  • Page 1 Adam Equipment CBC-M SERIES with EC type Approval (P.N. 8226, Revision C6, February 2008) Software rev.: 3.06A & above © Adam Equipment Company 2007...
  • Page 2 © Adam Equipment Company 2007...
  • Page 3: Table Of Contents

    CONTENTS INTRODUCTION .....................2 SPECIFICATIONS ...................3 INSTALLATION ....................4 LOCATING THE SCALE ................4 INSTALLATION OF CBC-M SERIES ............5 KEY DESCRIPTIONS..................5 DISPLAYS .......................6 WEIGHT DISPLAY..................6 UNIT WEIGHT DISPLAY ................7 COUNT DISPLAY ..................7 OPERATION....................7 ZEROING THE DISPLAY................7 TARING......................8 PARTS COUNTING ..................8 6.3.1 Setting Unit Weight ................8 6.3.2...
  • Page 4: Introduction

    1.0 INTRODUCTION • The CBC-M series provide accurate, fast and versatile counting and check-weighing scales. • CBC-M scales are kilogram only scales. • There are 4 models of approved scales with capacities up to 30 kg. • They all have stainless steel weighing platforms on an ABS base assembly.
  • Page 5: Specifications

    Parts counting, weighing, accumulating memory, Check-count with alarm Interface RS-232 bi-directional interface English, German, French, Spanish selectable text Date/Time Real Time Clock (RTC), To print date and time information (Dates in year/month/day, day/month/year or month/day/year formats- Battery backed) © Adam Equipment Company 2007...
  • Page 6: Installation

    Avoid air movement such as from fans or • opening doors. Do not place near open windows or air-conditioning vents. Keep the scales clean. Do not stack material • on the scales when they are not in use. © Adam Equipment Company 2007...
  • Page 7: Installation Of Cbc-M Series

    INSTALLATION OF CBC-M SERIES • The CBC-M Scales comes with a stainless steel platform packed separately. • Place the platform in the locating holes on the top cover. • Do not press with excessive force as this could damage the load cell inside.
  • Page 8: Displays

    It has 5-digit display to indicate the weight on the scale. Arrows above symbols will indicate the following: Low battery, Net Weight Display, "Net" Stability indicator, "Stable" or symbol as above. Zero indicator, "Zero" or symbol as above 0    © Adam Equipment Company 2007...
  • Page 9: Unit Weight Display

    • This display will show the unit weight of a sample. This value is either input by the user or computed by the scale. The unit of measurement is kilograms on all CBC-M series. • The arrow indicator will be seen above "Sample" or symbol as above, when there is insufficient number of samples to accurately determine the count.
  • Page 10: Taring

    Press [CE] anytime to clear the unit weight. • Zero the scale by pressing the [Zero] key if necessary. If a container is to be used, place the container on the scale and tare by pressing [Tare] as discussed earlier. © Adam Equipment Company 2007...
  • Page 11: Counting More Parts

    • After the scale is tared the items to be counted are added and the "Count" display will show the number of items, computed using the total weight and the unit weight. • It is possible to increase the accuracy of the unit weight at © Adam Equipment Company 2007...
  • Page 12: Automatic Part Weight Updates

    2 seconds before returning to normal. • The scale must return to zero or a negative number, before another sample can be added to the memory. • More products can then be added and the [M+] key to be © Adam Equipment Company 2007...
  • Page 13: Automatic Accumulated Totals

    RS-232 interface. Specifications: RS-232 output of weighing data ASCII code Adjustable Baud rate, 600, 1200, 2400, 4800, 9600 and 19200 baud 8 data bits No Parity © Adam Equipment Company 2007...
  • Page 14 Includes 2 line feeds <lf> Pressing the [MR] key will not send the totals to the RS-232 when the continuous print is turned on. The continuous print will only be for weight and display data that is current. © Adam Equipment Company 2007...
  • Page 15: Input Commands Format

    Recall and Print- Same as if first the [MR] key and then the [Print] key is pressed. Will display the current accumulated memory and print the total results. C<cr><lf> Same as pressing [MR] first and then the [CE] key to erase the current memory. © Adam Equipment Company 2007...
  • Page 16: Rs-232 Setup

    Print continuously Print continuously and Print continuously and accumulate accumulate when [M+] Cont to PC automatically when is pressed [M+] and [Print] key stable. [Print] key have no function [Print] key no function no function © Adam Equipment Company 2007...
  • Page 17: Real Time Clock Setup

    This function may be enabled or disabled by the user. If enabled, when the scale is not used for some time (as pre-set by the user under this function) it automatically switches off. To set this parameter- © Adam Equipment Company 2007...
  • Page 18: Battery And Backlight Operation

    • If the battery has not been used properly or it is used for a number of years it may eventually fail to hold a full charge. If the battery life becomes unacceptable then contact your distributor or Adam Equipment. © Adam Equipment Company 2007...
  • Page 19: Backlight For Lcd

    Improper calibration of the scale. or when the [Zero] key is pressed, Damaged load cell. Damaged Electronics. A/D count is not correct Platform is not installed. Err 6 when turning the scale Damaged load-cell. Damaged electronics. © Adam Equipment Company 2007...
  • Page 20: Calibration

    11.0 CALIBRATION The CBC-M approved scales are sealed to prevent unauthorised calibration. Contact Adam Equipment or your supplier for more details. 11.1 CALIBRATION PROCEDURE The calibration of the CBC-M scale is accomplished by removing the label at the base of the scale which covers a hole through which the PCB can be accessed.
  • Page 21: Replacement Parts And Accessories

    12.0 REPLACEMENT PARTS AND ACCESSORIES If you need to order any spare parts and accessories, contact your supplier or Adam Equipment. A partial list of such items is as follows- • Mains Power cord • Stainless Steel Pan • Replacement Battery •...
  • Page 22: Warranty Information

    During the warranty period, should any repairs be necessary, the purchaser must inform its supplier or Adam Equipment Company. The company or its authorised Technician reserves the right to repair or replace the components at any of its workshops depending on the severity of the problems.
  • Page 23 Adam Equipment ADAM EQUIPMENT, BOND AVENUE, DENBIGH EAST INDUSTRIAL ESTATE, MILTON KEYNES, MK1 1SW, U.K. Tel: (01908) 274545 Fax: (01908) 641339 Intl Tel: -44 1908 -274545 Intl Fax: -44 1908 641339 E-Mail Address: info@Adamequipment.co.uk Test Certicifate Test certificaat Prüfzertifikat Certificato di prova...
  • Page 24 For a complete listing of all Adam products visit our website at www.adamequipment.com © Copyright by Adam Equipment Co. Ltd. All rights reserved. No part of this publication may be reprinted or translated in any form or by any means without the prior permission of Adam Equipment.
