Volume control on the MLC 104

To control the volume on the MLC 104 using the IR 452, press the rocker button
in the Display section. Pressing the up or down arrow on this button causes the
DVCM 50 to send a +V or –V SIS command to the MLC 104, which responds by
increasing or decreasing the volume on the display device.
Remove the Volume label from the sheet of labels provided with the IR 452, and
affi x it above the arrow rocker button on the IR 452 front panel as shown in the
illustration below.
