Installation Manual
Quick Guide
XX268-10-00
CE102D Network Indoor
Camera Dome
Vicon Industries Inc.
Tel: 631-952-2288 Fax: 631-951-2288 Toll Free: 800-645-9116
24-Hour Technical Support: 800-34-VICON (800-348-4266) UK: 44/(0) 1489-566300
Vicon Industries Inc. does not warrant that the functions contained in this equipment will meet your requirements or that the
operation will be entirely error free or perform precisely as described in the documentation. This system has not been designed
to be used in life-critical situations and must not be used for this purpose.
www.vicon-security.com
Document Number: 8009-8268-10-00
Issued: 214
Product specifications subject to change without notice.
Copyright © 2014 Vicon Industries Inc. All rights reserved.
Advertisement
Table of Contents
Related Manuals for Vicon CE102D
Summary of Contents for Vicon CE102D
-
Page 1: Camera Dome
24-Hour Technical Support: 800-34-VICON (800-348-4266) UK: 44/(0) 1489-566300 Vicon Industries Inc. does not warrant that the functions contained in this equipment will meet your requirements or that the operation will be entirely error free or perform precisely as described in the documentation. This system has not been designed to be used in life-critical situations and must not be used for this purpose. -
Page 3: Quick Installation Guide
Quick Installation Guide 1. Description The information in this manual provides quick installation and setup procedures for the CE102D Series of Camera Domes. These units should only be installed by a qualified technician using approved materials in conformance with federal, state, and local codes. Read these instructions thoroughly before beginning an installation. -
Page 4: Camera Installation
Quick Installation Guide 2. Installation 2.1 Camera Installation Carefully remove the contents from the box and verity that nothing was damaged in shipment. 1) Using the template sheet provided, make screw holes for camera on the ceiling. 2) Disassemble the camera by gently turning the camera cover counter-clockwise to remove it. 3) Secure the dome camera to the ceiling using the anchors (2x) and screws (2x) provided in the accessory kit. - Page 5 Quick Installation Guide Locking Screw Camera Dimension See the diagrams below for the exact dimension...
- Page 6 Quick Installation Guide • Connection Cable Name Description Lens Allows wide area to be monitored Power Cable Cable for Power source (12 VDC ) Ethernet Cable Cable for Ethernet (POE) • Connecting to the RJ-45 Connect a standard RJ-45 cable to the network port of the network camera. Generally a cross-over cable is used for directly connection to PC, while a direct cable is used for connection to a hub or switch.
-
Page 7: Network Connection And Ip Assignment
Quick Installation Guide 2.2 Network Connection and IP assignment The network camera is designed for use on an Ethernet network and requires an IP address for access. Most networks today have a DHCP server that automatically assigns IP addresses to connected devices. -
Page 8: Operation
Quick Installation Guide 3. Operation The network camera can be used with Windows® operating system and browsers. The recommended browsers are Internet Explorer®, Safari®, Firefox®, Opera® and Google® Chrome® with Windows. Note: To view streaming video in Microsoft® Internet Explorer, set your browser to allow ActiveX controls. -
Page 9: Access From The Internet
Quick Installation Guide 3.2. Access from the internet Once connected, the network camera is accessible on your local network (LAN). To access the network camera from the Internet you must configure your broadband router to allow incoming data traffic to the network camera. To do this, enable the NAT-traversal feature, which will attempt to automatically configure the router to allow access to the network camera. -
Page 10: Control Toolbar
Quick Installation Guide The protocol drop-down list allows the selection of the combination of protocols and methods to use depending on your viewing requirements and on the properties of your network. 2) Control toolbar The live viewer toolbar is available in the web browser page only. It displays the following buttons: The Stop button stops the video stream being played. -
Page 11: Resetting To The Factory Default Settings
Quick Installation Guide 3.6 Resetting to the factory default settings To reset the network camera to the original factory settings, go to the Setup>System> Maintenance web page (described in “3.5.5 System > Maintenance”) or use the Reset button on the network camera, as described below. - Page 12 Vicon Industries Inc. Internet Address: www.vicon-security.com CE102D Network Indoor Camera Dome 50303747A...
