Replacing the system board
23
Disconnect the hard drive, power, and LED cables from the system board.
Disconnect the speaker and headphone/microphone jack cables from the
audio card. Note the location and orientation of each cable. You will
reconnect these cables later.
Power cable
Headphone/Microphone jack cable
Hard drive cable
LED cable
Speaker cables
www.gateway.com
71
