Foot Well Removal / Installation; X2-Touring Foot Well Removal / Installation - Polaris 2008 sportsman 800efi Service Manual

Foot Well Removal / Installation

1. Remove the four plastic inserts (A) that secure the wheel
well to the front and rear cabs. (See "PLASTIC INSERT
REMOVAL / INSTALLATION" for help).
2. Remove the four screws (B) from the bottom of the foot
well. Remove the footwell.
18 in.lbs. (
A
3. Reverse the removal procedures to install the foot well. Be
sure to properly align the cab ends into the foot wells upon
reassembly.
A
B
BODY / STEERING / SUSPENSION

X2-Touring Foot Well Removal / Installation

1. Remove the four plastic inserts (A) that secure the wheel
well to the front and rear cabs. (See "PLASTIC INSERT
REMOVAL / INSTALLATION" for help).
2. Remove the six screws (B) from the bottom of the foot well.
Remove the footwell.
A
3. Reverse the removal procedures to install the foot well. Be
sure to properly align the cab ends into the foot wells upon
reassembly.
A
B
5.5
5
