that the following steps are followed: • Hardware is properly installed and tested with manual switches. • All internal switches have been restored back to the OFF state. • All the templates from the Control Strategy chapter that are relevant to your applica- tion are understood and are completely filled out. iGrow Series 100™ Main Screen Layout (Note: The ROI screen would only appear at this level once the energy information has been programmed.) HOME/BACK MENU iGrow Series 100 Manual...

  • Page 21: Navigation

    Navigation The iGrow Series 100™ has a unique touch sensitive navigation design that utilizes a touch wheel and 4 navigational touch sensitive “buttons” ( HOME, CANCEL, OK, BACK). On menu type screens, the wheel is used to rotate the selected choices. The wheel is used as a scroll to select different options It can be used to increase or decrease numeric values Note that the center of the wheel is not a button. Pressing HOME will bring the unit back to the Main screen. If data saving might be required, user will be prompted for input. Pressing CANCEL in the middle on an entry will bring the user back up a level, without making any changes. User can select any option by pressing OK. Pressing OK will prompt the system to accept the most recent data entry. BACK will bring the user back up one level. User will be prompted to save data, if needed. There are also eight “soft buttons” surrounding the display. Their behaviors are contex- tual and will be described by the notations displayed either below or above the buttons. Note that the display area itself is not touch sensitive. iGrow Series 100 Manual...

  • Page 22: Status Screens

    Status Screens Main Status Screens The main status screen displays the current status of your greenhouse zone. The numbers shown are only sample numbers and will differ for each user, but a description for each display will be explained. • Normal – This is the current temperature stage. It can go from Cool 6, to Normal, to Heat 2. • Day Setpoint – This is the current setpoint for heating, cooling.or normal. For ex- ample, if the device is in cool stage, it will show the cool setpoint. In the similar way it would show the heat setpoint. For the Normal stage both the heat and cool setpoints are shown. • The large 73.2F displayed is the current indoor temperature reading from the indoor temperature sensor. • Humidity – This is the current relative humidity reading in the zone. Note that this reading is only valid if the optional digital temperature/humidity probe is installed. For each of the outputs, the equipment’s name is displayed, as well as the current con- trolled state that it is in: • AUTO – equipment is being automatically controlled by the iGrow controller • OFF – equipment is being manually FORCED to OFF through software.

  • Page 23: Programming Screens

    or below the channel. The controller also has manual mechanical override switches inside the unit. These switches need to be in the AUTO position. If they are used to force the output OFF or ON, they will override all software settings. Programming Screens Once the user scrolls on the wheel or presses OK button, the following four choices will be displayed: •...

  • Page 24: Setpoint Programming

    Setpoint Programming Setpoint programming allows the user to program three different set- points for temperature and humid- ity. The Setpoints Menu can be entered by highlighting the Setpoints option on Main Menu using the Wheel or Button #1 and pressing OK. Setpoint programming is divided be- tween temperature and humidity. User can highlight the Setpoint sub- menu using wheel. User can select the option by press- ing OK There are three options in tempera- ture and humidity setpoints • DAY •NIGHT • DIF DAY is active by default. NIGHT and DIF can be turned on if desired. To select Day, Wheel or Button #1 can be used to highlight Day option (Similarly use Button 2, 3 for night and DIF option) iGrow Series 100 Manual...
  • Page 25 This brings you to the Basic setpoint menu system. Pressing Button #6 allows the user to modify the Heat setpoint. User can change the temp using wheel. Similarly user can change the cool setpoint by pressing on Button The Heat Setpoint is the low temper- ature target below which the heat stages are engaged and the Cool Setpoint is the high temperature target above which the cooling stages are invoked. Pressing Set Time (Button #7)and then Set DAY Start Time (Button #2) will allow the start time for the Day Time Setpoint to be set. The menu wheel can be used to in- crease or decrease each highlighted value Note that there is only one start time indicated, since the night and DIF...
  • Page 26 Button #8 toggles between Basic and Advanced setpoint menus. Ramp (in minutes) enables a gradual temperature transition from one setpoint to the next. Button #6 can be used to go to Ramp option Deadband creates a hysteresis in switch temperature which prevents the adjacent stages to oscillate back and forth from small temperature fluctuations. Button #7 can be used to go to Deadband. Wheel can be used to increase or decrease the corresponding value. Press the Back button to navigate back to the Temp Setpoints screen and set the NIGHT setpoint.
  • Page 27 Pressing Set Time will allow the user to set the start time for the Night Setpoint. Note that both Day and Night Times are being displayed now. In the same manner, the DIF set- point can be selected and modified. Other than the ability to switch the NIGHT and DIF Setpoints on and off, they behave similarly to the DAY Set- point. Corresponding Diagram shows when day, night and DIF options are acti- vated.
  • Page 28 This is an optional feature requiring a humidity sensor. The same process can be used to modify the humidity setpoints. Note that the start and end times are the same for Temperature Set- points and Humidity Setpoints. There are two parameters for each humidity setpoint: Humidify - if the RH reading is below this parameter, the condition is con- sidered too dry, and the system will go into the humidification stage.

  • Page 29: Reports / Logs

    Reports The second main section of the iGrow Series 100™ controller is the Reports section. This section pro- vides a brief overview of the options available. This section gives the reports and graphs of energy and equipment us- age as well as operational costs. User can go to reports submenu by pressing OK There are 7 subsections under Re- ports: 1. Return on Investment 2. Graphing 3. Equipment Costs 4. Energy Costs...

  • Page 30: Return On Investment

    Return on Investment This section allows the user to re- view the return on investment. Buttton #1 can be used to access this option. iGrow Series 100 Manual...

  • Page 31: Graphing

    Graphing This section allows the user to view graphs for different vairables against time. Pressing Button #2 from Repots sub- menu will take the user to graphing submenu. The graphs for the following time pe- riods can be seen: • Temperature • Humidity • Light • Stages • Wind • Rain • Relay Outputs • Equipment Status To highlight the sub options Wheel or Buttons #1 - #8 can be used to go to the corresponding options. Pressing OK will let user select the options Temperature In the temerature option user can view graphs for the following •...
  • Page 32 User can view the graphs for the foll- wing time periods • Since Reset • Last Hour • Last 24 hour • Last week • Last 7 days To highlight the sub options Wheel or Buttons #1 - #5 can be used to go to the corresponding options. Pressing OK will let user can view the graphs. Humidity In the humdity option user can view graphs for the following • Inside Humidity • Outside Humidity •...
  • Page 33 Stages In the stages option user can view graphs for the following • Temperature Stage • Humidity Stage To highlight the sub options Wheel or Buttons #1,#2 can be used to go to the corresponding options. Press- ing OK will let user select the options. Similar to temperature option user can view graphs for different time periods. Wind In the wind option user can view graphs for the following • Wind Speed • Wind Direction To highlight the sub options Wheel or Buttons #1, #2 can be used to go to the corresponding options. Press- ing OK will let user select the options. Similar to temperature option user can view graphs...

  • Page 34: Relay Outputs

    Relay Outputs In the relay option user can view graphs for Relay 1 output to Relay 8 output. To highlight the sub options Wheel or Buttons #1 - #8 can be used to go to the corresponding options. Press- ing OK will let user select the op- tions. Similar to temperature option user can view graphs for different time periods. Equiptment Status In the equipment status option user can view graphs for Channel 1 to Channel 8.

  • Page 35: Equipment Costs

    Equipment Costs This section allows the user to re- view the operational cost of the cli- mate zone broken down by equip- ment, expressed in percentages. The equipment cost for the following time periods can be seen: • Since Reset • Last Hour • Last 24 hour • Last week • Last 7 days • Last 30 days • This Month • This year To highlight the sub options Wheel or Buttons 1 - 8 can be used to go to the corresponding options. Pressing OK will let user select the options Use Button #1 and #4 to change the time frame for the equipment costs.

  • Page 36: Energy Costs

    Energy Costs Here the user can review the operational cost of the climate zone broken down by energy types expressed as percentages. The energy cost for the following time periods can be seen: • Since Reset • Last Hour • Last 24 hour • Last week • Last 7 days • Last 30 days • This Month • This year To highlight the sub options Wheel or Buttons #1 - #8 can be used to go to the corre- sponding options. Pressing OK will let user select the options Use Button #1 and #4 to change the time frame for the different energy types.

  • Page 37: Equipment Usage

    Equipment Usage This is where the user can review the various equipment runtimes When selecting the equipment us- age menu the channels/equipment are listed. Note that the names of the chan- nels/equipment will change when you label the equipment in the sub- sequent menus. After selecting a given channel/ equipment user can select time pe- riod to view the usage.

  • Page 38: Energy Usage

    Energy Usage In this section the user can check the usage of individual energy types. On selecting the energy usage screen the different energy options are presented to choose from. Note: By default all devices are of electrical energy type. The energy type for a device can be changed un- der the equipment setup. After selecting a given energy type user can select time period to view the usage.

  • Page 39: Event Logs

    Event Logs The event log options allows the user to view the history of various events which happened over a peri- od of time like stage changes, sensor error, relay status changes, etc. On selecting the event log the user is presented with the time periods to view the event logs over that dura- tion. The following time periods are avail- able • Since Reset • Last hour • Last 24 Hours • Last 7 days • Last 30 days •...
  • Page 40 On selecting a time period the events from that time onwards are shown. Column 1: Displays the timestamp at which the event occurred. Column 2: Describes the event. The screen allows the user to view either all the events or just the ex- ceptions (Button #1 toggles between General/Exceptions). The default view is the general view, showing all the events, including the exceptions. Note that the exceptions are high- lighted in general view. Details: elaborates the selected event.

  • Page 41: System Setup

    System Setup The System Setup is the third option in the main menu where the user can setup the equipment at instal- lation time, as well as other miscel- laneous operations. Pressing OK or Button #3 will let the user to go to system setup submenu The subsections under the system setup are : 1. Equipment Setup 2. Save/Restore 3. Sensor Setup 4. Time & Date Setup 5. Location Setup 6. Energy Cost 7. IP Address Setup 8. Measurement Units 9. Advanced...

  • Page 42: Equipment Setup

    Equipment Setup This section allows user to setup the equipment on the various channels, set their type, assign names, energy type, etc. Note: Equipment is programmed in- dividually. Note: All subsequent screens are ap- plicable to the selected equipment only. On selecting the equipment setup, the various Channels in which the equipment is connected can be se- lected.
  • Page 43 Timed override will switch ON or OFF the corresponding equipment during the specified time set by user. The timed override is provided for the user to set either a daily recur- ring event or a one time event. This can be done by pressing Button #7 The start time for the override can be set using this screen. Start time can be changed by press- ing Button #5. Buttons #1 - #4 are used to highlight time options.
  • Page 44 Before equipment can be utilized, the proper equipment type must be defined. User can go to Initial setting (press Button 3) to set the name and type of the corresponding channel. An optional, but useful, step is to as- sign a name to the equipment. This name will be displayed at the MAIN status screen. Button #3 can be used to go set name option. The figure below shows the screen to set up the name of the equipment. Back button is be used to delete the present name i.e., Channel 1. Then, user can enter the desired name. This screen is similar to the mobile phone SMS screen. To select a given alphabet press the required button the number of times = the position of the alphabet in the button. E.g. to type C press Button #1 three times.

  • Page 45: General Type

    General Type The general equipment types are: ON/OFF: Refers to any piece of equip- ment that turns on and off in each of the heating/cooling/dehum stages. For ex- ample, heater, fan, cool pad, pump, etc. VENT: Refers to a proportionally con- trolled ventilation equipment, e.g. side wall, ridge vent. CURTAIN: Refers to a shading system. ALARM: Use the alarm output to turn an output on depending upon crossing a temperature level. This is normally connected to a telephone dialer such as the Sensaphone. To highlight the sub options use Wheel or Buttons #1 - #4 corre- sponding to the options and OK to select the options By default all equipment are marked...
  • Page 46 On selecting a vent the user needs to do the set up of the following: • Open to Close time • Overrides To highlight the sub options use wheel or Buttons #1 and #2 and OK to select the options The Vent Open- Close Time is the time in minutes and seconds that it takes for the vent to go from full closed to full open position and vice versa.
  • Page 47 Navigating back to the Setup Over- rides menu, you get this screen. These overrides are important for safe and effective vent operations. To highlight the sub options Wheel or Buttons #1 - #3 can be used. Op- tions can be selected by pressing OK. Note: The weather station or some of its core components need to be installed to setup these overrides.
  • Page 48 Outside Temp Vent Override Set Vent Open Limit: This is the maximum position the vent can be open when the outside temperature is below the set temperature limit. Set Temp Limit: This is the user- specified temperature value which triggers the Vent Open Limit when temperature drops below set value. These values can be changed by selecting Buttons #1 and #2. Wheel can be used to mod- ify the value The curtains are also a dual channel device and can only be programmed...
  • Page 49 Shock Protection: Selecting a shock protection mode helps in opening the curtain slowly,preventing it to open all at once and thus preventing sudden temperature changes . Press Button #2 to go to night mode setup option. Then, press Button #6 to go to this option Note: Covered % is the amount by which the curtain should be covered. By pressing Button #7 user can to go to % covered option. Wheel can be used to increase or decrease the value The day mode and the night mode start time can be set to an absolute value using the screen as shown or to a the sunrise and sunset values.
  • Page 50 Toggle Alarm Type: There are two temperature alarm settings that can be programmed. One is a High temp alarm, the other is a Low Temp alarm. Pressing Button #1 enables you to toggle the programming screens be- tween the two options. After selecting low/high options, Button #2 will allow user to set tem- perature. Wheel is used to increase or decrease the values Wait Time: This Tab lets to set a wait time before the alarm is triggered. This time can be set from 0 to 99 minutes.

  • Page 51: Energy Type

    Energy Type Once the energy type is selected, the user will be prompted to enter the relevant information in order for the controller to accurately determine the energy consumption rate. It is advised to use accurate instru- ments (by trained personnels) to measure the consumption rate of the equipment, since this deter- mines the accuracy of the control- ler’s ability to determine cost.
  • Page 52 To enable a precise measured calcu- lation of the electrical consumption, select Measured and press OK. Note: A confirmation popup comes up indicating the change in setup as shown. The Voltage Phase, amperes(Amps) and the Power Factor(PF) values are entered by pressing Buttons #1 - #4 and using the Wheel to modify the values. Using the above values the kW value is calculated. To enable a rough/approximate cal- culation of the electrical consump- tion , the estimated setup is select- iGrow Series 100 Manual...
  • Page 53 The Voltage, HP/kW/Amps, Motor efficiency and operational load val- ues are entered by pressing Button (#1, #2, #3, #4) and using the Wheel to modify the values. Energy Type - Oil For setting the energy type as Oil the highlight is moved to the Oil type by pressing Button #2 or by using the wheel and pressing OK. The unit of measurement is BTUs/ The value of BTU/hr is entered by pressing the Button #1 and modify- ing the values by using the wheel.
  • Page 54 Energy Type - Gas For setting the energy type as Gas, the highlight is moved to the gas type by pressing Button #3 or by us- ing the Wheel and pressing OK. The unit of measurement is BTUs/ The value of BTU/hr is entered by pressing the Button #1 and modify- ing the values by using the Wheel. The default value is 1 BTU/hr. Energy Type - Water For setting the energy type as Water, the highlight is moved to Water type by pressing Button #4 or by using the Wheel and pressing OK.
  • Page 55 The unit of measurement is gallons per minute. The value of Gallon/min is entered by pressing the Button #1 and modi- fying the values by using the Wheel. The default value is 1Gallon/min. Energy Type - Other For setting the energy type as Other, the highlight is moved to the Other type by pressing Button #5 or by us- ing the Wheel and pressing OK. The unit of measurement is units per hour. The value of Units/hr is entered by pressing the Button #1 and modify- ing the values by using the Wheel. The default value is 1Unit/min.

  • Page 56: Assign Stages

    Assign Stages Assigning of stages can be done for a given channel through Assign Stage button at the Equipment Settings menu or directly through the Staging line on the main menu. The Stage settings can set for: • Temp Stages • Humidity stages Note: There are 8 temperature stag- es and 4 humidity stages. There are 2 heating (H1, H2) and 6 cooling (C1, C2, C3, C4, C5, C6) stages. The normal stage(N) is when neither heating nor cooling is required. C1 is the lowest stage of cooling and C6 the highest while H1 is the lowest heating stage and H2 is the highest. iGrow Series 100 Manual...

  • Page 57: Temperature Stages

    Temperature Stages “Channel” stages: This selection al- lows the user to set staging param- eters on the current channel they are under. “All Equipment” stages: This selec- tion provides a table with each piece of equipment in the left column and each stage of heating and cooling across the top. It gives a quick over- view of how all of the equipment fit on the staging table. When choosing to assign individual equipment to a temperature stage the following screen is shown.
  • Page 58 The user can quickly set the temper- ature staging options for every piece of equipment by selecting the “All equipment” stages option on the As- sign Stage menu. Enter this menu by highlighting it using the Wheel or Button #2 and pressing OK. The arrows are used for moving the highlight to the desired stage. The Setup and OK buttons are used to select or deselect the highlighted stage for a device.

  • Page 59: Humidity Stages

    Humidity Stages “Channel” stages: This selection al- lows the user to set staging param- eters on the current channel they are under. “All Equipment” stages: This selec- tion provides a table with each piece of equipment in the left column and each stage of heating and cooling across the top. It gives a quick over- view of how all of the equipment fit on the staging table. When choosing to assign individual equipment to a humidity stage the following screen is shown.
  • Page 60 The user can quickly set the humid- ity staging options for every piece of equipment by selecting the “All equipment” stages option on the As- sign Stage menu. Enter this menu by highlighting it using the Wheel or Button #2 and pressing OK. The arrows are used for moving the highlight to the desired stage. The Setup and OK buttons are used to select or deselect the highlighted stage for a device.

  • Page 61: Reset Runtime

    Reset Runtime The runtime counter for an equip- ment channel can be reset in the main Equipment Settings menu. This is useful when a user changes any equipment previously mapped to a channel. While in the main Equipment Set- tings menu, press Reset Runtime. The runtime values are used in ROI calculations and runtime accuracy is important for accurate cost calcula- tions.

  • Page 62: Save & Restore

    Save & Restore The controller’s settings as well as the log files can be saved either to onboard memory or a USB memory stick. Data can also be recalled from the files stored to the controller. On selecting the Save/Restore but- ton and pressing OK we get a menu to choose from. Save/Restore Config: Store and re- store the configuration file. Save Log Files: Save the log file to USB.

  • Page 63: Save & Restore Configurations

    Save & Restore Configurations This option lets you label and store your program in either the internal memory of the iGrow 100 Series controller or a USB drive (jump drive). You may have programs for different crops or for different seasons of the year. This will be a convenient way of storing your programs with the capability to restore the program whenever desired. Save Configuration: Allows the user to store the controller settings/configuration to on- board memory/USB. Restore Configuration: Allows the user to restore the configuration stored on the on- board system memory or USB. Delete Configuration: Allows the user to delete the configuration files stored n system memory/USB. Buttons 1, 2 or 3 are used to go to the corresponding options. Once the user has selected what ac- tion they would like to perform, the system prompts for a destination to perform the action to. Currently supported save/load de- vices include: •...
  • Page 64 If a given drive is not present /con- nected the system gives an error popup indicating the same. In case the drive is busy a popup indicating device is busy is displayed. Once a save/restore option is se- lected the user is prompted to enter the file name in the screen indicated below. This screen is similar to the mobile phone SMS screen. To select a given alphabet press the required button the number of times = the position of the alphabet in the button. E.g. to type C press Button #1 three times.

  • Page 65: Save Log Files

    Save Log Files To save the log file select the Save Log Files option by highlighting it us- ing the Wheel or by pressing Button #2 and press OK. Currently supported Save Log File options include: • Save History Log File • Save Event Log Files • USB Logging Setup Buttons #1, #2 or #3 are used to go to the corresponding options. On selecting the Save History Log Files a popup indicating the file for- mats pop-ups. Log files can be saved in either .xml or .csv file formats.
  • Page 66 After selecting the required format the user is promoted to choose the drive to store the file in. User can select an option by scrolling and pressing OK The system prompts the user to en- ter a file name. Note: The process of writing from system memory to USB can be time consuming. This screen is similar to the mobile phone SMS screen. To select a given alphabet press the required button the number of times = the position of the alphabet in the button. E.g. to type C press Button #1 three times.

  • Page 67: Sensor Setup

    Sensor Setup The Sensor Setup menu can be found under the System Setup menu. Scroll to the appropriate line using the Wheel or quickly navigate by pressing Button #3 and then OK. The Sensor Setup page is where the user can map the sensor that is used for inside temperature readings. Sensors can also be calibrated and averaged in this section. Map Sensors: This is where the user can set up the system according to the various sen- sors available. Calibrate Sensor: The sensors can be calibrated to adjust for offsets/software setup here. Self Test Setup: This is where the diagnostic mode test setup for digital sensor is done. Analog Sensor Averaging: This option allows the user to average the data from separate analog sensors. Buttons #1 - #4 are used to go to the corresponding options. iGrow Series 100 Manual...

  • Page 68: Map Sensors

    Map Sensors The mapping of the inputs to the different sensors is done here. The figure below shows the different inputs available for mapping. InTemp: Inside Temperature sensor In Hum: Inside Humidity sensor Light: Light sensor OutTemp: Outside temperature sensor Wind: Wind direction and speed sensor Rain: Rain sensor Back up Temp: Back up temperature sensor On selecting a given input you are presented with options to map that input to different sensors. You can also enable/disable that sensor. E.g. if are you are using an analog probe to measure the inside tem- perature then select analog for In- Temp. If you don’t have a particular sensor select None/Disabled for that...

  • Page 69: Calibrate Sensors

    Calibrate Sensors To calibrate an input the sensor is selected. The Previous and Next buttons are used to scroll through the different sensors. Raw Value: This is the direct reading from the sensor. CAL: This is the offset which will be added to raw value to generate the adjusted value(ADJ). The Wheel can be used to increase and decrease the values. ADJ: This is the value which will be reflected on the status screen. iGrow Series 100 Manual...

  • Page 70: Self Test Set Up

    Self Test Set Up This section enables the user to set up the test parameters for automat- ic testing of the digital temperature sensors. If a digital sensor is present and au- tomatic testing of that sensor is de- sired, map the sensor to one of the digital values in the Map Sensors screen. Note: This section only applies to mapped digital sensors. Enable/Disable Test: Sets the test to enabled or disabled. Button #1 is used to go to this option Self Test Time: The time interval be- tween planned sensor tests. Set Retest Time: The delay after which a test should repeat once a previous test has failed. Button #4 is used to go to this option.

  • Page 71: Analog Sensor Mapping

    Analog Sensor Mapping This section enables the user to average the data from separate analog sensors. This is useful in situations where the user needs to take temperature data from multiple locations in a zone and average them to form an accurate temperature reading for the entire zone. Use the Arrows and Wheel to navigate to a desired analog sensor and map it to be aver- aged using the Enable/Disable toggle or the OK button. iGrow Series 100 Manual...

  • Page 72: Time & Date Setup

    Time & Date Setup This section allows the user to change the time and date values on the 100 Series controller. Time and Date setup menu can be found under system setup menu Wheel or Button #4 can be used to go to highlight this option and OK to select this option. After selecting Time & Date Setup the user can choose to select either Set Time or Set Date from the menu. Highlight your choice by using the Wheel or Button #1, #2 and press OK to go to the highlighted selec- tion.

  • Page 73: Set Time

    Set Time The time on the system clock can be adjusted by highlighting a chosen field (Button #1, #2, #3) and using the Wheel to modify the field value. If a given field is already highlighted repressing that button causes the value in that field to be increased. 12H/24H: Used to set the time display as 24 hr/12 hr duration. Set Hour: Used to highlight the hour field. Set Min(X0): Used to highlight the tens place of minutes value. Set Min(0X) :Used to highlight the single place of minutes value. AM/PM: Used to set AM/PM value. Note that when the clock is set to 24H, the AM/PM button increments the time by 12 hours. iGrow Series 100 Manual...

  • Page 74: Set Date

    Set Date The date on Series 100 controller can be adjusted by highlighting a chosen field (Button #1, #2, #3) and using the Wheel to modify the field value. If a given field is already high- lighted repressing that button causes the value in that field to be increased. The date is displayed in MM/DD/YYYY format. Set Month: Used to highlight the month field. Set Day: Used to highlight the day field. Set Year: Used to highlight the year field. iGrow Series 100 Manual...

  • Page 75: Location Setup

    Location Setup Location setup allows the user to setup the latitude and longitude val- ues . The 100 Series controllers have an internal astronomical clock and can calculate the precise sunrise and sunset times once the location of the unit is entered. Location setup menu can be found under system setup menu Wheel or Button #5 can be used to go to highlight this option and OK to select this option EDIT LATITUDE: Allows the user to edit the latitude value. EDIT LONGITUDE: Allows the user to edit the longitude value. Valid Location SetUp: If set to False, indicates that the latitude and longi- tude values are incorrect and should be ignored. If set to true indicates...

  • Page 76: Energy Cost

    Energy Cost This is where the energy cost rates are entered for each of the energy/ water types. Energy Cost setup menu can be found under system setup menu Wheel or Button #6 can be used to go to highlight this option and OK to select this option To select a given energy type high- light it using the Wheel or Buttons #1 through #5 and press OK. The energy cost for Electricity is en- tered according to the seasons: •...
  • Page 77 Set Regular Rate / Set Peak Rate / Set Off Peak Rate: Takes you to the screen where you can set the time of start of the rate and its cost per unit during that period. Set Start Date: Takes you to a screen where you can set the starting date for a given season i.e. summer or winter. Buttons #1, #2, #3, #5 can be used to go to the above mentioned options. The figure shows the screen for rate setup and time set up for Regular Rate during summer. Button #1 can be used to select set rate option. After selecting set Rate the Wheel can be used to modify the rate vale. Button #5 can be used to select set start time option The figure shows the screen to set up the start time. Use Buttons #1 - #3 to highlight the field and use. Button #6 can be used to change AM/PM. Wheel to change the values in the highlighted field.
  • Page 78 For energy types other than Electric- ity the cost of the resource for each month can be set. The arrows are used to scroll through the selections and the Setup button. OK button can be used to set the values. This figure displays the popup win- dow which came up when SetUp ( Buttton #3)/OK button was pressed to modify the cost for month of Jan- uary. The Wheel is used to increase/de- crease the selected value. iGrow Series 100 Manual...

  • Page 79: Communication Setup

    Communication Setup The Communication Setup screen can be accessed by navigating ap- propriate line in the System Setup Menu. Communication setup menu can be found under system setup menu Wheel or Button #7 can be used to go to highlight this option and OK to select this option The Communication Setup Menu consists of Weather Station Setup and IP Address Setup. Weather Station Setup: Allows the user to indicate whether a weather station is directly connected to the unit or through a networked unit.

  • Page 80: Weather Station Setup

    Weather Station Setup The Weather Station Setup menu is used to configure the unit to work with a Link4 Weath- er Station. Pressing Weather Station Setup cycles through the three options. Connected Directly: The weather station is wired directly into this unit. Selecting this op- tion also enables the weather station data to be transmitted to other networked 100 Se- ries controllers. Connected via Another Unit: The weather station is wired into another 100 Series control- ler. That unit can share weather station data to this and any other unit that is networked to it. Not present / None of the above: There is no weather station data available. iGrow Series 100 Manual...

  • Page 81: Ip Address Setup

    IP Address Setup The IP Address setup is needed in case you need to access the unit using the web or a PC. IP Address: This is the address that you will enter when you try to access the unit using a PC. This address must be a nonconflicting IP address and can be obtained from the net- work administrator. Subnet Mask: This can be obtained from the PC used to access the unit or from your network administrator. Gateway Address: This can be obtained from the PC used to access the unit or from your network administrator. MAC Address: This is the MAC address of your unit. The MAC address is unique for each unit and cannot be edited. The Arrow Buttons are used to move the highlight. The EDIT Button( But- ton #4) is used to modify the high- lighted item.

  • Page 82: Measurement Units

    Measurement Units The units for temperature, wind speed, as well as light can be adjust- ed under the Measurement Units section of the System Setup. Scroll the Wheel to the desired menu and select OK. The units can be changed by press- ing the buttons for the correspond- ing measurement (Button #5, #6, #7). Pressing the buttons toggles the units.

  • Page 83: Advanced

    Advanced Advanced settings for the 100 Series controller can be configured under the Advanced section of the System Setup. Scroll the Wheel to the desired menu and select OK. Press the button for the correspond- ing selection (Button #1 - #8) to en- ter the desired menu. Humidity Settings: Used to set outside temperature override settings for humidity stages. ROI Settings: Used to set the initial values for Return on Investment calculations. ClearAll Data: Formats the data flash and deletes all the log files on the unit. Unit Info: Gives the general unit details. Stage Delay: Used to set the delay between stage changes. Begin Bootload: Used for firmware upgrade using bootloader. Password: Used to set up password. UI Test: Test the functionality of the touch sensitive user interface. iGrow Series 100 Manual...

  • Page 84: Humidity Settings

    Humidity Settings Override On Duration: The time for the override to remain active Override Off Duration: The time for override to remain inactive/off Buttons #1 - #4 can be used to select override on/off. Wheel can be used to change the values. LowOutTemp: If temperature falls below this value, override will trig- ger. Button 5 is used to select lowout temp option. Wheel can be used to change the values. The Humidity settings are used to setup the system in case the outside temperature is low. This screen will specify some important parameters for your humidity control. With this screen you have the option of cycling the humidification and dehumidification stages. For example, suppose the zone humidity exceeds the humidity threshold. Without the cycling option, your system will remain in the dehumidification stage until the humidity falls below the dehumidification threshold by at least 2% RH. In some cases it may be impossible to get below your humidity threshold. For these circumstances and for other cases, it would be helpful to cycle in and out of the humidity control override. This screen gives you the capability to do so. The options are: 1. Set the override ON duration in minutes and seconds 2. Set the override OFF duration in minutes and seconds 3. Set a low temperature threshold. The low temperature threshold is the outside temperature below which the dehumidifi- cation stage will revert to its Cold dehumidification state. For example, you may want to dehumidify but if it’s very cold outside, you may want to turn on the heat instead of open...

  • Page 85: Roi Settings

    ROI Settings Set Initial Amount: The initial cost of the unit is entered here . This value is used to calculate the Return on In- vestment values. Button #1 can be used to highlight the option. Wheel can be used to increase or decrease the value. Clear All Data Clear All Data: This function is used to format the system memory (data flash). Button #3 can be used to highlight the option. Wheel can be used to toggle be- tween options.

  • Page 86: Stage Delay

    Stage Delay Stage Delay: This time setting in sec- onds is the shortest time permitted for switching between temperature stages. A typical value here would be 60 to 120 seconds. This parameter is useful in minimizing the cycling of your equipment. Button #5 can be used to highlight timing option. Button #1 is used to highlight State Delay Option. The Wheel is used to adjust the time values. Bump Off Time Button #5 can be used to highlight timing option. Button #1 is used to highlight State Delay Option. The...

  • Page 87: Ui Test

    UI Test UI Test: This is a diagnostic mode used for testing if the buttons on the 100 Series controller are working correctly. Button #8 can be used to highlight the option. Wheel can be used to toggle between options. Pressing a given button highlights it on the screen. the Button #1 through #8 one after another.

  • Page 88: Stages/Staging

    Stages The last main section of the iGrow Series 100™ controller is the Stages section. This section provides quick access to the staging options found under the Equipment Setup menu. Note: There are 8 temperature stages and 4 humidity stages. There are two subsections under Staging: 1. Temp Stages 2. Humidity Stages PLEASE REFER TO “ASSIGN STAGES” UNDER EQUIPMENT SETUP FOR DE- TAILED INSTRUCTIONS ON HOW TO SET UP STAGING. (page 50) iGrow Series 100 Manual...

  • Page 89: Complete Menu Structure Listing

    Complete Menu Structure Listing Setpoints 1.1. Temp Setpoint 1.1.1. Set – DAY 1.1.1.1. SetHeat Setpoint The Heat Setpoint is the low temperature target below which the heat stages are en- gaged. 1.1.1.2. SetCool Setpoint The Cool Setpoint is the high temperature target above which the cooling stages are invoked. 1.1.1.3. Set Stage Separation The Stage Separation is the temperature spacing between the stages. For example, when the temperature in the zone goes above the cool setpoint, the system will go into Cool 1. If the temperature continues to rise and goes above the Cool Setpoint + the Stage Separation temperature, then the system will go into Cool 2, and so forth. 1.1.1.4. Set Time 1.1.1.4.1. Set DAY Start Time The Day Start Time is time when the Day Set Points are engaged. 1.1.1.4.1.1. Sun Based or Absolute (fixed) The Start Time is either an absolute/fixed time or varies astronomically based on the day length. For the sun based option, the start time will adjust each day from the date that the option is selected. The day length is an Astronomic adjustment based on the latitude and longitude entries that you made. 1.1.1.5. Advanced 1.1.1.5.1. Ramp Time The Ramp Time enables a smooth transition of the target temperatures between the iGrow Series 100 Manual...
  • Page 90 time periods. If the ramp time is set to 0, there will be an immediate step transition in the set points from the previous time window. If the ramp time is not 0, for example, if it is 30 minutes, then the setpoints will adjust gradually from one time period to the next over the 30 minute time span. 1.1.1.5.2. DeadBand This is sometimes called “hysteresis band”. For cooling, it is the number of degrees the temperature needs to drop from the lower boundary of its current stage before it switches to the lower stage. (Note: without deadbands, equipment tends to cycle fre- quently and constantly change stages when the temperature reaches the setpoint or a stage boundary). For heating, it is the number of degrees the temperature needs to rise above the temperature boundary before it switches to a lower heating stage. Typical values will be 1 to 2 degrees, Fahrenheit. 1.1.2. Set – NIGHT 1.1.2.1. On / Off By selecting the On option, you will be able to program separate setpoints and other parameters for your defined night time period. The Off option disables this second set of setpoint parameters. 1.1.2.2. SetHeat Setpoint Same description as for Day 1.1.2.3. SetCool Setpoint Same description as for Day 1.1.2.4. Set Stage Separation Same description as for Day 1.1.2.5. Set Time 1.1.2.5.1. Set NIGHT Start Time The Night Start Time is the time when the night setpoints are engaged. 1.1.2.5.1.1. Sun Based or Absolute Same description as for Day iGrow Series 100 Manual...
  • Page 91 1.1.2.6. Advanced 1.1.2.6.1. Ramp Same description as for Day 1.1.2.6.2. DeadBand Same description as for Day 1.1.3. Set – DIF DIF is short for Difference. This is a technique that some growers use to control the growth characteristics of certain plant types. The technique involves dropping the greenhouse temperature significantly an hour or two before sunrise. After sunrise, the temperature is raised gradually for an hour or so until the normal day time temperature target is achieved. 1.1.3.1. On / Off By selecting the On option, you will be able to program separate setpoints and other parameters for your defined DIF time period. The Off option disables this third set of setpoint parameters. 1.1.3.2. SetHeat Setpoint – Same description as for Day 1.1.3.3. SetCool Setpoint – Same description as for Day 1.1.3.4. Set Stage Separation – Same description as for Day 1.1.3.5. Set Time 1.1.3.5.1. Set DIF Start Time The DIF Start Time is the time when the DIF setpoints are engaged. 1.1.3.5.1.1. Sun Based or Absolute Same description as for Day 1.1.3.6. Advanced 1.1.3.6.1. Ramp – Same description as for Day 1.1.3.6.2. DeadBand – Same description as for Day iGrow Series 100 Manual...
  • Page 92 1.2. Humidity Setpoint 1.2.1. Set – DAY 1.2.1.1. Set Humidify Setpoint The Humidify Setpoint is the low humidity target below which the humidification stage is engaged. 1.2.1.2. Set Dehumidify Setpoint The Dehumidify Setpoint is the high humidity target above which the dehumidification stages are engaged. 1.2.1.3. Set Time 1.2.1.3.1. Set DAY Start Time This is the time that the Day Humidity Setpoints are invoked 1.2.1.3.1.1. Sun Based or Absolute The start time is either a fixed (absolute) time or it can vary daily based on the increase or decrease in day length. The day length is an Astronomic Adjustment based on the latitude and longitude entries that you made. 1.2.1.4. Advanced 1.2.1.4.1. Ramp Time The Ramp Time enables a smooth transition between the humidity targets. If the ramp time is set to 0, there will be an immediate step transition in the humidity setpoints from the previous to the current setpoint of the following period. If the ramp time is not zero, the ramping begins at the end of the period. 1.2.1.4.2. DeadBand For the dehumidification case, this is the humidity drop below the dehumidification boundary where the dehumidification stage terminates. For the humidification case this the humidity increase above the humidification bound- ary where the humidification stage terminates. 1.2.2. Set – NIGHT iGrow Series 100 Manual...
  • Page 93 1.2.2.1. On / Off The default for the night humidity setpoint is OFF. Pressing the tab will enable the set- ting of a night time humidity setpoint. 1.2.2.2. Set Humidify Setpoint Use the scroll to set the low (humidity) setpoint. You can also set it at 0. 1.2.2.3. Set Dehumidify Setpoint Pressing the second tab from the left on the bottom of the display will let you set the upper humidity setpoint. This is the de-humidification setpoint. 1.2.2.4. Set Time This is the time that the night setpoints are invoked. 1.2.2.4.1. Set NIGHT Start Time 1.2.2.4.1.1. Sun Based or Absolute The start time is either a fixed (absolute) time or it can vary daily based on the increase or decrease in day length. The day length is an Astronomic Adjustment based on the latitude and longitude entries that you made. 1.2.2.5. Advanced 1.2.2.5.1. Ramp The Ramp Time enables a smooth transition between the humidity targets. If the ramp time is set to 0, there will be an immediate step transition in the humidity setpoints from the previous to the current setpoint of the following period. If the ramp time is not zero, the ramping begins at the end of the period 1.2.2.5.2. DeadBand For the dehumidification case, this is the humidity drop below the dehumidification boundary where the dehumidification stage terminates. For the humidification case this the humidity increase above the humidification bound- ary where the humidification stage terminates. 1.2.3. Set – DIF iGrow Series 100 Manual...
  • Page 94 DIF is a third time window in a 24 hour period that you can elect to use to control the humidity separately from the other two periods. 1.2.3.1. On / Off The default for the DIF humidity setpoint is OFF. Pressing the tab will enable the setting of a DIF time period humidity setpoint. 1.2.3.2. Set Humidify Setpoint The Humidify Setpoint is the low humidity target below which the humidification stage is engaged during the DIF time period. 1.2.3.3. Set Dehumidify Setpoint The Dehumidify Setpoint is the high humidity target above which the dehumidification stages are engaged during the DIF time period. 1.2.3.4. Set Time 1.2.3.4.1. Set DIF Start Time 1.2.3.4.2. This is the time that the DIF setpoints are invoked. 1.2.3.4.2.1. Sun Based or Absolute The start time is either a fixed (absolute) time or it can vary daily based on the increase or decrease in day length. The day length is an Astronomic Adjustment based on the latitude and longitude entries that you made. 1.2.3.5. Advanced 1.2.3.5.1. Ramp The Ramp Time enables a smooth transition between the humidity targets. If the ramp time is set to 0, there will be an immediate step transition in the humidity setpoints from the previous to the current setpoint of the following period. If the ramp time is not zero, the ramping begins at the end of the period 1.2.3.5.2. DeadBand For the dehumidification case, this is the humidity drop below the dehumidification boundary where the dehumidification stage terminates. iGrow Series 100 Manual...
  • Page 95 For the humidification case this the humidity increase above the humidification bound- ary where the humidification stage terminates  Reports 2.1. Return on Investment 2.2. Equipment Costs 2.2.1. Since Reset 2.2.2. Last Hour 2.2.3. Last 24 Day 2.2.4. Last 7 Days 2.2.5. Last 30 Days 2.2.6. This Month 2.2.7. This Year 2.3. Energy Costs 2.3.1. Since Reset 2.3.2. Last Hour 2.3.3. Last 24 Day 2.3.4. Last 7 Days 2.3.5. Last 30 Days 2.3.6. This Month 2.3.7. This Year 2.4. Equipment Usage 2.4.1.
  • Page 96 2.4.3. Channel 3 2.4.3.1. Since Reset 2.4.3.2. Last Hour 2.4.3.3. Last 24 Day 2.4.3.4. Last 7 Days 2.4.3.5. Last 30 Days 2.4.3.6. This Month 2.4.3.7. This Year 2.4.4. Channel 4 2.4.4.1. Since Reset 2.4.4.2. Last Hour 2.4.4.3. Last 24 Day 2.4.4.4. Last 7 Days 2.4.4.5. Last 30 Days 2.4.4.6. This Month 2.4.4.7. This Year 2.4.5. Channel 5 2.4.5.1. Since Reset 2.4.5.2. Last Hour 2.4.5.3. Last 24 Day 2.4.5.4. Last 7 Days 2.4.5.5. Last 30 Days 2.4.5.6. This Month...
  • Page 97 2.4.8. Channel 8 2.4.8.1. Since Reset 2.4.8.2. Last Hour 2.4.8.3. Last 24 Day 2.4.8.4. Last 7 Days 2.4.8.5. Last 30 Days 2.4.8.6. This Month 2.4.8.7. This Year 2.5. Energy Usage 2.5.1. Electricity 2.5.1.1. Since Reset 2.5.1.2. Last Hour 2.5.1.3. Last 24 Day 2.5.1.4. Last 7 Days 2.5.1.5. Last 30 Days 2.5.1.6. This Month 2.5.1.7. This Year 2.5.2. 2.5.2.1. Since Reset 2.5.2.2. Last Hour 2.5.2.3. Last 24 Day 2.5.2.4. Last 7 Days 2.5.2.5. Last 30 Days...
  • Page 98 2.5.4.7. This Year 2.5.5. Other 2.5.5.1. Since Reset 2.5.5.2. Last Hour 2.5.5.3. Last 24 Day 2.5.5.4. Last 7 Days 2.5.5.5. Last 30 Days 2.5.5.6. This Month 2.5.5.7. This Year System Setup 3.1. Equipment Setup 3.1.1. Channel 1 3.1.1.1. Override This feature lets you manually override your greenhouse equipment for specified peri- ods of time, either once or daily. 3.1.1.1.1. Enable/Disable Enable lets the override operate. Disable disallows the override but maintains the other user entries. 3.1.1.1.2. Force ON/OFF You can select whether you want to force (override) the on/off equipment either On or Off and the proportional equipment such as vents and curtains to a particular position based on percentage open for a vent and percent covered for a curtain.. 3.1.1.1.3. Override Duration 3.1.1.1.3.1.
  • Page 99 If “Daily” is selected, the override will occur every day at the Start Time. If “One time” is selected, once the override is completed, it will not occur again without being reset to 3.1.1.2. Initial Settings This is where you go for the first time to define the type of equipment on each channel that you are using and to name the channel. 3.1.1.2.1. Set Type There are three types (classes) of equipment that you can program. One is On/Off and the other two are “proportional” or Vents and Curtains. 3.1.1.2.1.1. General Type Select this option when you want to setup the channel 3.1.1.2.1.1.1. On/Off On/Off equipment such as fans, louvers, heaters, etc., are sometimes referred to as digi- tal outputs. This equipment type occupies only one channel and can be programmed on any channel. 3.1.1.2.1.1.2. Vent A vent with a drive open and drive close relay requires two consecutive channels. The first must be an odd number and the second, its neighbor to the right, an even number. Acceptable pairs are 1&2, 3&4, 5&6 and 7&8. The odd numbered channel opens the vent, the even number closes the vent. A vent is a proportional device, sometimes referred to as a “timed analog output”. 3.1.1.2.1.1.2.1. Open to Close Time 3.1.1.2.1.1.2.1.1. Set Open Time The “Open Time” is the time in minutes and seconds that it takes for the vent to go from its full close position to full open position. 3.1.1.2.1.1.2.2. Setup Overrides This section assumes that you have outside sensors such as a rain sensor, wind speed and direction sensor and/or an outside temperature sensor. These are typically part of a weather station assembly but can be obtained separately. iGrow Series 100 Manual...
  • Page 100 3.1.1.2.1.1.2.2.1. Rain Set Vent Open Limit – this sets a limit on the maximum open position for the vent when the sensor detects rain. 3.1.1.2.1.1.2.2.2. Wind Set Vent Open Limit This is the maximum percent open for the vent when the wind speed exceeds the limit set next. The program calculates the average wind speed over the last 3 seconds. This is to eliminate responding to short wind gusts. Set Wind Speed Limit This is the wind speed at which the vent will be closed to the Vent Open Limit previously programmed. The wind override ends when the wind speed falls below the threshold for two minutes. 3.1.1.2.1.1.2.2.3. Outside Temp In the event that it is very cold outside you may want to limit the percentage opening of the vent regardless of the inside zone temperature. Set Vent Open Limit This is the maximum percent open for the vent when the outside temperature falls below the threshold set in the next entry. Set Temp Limit This is the outside temperature below which the vent will not exceed the maximum percent open assigned in the previous entry. 3.1.1.2.1.1.3. Curtain 3.1.1.2.1.1.3.1. Set Day Mode Light Threshold This option assumes that you have a light sensor either outside or above the curtain. The “Light Threshold” is the light level above which the curtain will be covered to the percentage specified in the next entry. 3.1.1.2.1.1.3.2. Set Day Mode Covered % This is the maximum position for closing the curtain during the day. This is particularly iGrow Series 100 Manual...
  • Page 101 important if you are dependent on the ridge vents for cooling. 3.1.1.2.1.1.3.3. Set Day Mode Start Time This is the starting time when the curtain will be subject to the light threshold. As long as the light level is below the light threshold the curtain will remain uncovered. 3.1.1.2.1.1.3.4. Set Day Mode End Time This is the ending time for the day mode of the curtain. 3.1.1.2.1.1.3.5. Set Open Delay time The purpose of this parameter is to the reduce the curtain movement. The light level must be below the “Light Threshold” for at least this many minutes before the curtain will open. 3.1.1.2.1.1.3.6. Enable Shock Protection Enabling Shock Protection forces the curtain to open slowly in the morning when the outside temperature is below a certain threshold. This is to avoid the in-rush of cold air that may be above the energy curtain. In the morning when the curtain is scheduled to open and if the outside temperature is below deg, the curtain will open in four steps. It will open 5% and then pause for 5 minutes. It will repeat this 4 times and then open to 0% without stopping. 3.1.1.2.1.1.3.7. Set Open-Close Time This is the time it takes for the curtain to go from its uncovered position 0% closed to its covered position, 100% closed. Enter the time in minutes and seconds. 3.1.1.2.1.1.4. Alarm Any one of the available 8 channels can be selected to be an alarm output. When an alarm condition is met, the digital output (relay) is closed. 3.1.1.2.1.1.4.1. Toggle Alarm Type There are two temperature alarm settings that can be programmed. One is a High temp alarm, the other is a Low Temp alarm. Pressing the top left Tab enables you to toggle the programming screens between the two options. 3.1.1.2.1.1.4.2. Set Temperature This Tab lets you select the temperature threshold above or below which the alarm will iGrow Series 100 Manual...
  • Page 102 be triggered. 3.1.1.2.1.1.4.3. Set Wait Time This Tab lets to set a wait time before the alarm is triggered. This time can be set from 0 to 99 minutes. The alarm condition must exist during the entire wait time for the alarm condition to be met. If the temperature drops below the threshold during the wait time, the clock will be reset to 0. 3.1.1.2.1.2. Energy Type 3.1.1.2.1.2.1. Electricity 3.1.1.2.1.2.1.1. Measured 3.1.1.2.1.2.1.1.1. Voltage 3.1.1.2.1.2.1.1.2. Phase 3.1.1.2.1.2.1.1.3. Amps 3.1.1.2.1.2.1.1.4. Power Factor 3.1.1.2.1.2.1.1.5. Status 3.1.1.2.1.2.1.2. Estimated 3.1.1.2.1.2.1.2.1. Voltage 3.1.1.2.1.2.1.2.2. HP / kW / Amps 3.1.1.2.1.2.1.2.3. Motor Efficiency 3.1.1.2.1.2.1.2.4. Operational Load 3.1.1.2.1.2.1.2.5. Status 3.1.1.2.1.2.2. 3.1.1.2.1.2.2.1. BTUs/h 3.1.1.2.1.2.2.2. Status 3.1.1.2.1.2.3.
  • Page 103 3.1.1.2.1.2.5.2. Status 3.1.1.2.2. Set Name You can program a custom name for each piece of equipment connected to the iGrow. The alphanumeric display lets you enter text much like you would on a cell phone. You have up to nine(9) positions that you can use. 3.1.1.3. Assign Stage Select either the temperature stages or the humidity stages. 3.1.1.3.1. Temp Stages 3.1.1.3.1.1. 1. “Channel ” stages This selection lets you program the particular channel that you’ve chosen. 3.1.1.3.1.2. 2. “All Equipment Stages” This selection gives you a table with each piece of equipment in the left column and each stage of heating and cooling across the top. It gives a quick overview of how you’ve programmed each piece of equipment. It also gives you the option of programming in a single location any or all of the equipment for temperature control. 3.1.1.3.2. Humidity Stages 3.1.1.3.2.1. 1.“Channel ” stages This selection lets you program the particular channel that you’ve chosen. 3.1.1.3.2.2. 2. “All Equipment Stages” This selection gives you a table with each piece of equipment in the left column and each humidity stage across the top. It gives a quick overview of how you’ve pro- grammed each piece of equipment. It also gives you the option of programming in a single location any or all of the equipment for humidity control. 3.1.1.3.2.2.1. Humidify When the zones humidity goes below the low humidity setpoint, this engages the hu- midity or humidification stage. Equipment programmed at the controller can be activated or de-activated, as desired, when this stage is triggered. Another option for each piece of equipment is N/A, which iGrow Series 100 Manual...
  • Page 104 means no particular action is taken with that equipment in the humidify stage. 3.1.1.3.2.2.2. De-Humidify When the zones humidity goes above the high humidity setpoint, this engages the dehu- midification stage. Equipment programmed at the controller can be activated or de-activated, as desired, when this stage is triggered. Another option for each piece of equipment is N/A, which means no particular action is taken with that equipment in the humidify stage. 3.1.1.3.2.2.3. De-Humidify (Cold) When the zones humidity goes above the high humidity setpoint and the outdoor tem- perature goes below xx deg, the “Cold De-humidification” stage is engaged. Equipment programmed at the controller can be activated or de-activated, as desired, when this stage is triggered. Another option for each piece of equipment is N/A, which means no particular action is taken with that equipment in this stage. 3.2. Save/Restore This option lets you label and store your program in either the internal memory of the iGrow, to a USB drive (jump drive), and/or an SD card. You may have programs for dif- ferent crops or for different seasons of the year. This will be a convenient way of storing your programs with the capability to restore the program whenever desired. 3.2.1. Save Configuration Pressing the Save Configuration key will bring up the save to option. Clearly, if you are going to save to a USB drive or an SD card you will need to have placed either of these devices inside your iGrow. After making you selection you will be given the option of labeling the file with up to nine alphanumeric. 3.2.2. Restore Configuration Pressing this key will bring up the “restore from..” option. You must select one of the three options from which to extract the file. The file you select will then replace the one you currently are using. 3.2.3. Delete Configuration Pressing this key will bring up the “delete from” option. You must select one of the op- tions from which to remove the file. The file will then be permanently deleted. 3.3. Sensor Setup iGrow Series 100 Manual...
  • Page 105 3.3.1. Map Sensors 3.3.2. Calibrate Sensors 3.3.3. Sef Test Set Up 3.3.4. Analog Sensor Averaging 3.4. Time & Date Setup 3.4.1. Set Time You can set the current time using the four tabs at the top of the screen. You also have the option of using a 24 hour clock by pressing the tab at the bottom of the screen. 3.4.2. Set Date You can set the date using the three tabs at the top of the screen. 3.5. Location Setup The iGrow 800 has an internal astronomical clock. By knowing the actual coordinates, sunrise and sunset times can be precisely calculated. Go to heavens-above to find coor- dinates for your precise location. If a negative longitude is given you are west, and if a negative latitude is given you are in the southern hemisphere. 3.5.1. Edit Latitude To edit, press the appropriate tab at the bottom of the screen. 3.5.2. Edit Longitude To edit, press the appropriate tab at the bottom of the screen. 3.6. Energy Cost 3.6.1. Electricity 3.6.2. 3.6.3. 3.6.4.
  • Page 106 3.7.2.1. IP Address 3.7.2.2. Subnet Mask 3.7.2.3. Gateway Address 3.7.2.4. MAC Address 3.8. Measurement Units 3.8.1. Temp Units The lower left hand tab on the Measure Units Setup screen is used to toggle between the Fahrenheit or Celsius units for temperature. Every temperature reading displayed will be based on the units you select. 3.8.2. Speed Units The second tab at the bottom of the screen is used to toggle between Mph (Miles per hour) and kmph (kilometers per hour). 3.8.3. Light Units The third tab from the bottom left is used to select between Watts/meter-squared and Kilolux (Klux) for light measurements. 3.9. Advanced 3.9.1. Unit Info This tab provides important information regarding your iGrow unit. It includes the model type, the version number and the serial number. 3.9.2. Humidity Settings This screen will specify some important parameters for your humidity control. With this screen you have the option of cycling the humidification and dehumidification stages. For example, suppose your zones humidity exceeds the humidity threshold. Without the cycling option, your system will remain in the dehumidification stage until the humid- ity falls below the dehumidification threshold by at least 2% RH. In some cases it may be impossible to get below your humidity threshold. For these circumstances and for other cases, it would be helpful to cycle in and out of the humidity control override. This screen gives you the capability to do so. The options are: 1. Set the override ON duration in minutes and seconds 2. Set the override OFF duration in minutes and seconds...
  • Page 107 3. Set a low temperature threshold. The low temperature threshold is the outside temperature below which the dehumidi- fication stage will revert to its Cold dehumidification state. For example, you may want to dehumidify but if it’s very cold outside, you may want to turn on the heat instead of open a vent and turning on a fan. This humidity settings option can be useful in other applications even if you do not have a humidity sensor. For example, you may want to do misting control with a particular output, You can set up a “software” humidity sensor, a humidity time window and threshold so that the cycling will take place during your selected time period. 3.9.3. Stage Delay This time setting in seconds is the shortest time permitted for switching between tem- perature stages. A typical value here would be 60 to 120 seconds. This parameter is useful in minimizing the cycling of your equipment. Stages 4.1. Temp Stages 4.1.1. “All Equipment Stages” This selection gives you a table with each piece of equipment in the left column and each stage of heating and cooling across the top. It gives a quick overview of how you’ve programmed each piece of equipment. It also gives you the option of programming in a single location any or all of the equipment for temperature control. 4.2. Humidity Stages 4.2.1. “All Equipment Stages” This selection gives you a table with each piece of equipment in the left column and each humidity stage across the top. It gives a quick overview of how you’ve pro- grammed each piece of equipment. It also gives you the option of programming in a single location any or all of the equipment for humidity control. 4.2.1.1. Humidify When the zones humidity goes below the low humidity setpoint, this engages the hu- midity or humidification stage. Equipment programmed at the controller can be activated or de-activated, as desired, iGrow Series 100 Manual...
  • Page 108 when this stage is triggered. Another option for each piece of equipment is N/A, which means no particular action is taken with that equipment in the humidify stage. 4.2.1.2. De-Humidify When the zones humidity goes above the high humidity setpoint, this engages the dehu- midification stage. Equipment programmed at the controller can be activated or de-activated, as desired, when this stage is triggered. Another option for each piece of equipment is N/A, which means no particular action is taken with that equipment in the humidify stage. 4.2.1.3. De-Humidify (Cold) When the zones humidity goes above the high humidity setpoint and the outdoor tem- perature goes below xx deg, the “Cold De-humidification” stage is engaged. Equipment programmed at the controller can be activated or de-activated, as desired, when this stage is triggered. Another option for each piece of equipment is N/A, which means no particular action is taken with that equipment in this stage. iGrow Series 100 Manual...
  • Page 109 Delivering Confidence Through Intelligent Environmental Controls and Automation Solutions 22725 La Palma Avenue, Yorba Linda, CA 92887 USA P: 866.755.5465 F: 714.854.7244 support@link4corp.com ● 960-1001-04 ● www.link4corp.com Copyright © 2012 Link4 Corporation. All Rights Reserved...

  • Page 110: Resetting The Controller

    Resetting the Controller Hard Reset- In the event that you need to perform a reset, open up the front door and locate the RED push button switch on the right hand side. Pressing this briefly will reset the controller. This is a safe operation and will not cause you to lose any programming or configurations. Factory Default Reset- if ever wanted, or is necessary, you can reset the iGrow Series 100TM to its factory default settings. To do this, unplug the controller, remove the bat- tery for 30 seconds, then reinsert the battery back into the holder. Apply power. After doing so, the controller will say “iGrow Series 100 Restoring Default Configurations………” It is suggested that you use a USB stick to save your configurations before making a fac- tory default reset. Then, you can use it to quickly restore all your settings. WARNING: This process will erase all of your programmed settings. This can not be undone. iGrow Series 100 Manual...
