ENHANCED VISION Merlin User Manual page 25

Programming Color Select Options
With Merlin turned on, place a piece of reading material on the base table so
that it appears on your monitor at a magnification size that is comfortable for
viewing. Follow these steps to program Color Select options:
Step 1) Press and hold the MODE button until the words "ENTERING SETUP"
appear on your monitor.
Step 2) Turn the Size dial clockwise to scroll through the various menu
options. If you just want to add a new Color Select viewing mode,
turn the dial until "COLOR SELECT 4" appears on your screen
(because color select 1 through 3 have already been programmed at
the factory). Press the PRESET button to select this option for
programming.
NOTE: To change the viewing modes pre-programmed at the factory, turn the
Size dial to "COLOR SELECT 1," "COLOR SELECT 2" or "COLOR SELECT 3"
and press the PRESET button to change the selected option.
Step 3) Turn the Size dial to display each of the available color combinations.
Step 4) To reverse the colors, such as from yellow text on a blue background
to blue text on a yellow background, press the MODE button.
Step 5) When you have chosen a color combination, press the PRESET button
to enter that choice into Merlin's memory. Your selection has now
been added to the viewing modes available in normal use. This also
returns you to the main setup menu.
Step 6) To program another Color Select viewing mode, turn the Size dial to
that color number. Press the PRESET button to select this option for
programming and repeat steps 3 through 5.
Merlin with Color Select
21
