  • Page 1 VGA & USB Users Manual...
  • Page 2 Congratulations on your purchase of the Transformer. Enhanced Vision products are designed to give you the highest quality and convenience available. Transformer is the most flexible and portable solution for reading, writing and viewing magnified images at any distance. Compatible with popular magnification software and windows operating systems, Transformer’s unique...
  • Page 3 FCC COMPLIANCE NOTICE This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation.

  • Page 4: Table Of Contents

    Transportation …………………..…………….………… 7 Care & Maintenance ………………………….………... 8 Chapter 2: System Requirements System Requirements …………...………….….………9 Chapter 3: Getting Started Setting up your Transformer ……………………….10-11 Software installation ………………………………...12-13 Charging…………………..…………………….………. 14 Keyboard Controls ………..….….…………………….. 15 Chapter 4: Package Contents & Controls Package Contents & Controls…….…..……………16-17 Chapter 5: Using the Transformer Viewing Modes ………..…………….……………...
  • Page 5 Changing View Modes …………………….….………..34 Changing Languages ………………….……………….35 Chapter 7: Troubleshooting Troubleshooting …………………………………………36 Chapter 8: Specifications Specifications ……………………………….………. 37-38 Chapter 9: Warranty information Warranty information ……………………….………. 39-40 Chapter 10: Other Enhanced Vision Products Other Enhanced Vision Products ……………….… 41-43 Table of Contents...

  • Page 6: Chapter 1: Safety Precautions

    Transformer, please read these important safety precautions carefully. General guidelines for use: ▶ Use the Transformer on a stable, level surface such as a solid desk or table, according to its intended design specifications. ▶ Always use the power supply provided with your package. Do not attempt to use any other power supply;...

  • Page 7: Transportation

    ▶ To prolong battery life, remove the battery from the Transformer if the system is not being used for one week or more. ▶ If needed, clean the surface of the Transformer with a soft damp cloth or an electrostatic dusting wipe.
  • Page 8 Susceptibility to Interference: There may be temporary performance degradation of the Transformer when subjected to a strong magnetic and/or radio-frequency field, electrostatic discharge or transient electrical noise. An electrostatic discharge (caused by static electricity) may cause image distortion. If this happens, switch the unit off and try moving the unit to a different location.

  • Page 9: Chapter 2 System Requirements

    SYSTEM REQUIREMENTS Laptop or Desktop PC Minimum Requirements: Operating Systems: Supported platforms for our Viewer application: • * Windows 7 (32-bit & 64-bit) Minimum requirements: • OS: *Windows 7 • Processor: Intel Pentium M 1.5 GHz • Memory: 512 MB •...

  • Page 10: Chapter 3: Getting Started

    3a. Connecting USB to Computer Connect USB cable that was provided to the back of your Transformer. Plug in the opposite end to your desktop or laptop computer. If this is your first time using this product, refer to page 8 for software installation.
  • Page 11 ▶ Keep the base of the unit on the flat surface. From the folded position, while holding the legs down, gently pull the arm of the Transformer to a vertical position. (See Figure 2) Figure 1 ▶ Pull the arm that is connected to the camera head slowly to a horizontal position.

  • Page 12: Software Installation

    Software Installation for Transformer USB If this is your first time using the Transformer, use the following instructions to install the viewer software. 1. Start up your PC as normal. Plug in the USB into your PC and the opposite end into your transformer.
  • Page 13 Figure 3 Figure 4 4. Once the setup wizard appears on screen, click to highlight “EVVAutoLauncher.exe” then click “Next”. (See figure 4) *If already installed EV Viewer will automatically launch. 5. Choose the destination folder to install the software and click on the “Next”...

  • Page 14: Charging

    Note: The included USB Cable DOES NOT charge the Transformer. The battery will take approximately 4 hours to fully charge. The Transformer Magnifier will provide up to 4 hours of usage when fully charged. When plugged in, powered on, and charging, the charge indicator light (page 17) of the Transformer will flash RED and will stay solid RED when fully charged.

  • Page 15: Keyboard Controls

    Keyboard Controls Switch Keyboard Comments Zoom+ Up Arrow Zooms in and navigates menu. Zoom - Down Arrow Zooms out and navigates menu. FREEZE Freeze Markers (Horizontal) Markers (Vertical) Escape Enter menu MODE Next color Mode Enter Select menu item Light On/Off On/Off FIND Space Bar...

  • Page 16: Chapter 4 Package Contents & Controls

    O. VGA Input (Model TRVEA Only) Please refer to the illustrations on the next page to identify the package contents and controls of your Transformer. In addition to this users guide, you’ll find the following items inside the box: Accessories 1.

  • Page 17: Package Contents & Controls

    Chapter 4 Package Contents & Controls...

  • Page 18: Chapter 5: Using The Transformer

    Viewing Mode The Transformer can be used to view objects at a distance, up close, or anywhere in between. To change viewing mode, simply turn the position of the camera by rotating it on the arm.
  • Page 19 However, if you prefer for it to be on, simply press the Green power button. NOTE: For the Transformer to be able to focus at all levels of magnification in distance mode, the object or target should be at least 3 or more feet away.
  • Page 20 Figure 1 Figure 2 Viewing Position While in Reading and Writing mode the Transformer has the flexibility to be used in three different positions, Right, For- ward, and Left. For each different position simply press the rotate button (See Figure 2) until the image is displayed correctly on screen.
  • Page 21 The Camera can be rotated backwards to provide you with the equivalent of a full-length mirror. In this position, you can use the Transformer to help you put on make-up, shave or perform other personal hygiene. Be sure to open the Reading Lens for Self Viewing.

  • Page 22: Adjusting Window Divider

    [F8] key a sixth time will exit the camera viewing window, returning you to your full screen PC desktop. Pressing [F8] again will repeat all six screen rotation cycles in sequence (See Figure 1). Figure 1 Chapter 5 Using the Transformer...
  • Page 23 PC keyboard to increase or decrease the height of the video divider window. This adjustment is useful when viewing magnified documents above and below your PC display. Chapter 5 Using the Transformer...

  • Page 24: Capturing A Still Image

    3) Select the directory in which you wish to store the file. If desired give the snapshot a descriptive file name. If no filename is entered, the default timestamp filename will be used. The image will be saved as a standard. JPEG file (Windows* JPEG). Chapter 5 Using the Transformer...

  • Page 25: Viewing A Stored Image

    NOTE: The image will open in the Windows program you have currently set as your default picture viewer Using Third-party Screen Magnification Software (Computer Connection Only): The Transformer viewer application can be used in con junction with the following magnification software products: ▶ Dolphin SuperNova Version 11.5 to 12 ▶...

  • Page 26: Using The Find

    Using the Find The Transformer Find feature can help you quickly identify where you are currently magnified on a page, or can easily locate a specific part of an object you want to view more closely. NOTE: You cannot use object Find if you are magnified at 1x.

  • Page 27: Using The Freeze

    Using the Freeze Function Freeze allows you to take a snap shot of what the Transformer is magnifying in order for you to have extended time to view the image. This is particularly helpful when taking notes in a classroom.

  • Page 28: Color Select Mode

    Freeze Figure 1 Upgrading Your Software In the interest of continuous product improvement, updates to the Viewer software will be made available on the Enhanced Vision website at: http://www.enhancedvision.com/support/software/transformer.html For assistance in locating and downloading updates, call the toll free support number, 1-800-440-9476.

  • Page 29: Chapter 6 Using The Menu

    Accessing the Menu ▶ You can access the menu by pressing and holding the Freeze button on arm of the Transformer for 3 seconds. ▶ Once the setup menu shows on-screen, use the Zoom wheel + or - to scroll through the functions. To activate one of the functions press Mode while it is highlighted.

  • Page 30: Enable/Disable Window Markers

    Enabling/Disabling Line & Window Markers Line & Window Markers are used to frame an image between two horizontal lines. These lines may be used as a reading guide for long passages of text, as a guide to help keep your place as you move from one side of the page to the other, or just to make writing easier.

  • Page 31: Adjusting The Size/Position Of Selected Marker

    Adjusting the Size/Position of the Selected Marker The following directions can be used to adjust the Size/ Position of the Line or Window Marker: 1. Make sure the Line/Window marker is currently Enabled. (Refer back to page 30 if you are not sure how to do this) 2.

  • Page 32: Adjusting The Color Balance

    Adjusting the Color Balance Color is often affected by the lighting used in a room. The Transformer Color Balance control allows you to achieve optimum clarity. The following directions can be used to adjust the Color Balance: 1. Press and hold the Freeze button for 3 seconds until setup menu shows on-screen 2.

  • Page 33: Changing Favorite Color Modes

    Changing Favorite Color Modes The Transformer provides 28 selectable color modes, and allows selecting up to 6 favorites for use, as described on page 28. The following directions can be used to change the favorite color modes on your Transformer: 1.

  • Page 34: Changing View Modes

    3.) Press the “Power Button” on the Transformer (see page 12) * The Transformer will not power off when the VGA monitor is powered off or when the VGA Cable is unplugged. Press and Hold the “Green power button” on the Transformer for about 3 seconds, or until the “Battery Charge Indicator Light”...

  • Page 35: Changing Languages

    5. Using the Scroll Wheel, select the desired language and press the Mode button once. USB Mode The Transformer, while in USB mode, will automatically detect the language that is set on your Microsoft Windows PC. These settings can be changed in the Language...

  • Page 36: Chapter 7 Troubleshooting

    Clean the LCD display and/or camera lens using a cleaning cloth. Adjust the distance of the Transformer from your reading material or adjust the handle angle as needed to improve image quality (focus) Try selecting different color modes to improve image quality (See...

  • Page 37: Chapter 8 Specifications

    SPECIFICATIONS Features: • Lightweight, portable design • 330˚ adjustable camera head • 6 user favorite color modes (with 28 to choose from) • 28 available color modes • Magnification 2.45X up to 30X (Based on a 17” monitor) • Image “Freeze” mode •...
  • Page 38 Storage temperature : -4˚ – 140˚F (-20˚ – 60˚C) Estimated Charge times (using rechargeable battery): ~4 hours maximum * Note: Only with use of Enhanced Vision Battery **All times listed are approximate. Actual Charging and Usage times may vary depending on the life cycle remaining on the batteries, type and current rating of batteries used, LCD brightness setting, LED Mode and other variable factors.

  • Page 39: Chapter 9 Warranty Information

    Transformer against defects in material and workmanship under normal use for two years from the date of original purchase. Enhanced Vision, at its option, will at no charge either repair the product or replace it during the warranty period. There are no other expressed or implied warranties accompanying this product.
  • Page 40 Enhanced Vision representative or the Enhanced Vision warranty service center. If warranty service is required, please contact Enhanced Vision at (800) 440-9476 Monday through Friday, between 8 a.m. and 5 p.m. Pacific Standard Time (PST) to request a return authorization number.

  • Page 41: Chapter 10 Other Enhanced Vision Products

    DaVinci will read any printed text aloud with the push of a button. Magnification: 24” LCD: 2x- to 80x Chapter 10 Other Enhanced Vision Products...
  • Page 42 The adjustable arm, tilting screen, and rotating capability allows the camera to be positioned at any angle for optimal viewing. A built in handle allows for easy transport. Magnification 1.7x to 95x Chapter 10 Other Enhanced Vision Products...
  • Page 43 Additional batteries are available for your Transformer. Power Supplies Optional external charger is available for your Transformer. X-Y Mini table Place underneath your Transformer and make reading even easier! Contact Information: (US Office) Phone: (714) 465-3400 Fax: (714) 374-1821 (UK Office) Phone: +44 (0)115 9442317...
  • Page 44 NOTES ______________________________________________ ______________________________________________ ______________________________________________ ______________________________________________ ______________________________________________ ______________________________________________ ______________________________________________ ______________________________________________ ______________________________________________ ______________________________________________ ______________________________________________ ______________________________________________ ______________________________________________ ______________________________________________ ______________________________________________ ______________________________________________ ______________________________________________ ______________________________________________ ______________________________________________ ______________________________________________ ______________________________________________ Notes...
  • Page 45 The Transformer video magnifier is designed to enlarge and enhance images to improve the lives of people who have low vision. The extent to which Transformer can improve the ability to see images and text depends on a person’s individual condition and level of visual impairment. The Transformer is not designed to restore vision, correct eye conditions or have degenerative vision loss.
