If you set, for example, the address to channel 5, the DJ-COLOR 200 will use the channel 5 to 8 for control.
Please, be sure that you don't have any overlapping channels in order to control each DJ-COLOR 200
correctly and independently from any other fixture on the DMX data link.
If two, three or more DJ-COLOR 200 are addressed similarly, they will work similarly.
For address setting, press the Mode-button until the display shows "d" and set the desired address via the
Up/Down-buttons.
Controlling:
After having addressed all DJ-COLOR 200, you may now start operating these via your lighting controller.
Note:
After switching on, the DJ-COLOR 200 will automatically detect whether DMX 512 data is received or not. If
the data is received, the control LED flashes. If there is no data received at the DMX-input, the control LED
lights up permanently.
This situation can occur if:
- the 3 PIN XLR plug (cable with DMX signal from controller) is not connected with the input of the DJ-
COLOR 200.
- the controller is switched off or defective, if the cable or connector is defective or the signal wires are swap
in the input connector.
Note:
It's necessary to insert the XLR termination plug (with 120 Ohm) in the last lighting in the link in order to
ensure proper transmission on the DMX data link.

DMX-protocol

Control channel 1 - Colour-wheel
Linear colour change following the movement of the slider. In this way you can stop the colour-wheel in any
position.
DMX-value Feature
0-10 White
11-21 Light blue
22-32 Light green
33-43 Orange
44-54 Green
55-65 Sky blue
66-76 Pink
77-87 Red
88-98 Yellow
99-109 Dark blue
110-120 Dark green
121-127 Peach
128-191 Forwards rainbow effect with increasing speed
Control channel 2 – Effect-wheel
DMX-value Feature
0-20 Circle 1
21-42 Correction-filter 3,200 K
43-63 Correction-filter 6,000 K
64-84 Magenta
85-106 Cyan
107-127 Yellow
128-148 UV-like
149-170 Gobo 2
171-191 Gobo 1
192-212 Circle 4
