4.2 CONNECTION OF UPS

4.2-1
4.2-3
4.2-2
Mains
Ø UPS
2
(mm )
≥ 6 5 kVA
≥ 8 7 kVA
≥ 10 9 kVA
≥ 10 11 kVA
Refer to local regulations for correct cable rating.
4.2-4
5-11 kVA - Ref.: IOMNETRTXX01-GB 05
4. CONNECTION
UPS
Output
Ø
2
(mm )
≥ 6
≥ 8
≥ 10
≥ 10
