7. DMX CHANNELS

CHANNEL
CH1
CH2
CH3
CH4
CH5

8. KEY FEATURES

- 24 x 3W Tri LEDs
- 7 Operation Modes
- 3 & 5 Pin XLR Input & Output
- Zoom Lens (10° to 60° beam angle)
- DMX Control
- Double Bracket for Truss and Floor Mounting
- Gel Frame Included
- Built-in microphone
- 4-Button LED Digital Display (MODE, SETUP, UP, DOWN)

9. TECHNICAL SPECIFICATIONS

MODEL: LED MAX ZOOM TRI
LAMP: 24 x 3W Tri LEDs
OPERATING TEMPERATURE: -25°C to 45°C
VOLTAGE: 120VAC 60Hz 80W
FUSE: 2A 250V GMA
MAX: 80W
DIMENSIONS: 10.63" x 11.81" x 8.66" / 270 x 300 x 220mm
PACKING DIMENSIONS: 15.8" x 12.2" x 10.8" / 401 x 310 x 274 mm
NET WEIGHT: 13.55 lbs / 6.1 kg
GROSS WEIGHT: 14.65 lbs / 6.6 kg
WARRANTY: 2 Year Limited Warranty
DMX VALUE
000-189
190-250
251-255
000-255
000-255
000-255
000-255
FUNCTION
DIMMER
FLASH (slow → quick)
NO FUNCTION
RED
GREEN
BLUE
Electric machine adjustment
0=start
255=terminal
