Hi1150-1
Wood Cast
Insert
Owner's & Installation Manual
www.hampton-fire.com
Tested by:
Installer: Please complete the details on the back cover
and leave this manual with the homeowner.
Homeowner: Please keep these instructions for future reference.
0219WN036S
FPI FIREPLACE PRODUCTS INTERNATIONAL LTD. 6988 Venture St., Delta, BC Canada, V4G 1H4
920-846
11.19.24
Advertisement
Table of Contents
Related Manuals for HAMPTON BAY Hi1150-1
Summary of Contents for HAMPTON BAY Hi1150-1
- Page 1 Hi1150-1 Wood Cast Insert Owner's & Installation Manual www.hampton-fire.com Tested by: Installer: Please complete the details on the back cover and leave this manual with the homeowner. Homeowner: Please keep these instructions for future reference. 0219WN036S FPI FIREPLACE PRODUCTS INTERNATIONAL LTD. 6988 Venture St., Delta, BC Canada, V4G 1H4 920-846 11.19.24...
- Page 2 Tested to Method 28R, E2780-10, E2515-11. Model Hampton Hi1150-1 – 1.3 g/hr. "This manual describes the installation and operation of the Hampton Hi1150-1 wood heater. This heater meets the 2020 U.S. Environmental Protection Agency’s cord wood emission limits for wood heaters. Under specific test conditions this heater has been shown to deliver heat at rates ranging from 12,700 BTU/hr to 27,300 BTU/hr.
-
Page 3: Table Of Contents
Safety Maintenance Copy of the Safety Decal (Hi1150-1) ......... 4 Maintenance ..............20 Creosote ............... 20 Ways to Prevent and Keep Unit Free of Creosote ..... 20 Dimensions Wood Storage ............... 20 Fan Maintenance ............20 Unit Dimensions with Standard Flue Adaptor ..... 5 Door Gasket .............. -
Page 4: Copy Of The Safety Decal (Hi1150-1)
U.S. ENVIRONMENTAL PROTECTION AGENCY CERTIFIED TO COMPLY WITH 2020 PARTICULATE EMISSION STANDARDS USING CRIB WOOD.” TESTED TO METHOD 28R, E2780-10, E2515-11. MODEL REGENCY HI1150-1 – 1.3 G /HR. THIS WOOD HEATER NEEDS PERIODIC INSPECTION AND REPAIR FOR PROPER NOTE: Regency units are constantly being OPERATION. -
Page 5: Dimensions
OFFSET FLUE ADAPTOR (172-942) STANDARD FLUE ADAPTOR (172-942) OFFSET FLUE ADAPTOR (172-946) NOTE: Before assembling your Insert, use these dimensions to ensure appropriate clearances will be met (refer to Masonry and Factory Built Fireplace Clearances section). Hi1150-1 Hampton Wood Cast Insert |... -
Page 6: Unit Dimensions With Offset Flue Adaptor
6" (152mm) Diameter 942) STANDARD FLUE ADAPTOR (172-946) OFFSET FLUE ADAPTOR (172-946) NOTE: Before assembling your Insert, use these dimensions to ensure appropriate clearances will be met (refer to Masonry and Factory Built Fireplace Clearances section). | Hi1150-1 Hampton Wood Cast Insert... -
Page 7: Installation
Your fireplace opening requires the following minimum sizes: Height: 19-5/8" (499 mm) Width: 25" (635 mm) Depth: 15" (381 mm) (w/ standard flue adaptor) 18-1/16" (459 mm) (w/ offset flue adaptor) Faceplate Dimensions: Height 27-1/4" (692 mm) Width 38-5/16" (973 mm) Hi1150-1 Hampton Wood Cast Insert |... -
Page 8: How To Determine If Alternate Floor Protection Materials Are Acceptable
DEFINITIONS Thermal Conductance: C = Btu = W (hr)(ft2 )(oF) (m2))(K) Thermal Conductivity: k = (Btu)(inch) = W = Btu (hr)(ft3)(oF) (m)(K) (hr)(ft)(oF) Thermal Resistance: R = (ft2)(hr)(oF) = (m2)(K)Btu | Hi1150-1 Hampton Wood Cast Insert... -
Page 9: Installation Into A Masonry Fireplace
A fire extinguisher should be installed in the 7. Do not connect the insert to a chimney home. The location of the fire extinguisher system servicing another appliance or an should be known by all family members. air distribution duct. Hi1150-1 Hampton Wood Cast Insert |... -
Page 10: Installing Your Insert
Before inserting the unit the adaptor should 7. Ensure that the unit is still level. hang, when level, slightly above the required 10. Re-install the door removed in step 1. height. Pull Rod Diagram 4 Flex Liner Diagram 1 10 | Hi1150-1 Hampton Wood Cast Insert... -
Page 11: Fan & Cast Faceplate Installation
Note: If screws do not lineup, loosen the 2 screws per side as shown in Diagram 2 and adjust left side and right side facia. Tighten the 2 screws per side and install the fan on the unit. Hi1150-1 Hampton Wood Cast Insert | 02/19/09 918-745b... - Page 12 Do not turn the fan ON until your insert has reached operating temperature or at least 30 minutes after starting fi re. Ashlip Diagram 6 Installer: Please record unit serial number here before installing blower. Serial No.______________________________ 12 | Hi1150-1 Hampton Wood Cast Insert 918-745b 02/19/09...
-
Page 13: Brick Installation
Firebox floor - install brick over LyTherm Sheet c) Right and left side Firebricks Fire bricks Size 8-3/8" x 4-3/8" 9" x 4-1/4" 9" x 4-1/2" 9" x 2-3/8" 3-1/2" x 4-1/2" 7-3/4" x 4-1/4" 3-1/2" x 2-1/4" Hi1150-1 Hampton Wood Cast Insert |... -
Page 14: Baffle Installation
Baffle Installation Note: unit in images may not be identical to the Hi1150-1 — they depict 5. Install the front air tube removed in step 2. the process. 6. Install baffle brackets on either side by slightly lifting baffles up and placing brackets in between baffles and the front air tube. -
Page 15: Stainless Steel Smoke Deflector Installation
Ensure deflector is seated so bolts are seated at the bottom of the slot before tightening. Smoke deflector installed with 2 bolts. Note: This is a cutaway view from the back of the unit Hi1150-1 Hampton Wood Cast Insert |... -
Page 16: Seasoned Wood
Two dry pieces banged together sound hollow; wet pieces sound solid and dull. • Dry wood weighs much less than wet wood. • Split a piece of wood. If the exposed surface feels damp, the wood is too wet to burn. 16 | Hi1150-1 Hampton Wood Cast Insert... -
Page 17: Operating Instructions
ALL OTHERS LISTED ON PAGE 2 ARE NOT WARNING: Never build a roaring fire in APPROVED. SEASONED CORDWOOD SHOULD a cold wood insert. Always warm your BE LESS THAN 20% MOISTURE CONTENT. wood stove up slowly! Hi1150-1 Hampton Wood Cast Insert |... -
Page 18: Fan Operation
"high" or "Low". This will bypass the sensing device and allow full control of the fan. Switching from "Auto" to "Manual" or "High" to "Low" may be done at any time. Fan Wiring Diagram 18 | Hi1150-1 Hampton Wood Cast Insert... -
Page 19: Ash Disposal
Burning coal, cardboard, or loose paper damage to your stove including warping and can produce soot, or large flakes of char or fly ash, premature steel corrosion. Over firing will void causing smoke spillage into the room. your warranty. Hi1150-1 Hampton Wood Cast Insert |... -
Page 20: Maintenance
(3 mm / 1/8" or more) it should be removed to Ashlip reduce the risk of a chimney fire. 20 | Hi1150-1 Hampton Wood Cast Insert... -
Page 21: Door Gasket
After re-installing the door, carefully swing open and check the clearance to the Right Hand Cast Side. If tight or Wooden Door Handle rubbing, loosen the 7/16 nuts and adjust the clearance and then re-tighten. Hi1150-1 Hampton Wood Cast Insert |... -
Page 22: Latch Adjustment
5) Re-secure the latch assembly to the unit using 2 bolts. Confirm proper location of the door catch so that it closes tight, freely. Latch Assembly Latch Assembly removed from unit. Cleaning & Maintaining Your Wood Stove 22 | Hi1150-1 Hampton Wood Cast Insert... -
Page 23: Secondary Air Tube Removal/Installation
Secondary Air Tube Removal / Installation Note: unit in images may not be identical to the Hi1150-1 — they depict the process. 1. Allow the stove to burn out and cool down, until cool to touch. 5. To reinstall or replace, first slide left side of tube into hole on left side air channel. -
Page 24: Vertical Stainless Deflector Replacement
2. Loosen the two 7/16'' bolts + nuts to remove / replace vertical baffle. 3. Repeat steps to install new vertical deflector. NOTE: ENSURE BAFFLE IS PUSHED UP AS FAR AS POSSIBLE. TIGHT TO TOP OF FIREBOX. 24 | Hi1150-1 Hampton Wood Cast Insert... -
Page 25: Chimney Cleaning
Allow it to set, then tap or vibrate the screw or bolt to help loosen it before attempting to remove it. For best results, follow the instructions that are provided with the penetrating oil. Cleaning & Maintaining Your Wood Stove Hi1150-1 Hampton Wood Cast Insert |... -
Page 26: Parts List
210-111 Ashlip Metallic Black 210-115 Ashlip Timberline Brown 846-686 8 mm Soft Fibre Black Gasket Tape (8') (936-238) 173-031 Primary Air Deflector 948-467 Hinge Pin Lower 210-561 Door Assembly Metallic Black (no glass) 26 | Hi1150-1 Hampton Wood Cast Insert... -
Page 27: Cast Faceplate
* Not available as a replacement part. Brick Panels 173-960 Hi1150-1 Brick Kit Complete Fire bricks Size 8-3/8" x 4-3/8" 9" x 4-1/4" 9" x 4-1/2" 9" x 2-3/8" 3-1/2" x 4-1/2" 7-3/4" x 4-1/4" 3-1/2" x 2-1/4" Hi1150-1 Hampton Wood Cast Insert |... -
Page 28: Warranty
FPI. Alternatively, FPI may, at its own discretion, fully discharge all of its obligations under warranty by refunding the verified purchase price of the product to the original purchaser. The purchase price must be confirmed by the original Bill of Sale. 28 | Hi1150-1 Hampton Wood Cast Insert... - Page 29 God, weather-related problems from hurricanes, tornados, earthquakes, floods, lightning strikes/bolts or acts of terrorism or war, which result in a malfunction of the Appliance are not covered under the terms of this Limited Lifetime Warranty. Hi1150-1 Hampton Wood Cast Insert |...
- Page 30 Thank you for choosing a Regency Fireplace. Regency strives to be a world leader in the design, manufacture, and marketing of hearth products. To provide the best support for your product, we request that you complete a product registration form at http://www.regency-fire.com/Customer-Care/Warranty- Registration.aspx within ninety (90) days of purchase. 30 | Hi1150-1 Hampton Wood Cast Insert...
-
Page 31: Warranty Registration Card
For fireplace care and tips and answers to most common questions please visit our Customer Care section on our Web Site. Please feel free to contact your selling dealer if you have any questions about your Regency product. Hi1150-1 Hampton Wood Cast Insert |... - Page 32 32 | Hi1150-1 Hampton Wood Cast Insert...
-
Page 33: Recycling
By recycling your used appliances, you divert waste from your local landfills and help the environment. You also reduce the need for raw materials to manufacture new products. Contact your local municipality for appliance recycling services, local recycling programs, or appliance removal services to ensure your Regency appliance components, and packaging are properly recycled. Hi1150-1 Hampton Wood Cast Insert |... - Page 36 Installer: Please complete the following information Dealer Name & Address: _______________________________________ ___________________________________________________________ Installer: ___________________________________________________ Phone #: ___________________________________________________ Date Installed: _______________________________________________ Serial #: ____________________________________________________ Printed in Canada © Copyright 2024, FPI Fireplace Products International Ltd. All rights reserved.
