Overview

Future light
R
Down Up
Mode
DJ-Color 200
Control Board
1 2 3 4 5 6 7
(1) Housing screws
(2) Housing cover
(3) Mounting bracket
(4) Fixation screw
(5) Focus-screw
(6) Zoom-screw
(7) Control Board
(8) Safety eyelet
(9) Lamp system
(10) DMX-Out socket
(11) DMX-In socket
(12) Fuseholder
(13) Power supply
(14) Mode-button
(15) Down-button
(16) Up-button
(17) Display
(18) Control LED
