Gateway Profile 4 Service Manual page 83

Replacing Components in Your Gateway Profile 4
33
Connect the LCD video, LCD power, diskette drive, and optical drive cables
to the system board using the notes you made in Step 29.
34
Secure the two card brackets to the system board with the three screws
removed in Step 26.
35
Insert the three cards into the slots using the notes you made in Step 28.
You can slightly seesaw the card end-to-end as you insert it into the slot,
but do not bend the card sideways.
36
Secure the card retention plate to the computer chassis with the two screws
removed in Step 25.
78
LCD video cable
Optical drive cable
Diskette drive cable
www.gateway.com
LCD power cable
