- Page 1 Owner's & Installation Manual www.hampton-fire.com French Manual: https://bit.ly/2OCYeIi Manuel en Français : https://bit.ly/2OCYeIi MODEL: Hi1150CSA Tested by: Installer: Please complete the details on the back cover and leave this manual with the homeowner. Homeowner: Please keep these instructions for future reference.
- Page 2 Model Hampton Hi1150CSA – 1.7g/hr / 0.088 g/MJ (output). “This manual describes the installation and operation of the Hampton Hi1150CSA wood heater. Under specific test conditions this heater has been shown to deliver heat at rates ranging from 12,800 BTU/hr to 39,100 BTU/hr. Efficiency is determined using the B415 method resulting in lower and higher heat values.
-
Page 3: Table Of Contents
Safety Maintenance Copy of the Safety Decal (Hi1150CSA) ......4 Maintenance ..............20 Creosote ............... 20 Ways to Prevent and Keep Unit Free of Creosote ..... 20 Dimensions Wood Storage ............... 20 Fan Maintenance ............20 Unit Dimensions with Standard Flue Adaptor ..... 5 Door Gasket .............. -
Page 4: Copy Of The Safety Decal (Hi1150Csa)
DO NOT REMOVE THIS LABEL / NE PAS ENLEVER CETTE ÉTIQUETTE This is a copy of the label that accompanies each CERTIFIED FOR USE IN CANADA MODEL: HI1150CSA Hi1150CSA Wood Insert. We have printed a CERTIFIED TO: CAN/ULC 628:2022 0219WN027S copy of the contents here for your review. -
Page 5: Dimensions
OFFSET FLUE ADAPTOR (172-942) STANDARD FLUE ADAPTOR (172-942) OFFSET FLUE ADAPTOR (172-946) NOTE: Before assembling your Insert, use these dimensions to ensure appropriate clearances will be met (refer to Masonry and Factory Built Fireplace Clearances section). Hi1150CSA Hampton Wood Cast Insert |... -
Page 6: Unit Dimensions With Offset Flue Adaptor
6" (152mm) Diameter 942) STANDARD FLUE ADAPTOR (172-946) OFFSET FLUE ADAPTOR (172-946) NOTE: Before assembling your Insert, use these dimensions to ensure appropriate clearances will be met (refer to Masonry and Factory Built Fireplace Clearances section). | Hi1150CSA Hampton Wood Cast Insert... -
Page 7: Installation
Your fireplace opening requires the following minimum sizes: Height: 19-5/8" (499 mm) Width: 25" (635 mm) Depth: 15" (381 mm) (w/ standard flue adaptor) 18-1/16" (459 mm) (w/ offset flue adaptor) Faceplate Dimensions: Height 27-1/4" (692 mm) Width 38-5/16" (973 mm) Hi1150CSA Hampton Wood Cast Insert |... -
Page 8: How To Determine If Alternate Floor Protection Materials Are Acceptable
DEFINITIONS Thermal Conductance: C = Btu = W (hr)(ft2 )(oF) (m2))(K) Thermal Conductivity: k = (Btu)(inch) = W = Btu (hr)(ft3)(oF) (m)(K) (hr)(ft)(oF) Thermal Resistance: R = (ft2)(hr)(oF) = (m2)(K)Btu | Hi1150CSA Hampton Wood Cast Insert... -
Page 9: Installation Into A Masonry Fireplace
A fire extinguisher should be installed in the home. The location of the fire extinguisher should 7. Do not connect the insert to a chimney be known by all family members. system servicing another appliance or an air distribution duct. Hi1150CSA Hampton Wood Cast Insert |... -
Page 10: Installing Your Insert
Before inserting the unit the adaptor should 7. Ensure that the unit is still level. hang, when level, slightly above the required 10. Re-install the door removed in step 1. height. Pull Rod Diagram 4 Flex Liner Diagram 1 10 | Hi1150CSA Hampton Wood Cast Insert... -
Page 11: Fan & Cast Faceplate Installation
Note: If screws do not lineup, loosen the 2 screws per side as shown in Diagram 2 and adjust left side and right side facia. Tighten the 2 screws per side and install the fan on the unit. Hi1150CSA Hampton Wood Cast Insert | 02/19/09 918-745b... - Page 12 Do not turn the fan ON until your insert has reached operating temperature or at least 30 minutes after starting fi re. Ashlip Diagram 6 Installer: Please record unit serial number here before installing blower. Serial No.______________________________ 12 | Hi1150CSA Hampton Wood Cast Insert 918-745b 02/19/09...
-
Page 13: Brick Installation
Firebox floor - install brick over LyTherm Sheet c) Right and left side Firebricks Fire bricks Size 4-1/4" x 7" 4-1/2" x 7" 9" x 4-1/2" 9" x 2" 3-1/2" x 4-1/2" 4-1/4" x 8" 3-1/2" x 2-1/4" Hi1150CSA Hampton Wood Cast Insert |... -
Page 14: Baffle Installation
Repeat step on other side. 3. Install the center baffle. Centre Baffle 4. Install the right and left side baffles (right side baffle shown below). Baffle Bracket 14 | Hi1150CSA Hampton Wood Cast Insert... -
Page 15: Stainless Steel Smoke Deflector Installation
Ensure deflector is seated so bolts are seated at the bottom of the slot before tightening. Smoke deflector installed with 2 bolts. Note: This is a cutaway view from the back of the unit Hi1150CSA Hampton Wood Cast Insert |... -
Page 16: Seasoned Wood
Two dry pieces banged together sound hollow; wet pieces sound solid and dull. • Dry wood weighs much less than wet wood. • Split a piece of wood. If the exposed surface feels damp, the wood is too wet to burn. 16 | Hi1150CSA Hampton Wood Cast Insert... -
Page 17: Operating Instructions
CORDWOOD ONLY. COAL, BRIQUETTES AND a cold wood insert. Always warm your ALL OTHERS LISTED ON PAGE 2 ARE NOT wood stove up slowly! APPROVED. SEASONED CORDWOOD SHOULD BE LESS THAN 20% MOISTURE CONTENT. Hi1150CSA Hampton Wood Cast Insert |... -
Page 18: Fan Operation
"high" or "Low". This will bypass the sensing device and allow full control of the fan. Switching from "Auto" to "Manual" or "High" to "Low" may be done at any time. Fan Wiring Diagram 18 | Hi1150CSA Hampton Wood Cast Insert... -
Page 19: Ash Disposal
Burning coal, cardboard, or loose paper damage to your stove including warping and can produce soot, or large flakes of char or fly ash, premature steel corrosion. Over firing will void causing smoke spillage into the room. your warranty. Hi1150CSA Hampton Wood Cast Insert |... -
Page 20: Maintenance
(3 mm / 1/8" or more) it should be removed Ashlip to reduce the risk of a chimney fire. 20 | Hi1150CSA Hampton Wood Cast Insert... -
Page 21: Door Gasket
After re-installing the door, carefully swing open and check the clearance to the Right Hand Cast Side. If tight or Wooden Door Handle rubbing, loosen the 7/16 nuts and adjust the clearance and then re-tighten. Hi1150CSA Hampton Wood Cast Insert |... -
Page 22: Latch Adjustment
5) Re-secure the latch assembly to the unit using 2 bolts. Confirm proper location of the door catch so that it closes tight, freely. Latch Assembly Latch Assembly removed from unit. Cleaning & Maintaining Your Wood Stove 22 | Hi1150CSA Hampton Wood Cast Insert... -
Page 23: Secondary Air Tube Removal/Installation
Remove. See Diagram 1. 4. Remove top left and right metal retainers, followed by the fragile three piece C-Cast Baffles, then remove the remaining 2 tubes. Diagram 1 Hi1150CSA Hampton Wood Cast Insert |... -
Page 24: Vertical Stainless Deflector Replacement
2. Loosen the two 7/16'' bolts + nuts to remove / replace vertical baffle. 3. Repeat steps to install new vertical deflector. NOTE: ENSURE BAFFLE IS PUSHED UP AS FAR AS POSSIBLE. TIGHT TO TOP OF FIREBOX. 24 | Hi1150CSA Hampton Wood Cast Insert... -
Page 25: Chimney Cleaning
Allow it to set, then tap or vibrate the screw or bolt to help loosen it before attempting to remove it. For best results, follow the instructions that are provided with the penetrating oil. Cleaning & Maintaining Your Wood Stove Hi1150CSA Hampton Wood Cast Insert |... -
Page 26: Parts List
Ashlip Metallic Black 940-356/P Glass - Replacement (Includes Glass Gasket) 210-115 Ashlip Timberline Brown 846-686 8 mm Soft Fibre Black Gasket Tape (8') (936-238) 948-467 Hinge Pin Lower 210-561 Door Assembly Metallic Black (no glass) 26 | Hi1150CSA Hampton Wood Cast Insert... -
Page 27: Cast Faceplate
* Not available as a replacement part. Brick Panels 075-960 HI1150 Brick Kit Complete Fire bricks Size 4-1/4" x 7" 4-1/2" x 7" 9" x 4-1/2" 9" x 2" 3-1/2" x 4-1/2" 4-1/4" x 8" 3-1/2" x 2-1/4" Hi1150CSA Hampton Wood Cast Insert |... -
Page 28: Warranty
FPI. Alternatively, FPI may, at its own discretion, fully discharge all of its obligations under warranty by refunding the verified purchase price of the product to the original purchaser. The purchase price must be confirmed by the original Bill of Sale. 28 | Hi1150CSA Hampton Wood Cast Insert... - Page 29 God, weather-related problems from hurricanes, tornados, earthquakes, floods, lightning strikes/bolts or acts of terrorism or war, which result in a malfunction of the Appliance are not covered under the terms of this Limited Lifetime Warranty. Hi1150CSA Hampton Wood Cast Insert |...
- Page 30 Thank you for choosing a Regency Fireplace. Regency strives to be a world leader in the design, manufacture, and marketing of hearth products. To provide the best support for your product, we request that you complete a product registration form at http://www.regency-fire.com/Customer-Care/Warranty- Registration.aspx within ninety (90) days of purchase. 30 | Hi1150CSA Hampton Wood Cast Insert...
-
Page 31: Warranty Registration Card
For fireplace care and tips and answers to most common questions please visit our Customer Care section on our Web Site. Please feel free to contact your selling dealer if you have any questions about your Regency product. Hi1150CSA Hampton Wood Cast Insert |... - Page 32 32 | Hi1150CSA Hampton Wood Cast Insert...
-
Page 33: Recycling
By recycling your used appliances, you divert waste from your local landfills and help the environment. You also reduce the need for raw materials to manufacture new products. Contact your local municipality for appliance recycling services, local recycling programs, or appliance removal services to ensure your Regency appliance components, and packaging are properly recycled. Hi1150CSA Hampton Wood Cast Insert |... - Page 36 Installer: Please complete the following information Dealer Name & Address: _______________________________________ ___________________________________________________________ Installer: ___________________________________________________ Phone #: ___________________________________________________ Date Installed: _______________________________________________ Serial #: ____________________________________________________ Printed in Canada © Copyright 2025, FPI Fireplace Products International Ltd. All rights reserved.
