Special Application, cont'd
The table below shows the SIS commands that the DVCM 50 issues to the MLC 104
for each press of an IR 452 button, and the button that is activated on the MLC 104.
You must program the desired commands onto the MLC 104's front panel buttons, using
the Global Confi gurator software, in order for the MLC to send the correct command to
the projector.
For example, the fi rst row of the table above shows that when you press the
Power On button in the Display section of the IR 452, the signal sent to the
DVCM 50 is interpreted as the SIS command 1P. This command is sent to the
MLC 104 to activate the button that is labeled On (in the Projector section). The
MLC 104 responds by issuing the command to the projector to turn on.
Once you have programmed and labeled the buttons on the MLC 104, you should relabel
the IR 452 buttons to indicate the commands they will initiate on the MLC 104. Refer to
your IR 452 User's Manual for information on labeling buttons on the remote control.

Muting and unmuting

The MLC 104 does not have buttons that control muting and unmuting on the
display device. However, you can program Mute On and Mute Off commands
onto the MLC 104 using the Global Confi gurator (GC2) software. (Visit the Extron
Web site at www.extron.com for information on ordering the GC2 software.)
Depending on the feature set of your display device, you can program the MLC 104
to mute/unmute the video, audio, or both.
To use the IR 452 to control muting/unmuting, press the Mute On or Mute Off
button in the Display section. Pressing these buttons causes the DVCM 50 to
send an SIS command (1M for Mute On button or 0M for Mute Off button) to the
MLC 104, causing it to mute or unmute the display device.
DVCM 50 • Special Application
4-8
IR 452 Button
IR 452 Section
Name
Power On Display
Power Off Display
Vol Front Panel
PC Front Panel
Vol Front Panel
Video Front Panel
Volume Up
Display
(arrow)
Volume Down
Display
(arrow)
Mute On Display
Mute Off Display
SIS Command MLC 104 Button/
from DVCM 50 Function Activated
1P On
0P Off
1! Input selection button 1
2! Input selection button 2
3! Input selection button 3
4! Input selection button 4
Volume control knob
+V
Increase
Volume control knob
–V
Decrease
Audio/video muting on
1M
(No button equivalent)
Audio/video muting off
0M
(No button equivalent)
