INSTRUCTIONS FOR
INSTALLATION AND OPERATION
MODEL V896MSH
The information in this instruction manual covers the instal-
lation, operation, and maintenance of model V896MSH
Weatherproof Maximum Security Housing.
This unit should be installed only by a qualified techni-
cian using approved materials and wiring practices in
accordance with national, state, and local electrical
codes. Failure to comply with these instructions may
result in personal injury and/or damage to the equip-
ment. Read these instructions through completely before
attempting installation.
The V896MSH housing provides a tamper-resistant means
of concealing a video camera on either a ceiling, wall, or
pole and is intended for use in high-risk areas where
surveillance equipment is vulnerable to physical damage
or criminal violence. The housing is designed for small
solid-state cameras with fixed-focal-length lenses.
The housing is constructed entirely of welded lo-gauge
steel and is protected by cast-iron-gray vinyl paint. It is
virtually impenetrable and completely closed and sealed
against moisture. A thermostatically-controlled heater and
defogger option (Model V896MSH-H) is available for
outdoor applications. The camera window is 3/8-inch-
thick (0.95 cm) Lexan *. A hinged bottom section (the
WARNING:
Read ALL instructions COMPLETELY
A
before installing this unit. Failure to do so may
result in costly installation mistakes or personal
injury to the installers or other persons.
In order to open the enclosure for installation, use the
tion with the key. Turn the key lock to the open position.
Remove the screw with sealing washer that covers the
Product specifications subject to change without notice.
INC. 525 BROAD HOLLOW ROAD, MELVILLE, N.Y. 11747 TEL: 516-293-2200 FAX: 516-293-2627
TOLL FREE: l-800-645-9116 UK: 44/(O) 1489/577775
WEATHERPROOF MAXIMUM SECURITY HOUSING

1. INTRODUCTION

2. INSTALLATION

I
cover) is provided with a specially-keyed double-acting
lock for an uncomplicated but secure locking system.
The housing may be mounted directly to a solid ceiling,
or it may be mounted to a wall or pole using the V896MA
Mounting Adapter. The housing is designed with an
axially adjustable camera platform so that the camera
can be adjusted easily and the lens focused from below
the ceiling.
Provision is made for routing electrical connections,
including AC power lines and video cables, into the
housing. There are two holes in the top of the housing
for this purpose. Since the cables pass directly into the
ceiling or mounting adapter, they are not exposed at any
point to vandalism.
This product complies with European Community EMC
Directive 89/336. The product was subjected to the
testing outlined in European Normalization Standard
EN 5008 l-l (Electromagnetic Compatibility - General
Emissions Standard Part 1: Residential, Commercial,
and Light Industry), and EN 50082-l (Electromagnetic
Compatibility - Generic Immunity Standard part 1:
Reidential, Commercial, and Light Industry).
latch release. This is located on the side of the base. See
Figure 1. Insert the key into the opening on the side of
the housing base until it seats. Turn it against the spring
tension of the internal latches. The unit may now be
opened.
If the V896MSH-H option is to be installed, refer to
Instruction Manual X485 before doing any further in-
stallation procedures.
