VBOX PROLITE User Guide
Connector
2 CAN Bus/RS232
PIN
In/Out
Description
1
O
RS232 Tx Serial Data Transmit
2
I
RS232 Rx Serial Data Receive
3
I/O
CAN Bus
4
I/O
CAN Bus
5
O
+V Power
Chassis
Ground
Antenna connector
Connector
ANT
PIN
In/Out
Description
Center
-
RF Signal / Power for active antenna
Chassis
-
Ground
Type
Lemo 5 pin
Range
±12v
±12v
Type
SMA
Range
Page 18 of 20
