HI200 Wood Cast Insert Owner's & Installation Manual www.hampton-fi re.com Tested by: Installer: Please complete the details on the back cover and leave this manual with the homeowner. Homeowner: Please keep these instructions for future reference. FPI FIREPLACE PRODUCTS INTERNATIONAL LTD. 6988 Venture St., Delta, BC Canada, V4G 1H4...
Page 2
The pride of workmanship that goes into each of our products will give you years of trouble-free enjoyment. Should you have any questions about your product that are not covered in this manual, please contact the HAMPTON DEALER in your area. Keep those HAMPTON FIRES burning.
Brick Flue Baffl e & Secondary Air Tube Installation ..14 Firebrick Assembly ............14 Draft Control ..............14 First Fire ..............15 Fan Operation..............15 OPERATING INSTRUCTIONS First Fire ..............16 Fan Operation..............16 Ash Disposal..............16 Safety Guidelines ............16 Creosote ..............16 http://oee.nrcan.gc.ca/residential/personal/retrofi t-homes/retrofi t-qualify-grant.cfm HI200 Hampton Wood Cast Insert...
SAFETY LABEL This is a copy of the label that accompanies each HI200 Wood Insert. We have printed a copy of the contents here for your review. NOTE: Hampton units are constantly being improved. Check the label on the unit and if there is a difference, the label on the unit is the correct one.
UNIT DIMENSIONS WITH STANDARD FLUE ADAPTOR 6" (152mm) Diameter STANDARD FLUE ADAPTOR (171-932) NOTE: Before assembling your Insert, use these dimensions to en- sure appropriate clearances will be met (refer to Masonry and Factory Built Fireplace Clearances section).
Page 6
39-13/16” 2-7/8” 38-5/16” 6" (152mm) Diameter OFFSET FLUE ADAPTOR (171-936) NOTE: Before assembling your Insert, use these dimensions to en- sure appropriate clearances will be met (refer to Masonry and Factory Built Fireplace Clearances section). HI200 Hampton Wood Cast Insert...
1) Read all instructions before installing and must be supplied with appropriate supporting using your fi replace insert. Install and use means. Hampton Inserts are designed to use either a only in accordance with manufacturer’s 5.5" (140mm) or 6" (152mm) fl ue. installation and operating instructions.
R = 1/k x T = 1/0.84 x .75 = 0.893. specifi ed R of 0.893. Since proposed system R is greater than required, the system is Thermal Resistance: acceptable. R = (ft )(hr)( )(K) HI200 Hampton Wood Cast Insert...
1/2 to 1 inch of the leveling bolt. Flue Adaptor Diagram 2 Secure adaptor using 3 screws - 1 in the front and 1 each on the left and right side. HI200 Hampton Wood Cast Insert...
Page 10
Pull Rod Diagram 7 NOTE: The pull rod should not be thrown away. It should be kept if the stove is ever needed to be removed from the fi replace. Diagram 5: Pull Rod In Place HI200 Hampton Wood Cast Insert...
Note: If screws do not lineup, loosen the 2 screws per side as shown in Diagram 2 and adjust left side and right side facia. Tighten the 2 screws per side and install the fan on the unit. HI200 Hampton Wood Cast Insert...
Page 13
DO NOT ROUTE THE FAN POWER CORD UNDER OR IN FRONT OF THE UNIT. Do not turn the fan ON until your insert has reached operating temperature or at least 30 minutes after starting fi re. Ashlip Diagram 6 HI200 Hampton Wood Cast Insert...
fi t will ensure the tube will not move when the unit is burning. 2) Slide the left baffl e brick over the front air tube and then slide it back over the rear air tube. HI200 Hampton Wood Cast Insert...
9) During the fi rst few hours it may be more dif- fi cult to start the fi re. As you dry out your fi re brick and your masonry fl ue (if applicable), your draft will increase. Fan Wiring Diagram HI200 Hampton Wood Cast Insert...
Please take care to prevent the combined with moisture. The creosote vapors 9) Your Hampton Insert can be very hot. You build-up of ash around the start-up air housing condense in the relatively cool chimney fl ue of a may be seriously burned if you touch the located inside the fi...
A proper high temperature gasket adhesive is required. A gasket 1) Remove door from unit. repair kit, Part # 846-570 is available from your local Hampton dealer. 2) To replace the glass remove the 4 screws highlighted in the diagram below.
Bracket. Ensure an equal amount of spacers are removed from both top and bottom. 4) Re-secure the Latch to the Mounting Bracket using 2 inner hex bolts. 5) Re-secure the Latch Assembly to the unit using the 2 outer hex bolts. HI200 Hampton Wood Cast Insert...
Page 19
Latch Assembly re-assembled with spacers removed. Latch Assembly 5) Re-secure the Latch Assembly to the unit using 2 bolts. Confi rm proper location of the door catch so that it closes tight, freely. Latch Assembly removed from unit. HI200 Hampton Wood Cast Insert...
PARTS LIST CAST FACEPLATE Part # Description 210-921 Metallic Black Faceplate 210-925 Timberline Brown Faceplate Top Surround Left Side Surround Right Side Faceplate * Not available as a replacement part. HI200 Hampton Wood Cast Insert...
Brick Partial: 1-1/4" x 2" x 9" 81) * Brick Partial: 1-1/4" x 1-1/4" x 9" 84) * Brick Partial: 1-1/4" x 4-1/2" x 8" 85) * Brick Partial: 1-1/4" x 4-1/4" x 8" *Not available as a replacement part. HI200 Hampton Wood Cast Insert...
The authorized selling dealer is responsible for all in-fi eld service work carried out on your Hampton product. FPI will not be liable for results or costs of workmanship from unauthorized service persons or dealers.
