Page 1: Installation Instructions
® Roll-A-Door Series 1 Squareline Deluxe Doors INSTALLATION INSTRUCTIONS DISCLAIMER THESE INSTRUCTIONS ARE INTENDED FOR PROFESSIONAL GARAGE DOOR INSTALLERS Note: All references are taken from inside looking out Part No. 07488. Revision 3 May 2010... -
Page 2: Table Of Contents
Roll-A-Door ® Series 1 Installation Instructions CONTENTS BEFORE YOU START SAFETY CHECKLIST REQUIREMENTS BEFORE INSTALLATION FIXING REQUIREMENTS TOOLS CHECKLIST PARTS CHECKLIST INSTALLATION INSTALL FIRST BRACKET INSTALL SECOND BRACKET PLACE DOOR ON BRACKETS POSITION DOOR TENSION THE SPRINGS ATTACHING STOP GUIDES FITTING HANDLE CENTRE LIFT LOCK 2.10... -
Page 3: Requirements Before Installation
Roll-A-Door ® Series 1 Installation Instructions Hazard Control • Working at heights and working with ladders, scissor lifts, • Ladder check scaffold - risk of fall from height • Ladder placement • Do not work off the top rung • Wear appropriate PPE (Dyneema cut off Gloves) •... -
Page 4: Fixing Requirements
Roll-A-Door ® Series 1 Installation Instructions SIDEROOM - A minimum of 75mm (100mm desirable) of sideroom is required behind the opening and should extend above the head to allow for bracket fi xing. Sideroom on one side of 115mm is required if a B&D ®... -
Page 5: Installation
Roll-A-Door ® Series 1 Installation Instructions 2.0 INSTALLATION 2.1 INSTALL FIRST BRACKET a) Measure the door curtain width and mark where edge of the curtain will be, allowing for over lap on each side of the opening. 230mm Restricted or b) Add clearance of 10 to 75mm from edge of curtain to inside edge 250mm Normal Headroom of bracket to determine positioning of the bracket. -
Page 6: Place Door On Brackets
Roll-A-Door ® Series 1 Installation Instructions 2.3 PLACE DOOR ON BRACKETS a) Check the axle length and cut if sideroom is limited. Before cutting, make sure the fl oating axle is free and centred. Centre will be found by rotating the axle a quarter turn in either direction then releasing . With centre found, make a clear mark on the axle against the hub for later reference. -
Page 7: Tension The Springs
Roll-A-Door ® Series 1 Installation Instructions 2.5 TENSION THE SPRINGS FIRST PREPARE A SOFT WOOD CHOCK, ABOUT 400mm LONG. WOOD CHOCK THEN - Ensure that bottom rail is at the 3 o’clock position as shown in Step 4 - if not, refer to Step 2.4. a) Ensure both “U”... -
Page 8: Guides
Roll-A-Door ® Series 1 Installation Instructions 2.7 GUIDES a) Check that curtain overlaps equally on both sides. RESTRICTED HEADROOM 35mm b) Check that guides are the correct length, that is, level with the brackets (or in the restricted headroom position are 35mm maximum above bracket). -
Page 9: Centre Lift Lock
Roll-A-Door ® Series 1 Installation Instructions 2.9 CENTRE LIFT LOCK a) Raise the curtain until the lock corrugation is visible above LEG S the door guides. b) Install locking bar retainer in line with lock corrugation by pushing retainer towards door edge, sliding the legs under ®... -
Page 10: Final Adjustment
Roll-A-Door ® Series 1 Installation Instructions 2.10 FINAL ADJUSTMENT 1. If the door is hard to operate in ANY DIRECTION check that the door is not jamming in the guides. Check: a) the guide clearances; b) that guides are plumb; c) that the guide surfaces are clean and free from oil;... -
Page 11: Fixing Alternatives
Roll-A-Door ® Series 1 Installation Instructions 2.12 FIXING ALTERNATIVES 1. ALTERNATIVE GUIDE FITTING BRICK GARAGE TIMBER GARAGE a) Exact opening size: Door over laps 25mm each side. b) Door is too wide: The guides can be set back inside from the opening edge. -
Page 12: After Installation Care
Roll-A-Door ® Series 1 Installation Instructions 3.0 AFTER INSTALLATION CARE ® GENERAL CARE OF YOUR ROLL-A-DOOR REGULAR MAINTENANCE REQUIRED ® B&D recommends that you check the operation of your Roll-A-Door CLEANING at least every six months (more regularly in extreme environments or frequent use).
