INSTRUCTIONS FOR
INSTALLATION AND OPERATION
MODEL V8606H-XD
The information in this manual covers the installation
of the V8606H-XD
installation of this equipment must be in conformance
with national, state, and local electrical codes.
Model V8606H-XD is a miniature indoor camera enclo-
sure, constructed of two major parts: a steel upper
housing, into which the camera and lens am mounted,
and a tamperproof hinged lower housing or cover with
WARNING: Read
COMPLETELY before installing this unit. Fail-
A
ure to do so may result in costly installation
mistakes or personal injury to installers or other
persons.
CAUTION: Total weight of camera/lens assembly
A should not exceed 10 pounds (4.5 kg).
The V8606HXD is designed to be mounted to most types
of ceilings. JnstaUion in a suspended ceiling requires
model V8606H-XD-ACP, an adjustable ceiling panel
location is clear of obstacles (such as steel beams,
headers, pipes, electrical wiring, etc.) which would
interfere with the mounting of the housing. The
space.
WARNING: TO PREVENT RISK OF FIRE OR ELECTRIC SHOCK, DO NOT EXPOSE THIS UNIT TO RAIN OR MOISTURE.
INC. 525 BROAD HOLLOW ROAD, MELVILLE, N.Y. 11747 TEL: 516-293-2200
MINIATURE CEILING HOUSING
2. INSTALLATION
ALL
instructions
2.1 Ceiling Preparation
TOLL FREE: l-600445-91 16
NOTES
SUPERSEDES ITGTFWC'IION
a viewing window. The window is constructed of clear
acrylic plastic. A special tool is provided for opening
and closing the tamperproof screw. Electrical connec-
tions are made through one of five knock-outs.
This compact unit is designed for very shallow ceiling
clearances. The housing accepts small CCD cameras
with either fixed-focal-length manual or autoiris lenses.
which allows 360 degree position adjustment capability
for the V8606HXD housing. The V8606H-XD may
also be mounted in a panel supplied by the installer, but
the panel must be of a material (wood or metal) s&i-
ciently strong to support the combined weight of the
housing and camera/lens assembly. 'Ibe V8606H-XD
weighs 6.0 lb (2.7 kg). Conventional ceiling tile and
sheet rock will not support this housing.
NOTE: For installation to a suspended ceiling,
see the instructions included with model
2. Video, sync, and power cables must be routed near
the housing opening.
