AT-320 H323 Phone User Manual (V1.39)
● ppp pin: With pppoe or modem selected in iptype drop down list, please enter
the password here.
● local ip: With static ip selected in iptype drop down list, please enter IP address
of IP phone here.
● subnet mask: With static ip selected in iptype drop down list, please enter
subnet mask of IP phone here.
● router ip: With static ip selected in iptype drop down list, please enter router IP
address of IP phone here.
● dns: With static ip selected in iptype drop down list, please enter IP address of
DNS server here.
● dns 2: With static ip selected in iptype drop down list, please enter IP address of
backup DNS server here.
● mac: MAC address is the physical address supplied by the Ethernet NIC.
AT-320 phone is shipped from the factory with a unique algorism MAC
address printed on the back of the base.
Protocol Setting
Fig 3.3 Protocol Setting
