HI200
Wood Cast
Insert
Owner's & Installation Manual
www.hampton-fire.com
Tested by:
Installer: Please complete the details on the back cover
and leave this manual with the homeowner.
Homeowner: Please keep these instructions for future reference.
FPI FIREPLACE PRODUCTS INTERNATIONAL LTD. 6988 Venture St., Delta, BC Canada, V4G 1H4
918-739b
10/18/11
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for HAMPTON BAY Hampton HI200
Summary of Contents for HAMPTON BAY Hampton HI200
- Page 1 Tested by: Installer: Please complete the details on the back cover and leave this manual with the homeowner. Homeowner: Please keep these instructions for future reference. FPI FIREPLACE PRODUCTS INTERNATIONAL LTD. 6988 Venture St., Delta, BC Canada, V4G 1H4 918-739b 10/18/11...
- Page 2 Thank-you for purchasing a HAMPTON FIREPLACE PRODUCT. The pride of workmanship that goes into each of our products will give you years of trouble-free enjoy- ment. Should you have any questions about your product that are not covered in this manual, please contact the HAMPTON DEALER in your area.
-
Page 3: Table Of Contents
TABLE OF CONTENTS SAFETY LABEL MAINTENANCE Door Gasket ..............17 Copy of Safety Label .............4 Glass Cleaning ............17 Door Removal..............17 DIMENSIONS Glass Replacement .............17 Handle Replacement ...........18 Unit Dimensions ............5 Latch Adjustment ............18 Standard Flue Adaptor...........5 Annual Maintenance ............20 PARTS LIST INSTALLATION Main Assembly ............21 Before Installing Your Insert...........7... -
Page 4: Safety Label
SAFETY LABEL This is a copy of the label that accompanies each HI200 Wood Insert. We have printed a copy of the contents here for your review. Serial (Duplicate NOTE: Hampton units are constantly being improved. Check the label on the unit and if there is a difference, the label on the unit is the correct one. -
Page 5: Dimensions
DIMENSIONS UNIT DIMENSIONS WITH STANDARD FLUE ADAPTOR 25” 21-1/4” 2-7/8” 39-13/16” 38-5/16” 6" (152mm) Diameter 24” STANDARD FLUE ADAPTOR (171-932) Door Width NOTE: Before assembling your Insert, use these dimensions to en- sure appropriate clearances will be met (refer to Masonry and Factory Built Fireplace Clearances section). -
Page 6: Offset Flue Adaptor
DIMENSIONS UNIT DIMENSIONS WITH OFFSET FLUE ADAPTOR 25” 21-1/4” 39-13/16” 2-7/8” 38-5/16” 6" (152mm) Diameter OFFSET FLUE ADAPTOR (171-936) NOTE: Before assembling your Insert, use these dimensions to en- sure appropriate clearances will be met (refer to Masonry and Factory Built Fireplace Clearances section). -
Page 7: Installation
INSTALLATION CHIMNEY 6) Alteration of the fireplace in any manner is Hampton Inserts are constructed with the high- est quality materials and assembled under strict not permitted with the following exceptions; SPECIFICATIONS quality control procedures that ensure years of trouble free and reliable performance. a. -
Page 8: Masonry And Factory Built Fireplace Clearances
INSTALLATION MASONRY AND FACTORY BUILT FIREPLACE CLEARANCES The minimum required clearances to combustible materials when installed into a masonry or factory built fireplace are listed below. Adjacent Mantle** Side Minimum Minimum Minimum Side Wall (to Top) Facing Facing Hearth Hearth Hearth Side (to Side) (to Top) -
Page 9: Installing Your Insert
INSTALLATION INSTALLING YOUR INSERT STOP! PLEASE READ CAREFULLY. 3) Lift the unit up onto the Hearth and slide into the fireplace opening. Be sure to leave the unit out at least 3 to 4 inches in order to make the necessary flue connections and to install the fan and faceplate. CAST COMPONENTS ARE VERY FRAGILE. - Page 10 INSTALLATION 6) Install the unit by first setting the rear of the unit into the fireplace. See 10) Ensure that the unit is still level. diagram 3. Ensure that the unit is centered in the existing fireplace and lined up with the flue adaptor. 11) To complete the installation and to ensure a secure fit and connec- tion of the flue adaptor to the insert, it is essential that the two bolts, flat washers and lock washers (supplied with packaged manual) be...
-
Page 11: Installation Into Afactory Built Fireplace
INSTALLATION INSTALLATION INTO A 4) If the floor of your fireplace is below the In Canada this fireplace insert must be level of the fireplace opening, adjust the MASONRY FIREPLACE installed with a continuous chimney liner insert's levelling bolts to accommodate the of 5.5"... -
Page 12: Fan & Cast Faceplate Installation
HI200 INSTALLATION FAN & CAST FACEPLATE INSTALLATION FAN & CAST FACEPLATE INSTALLATION Stop! Read Carefully. Enamel & Cast components are very fragile. Use extreme care when handling. Note: The liner and fl ue adaptor should be installed prior to 2) Slide the unit into position leaving partially out to allow for installation reading these instructions. - Page 13 HI200 INSTALLATION 7) Install door and close with caution - adjustments may be 6) Place ashlip over fan by fi tting it onto the fl ange on the fi rebox. necessary. See Diagram 5 and 6. Diagram 7 8) Surround adjustments can be made up or down, loosen 4 bolts shown on face of unit (Diagram 7) and adjust.
-
Page 14: Brick Flue Baffle & Secondary Air Tube Installation
INSTALLATION FIREBRICK ASSEMBLY DRAFT CONTROL Firebrick is included to extend the life of your Before establishing your first fire, it is important insert and radiate heat more evenly. Check to that you fully understand the operation of draft see that all firebricks are in their correct posi- control. -
Page 15: First Fire
OPERATING INSTRUCTIONS INSTALLATION FIRST FIRE FAN OPERATION 10) For those units installed at higher elevations or into sub-standard masonry fireplaces, drafting problems may occur. Consult an When your installation is completed and in- The fan is to be operated only with the draft experienced dealer or mason on methods spected, you are ready for your first fire. -
Page 16: Operating Instructions
OPERATING INSTRUCTIONS CREOSOTE ASH DISPOSAL 8) Do not permit creosote or soot buildup in the chimney system. Check and clean chimney When wood is burned slowly, it produces tar and at regular intervals. During constant use, ashes should be removed other organic vapors, which form creosote when every few days. -
Page 17: Maintenance
MAINTENANCE DOOR GASKET GLASS REPLACEMENT If the door gasket requires replacement, 7/8" diameter material must be used. A proper high temperature gasket adhesive is required. A gasket 1) Remove door from unit. repair kit, Part # 846-570 is available from your local Hampton dealer. 2) To replace the glass remove the 4 screws highlighted in the diagram below. -
Page 18: Handle Replacement
MAINTENANCE HANDLE LATCH ADJUSTMENT REPLACEMENT The door latch may require adjustment as the door gasket material com- presses over time. Removal of spacers will allow the latch to be moved 1) Remove handle by undoing the hex head bolt using a 7/16" socket closer to the door frame, causing a tighter seal. - Page 19 MAINTENANCE LATCH ADJUSTMENT The door latch or door alignment may require adjustment as the door gasket material compresses after a few fires. Removal of spacers will allow the latch to be moved closer to the door frame, causing a tighter seal and the ability to raise or lower the latch assembly. 1) Raise or lower the latch by undoing the inner 2 bolts.
-
Page 20: Annual Maintenance
MAINTENANCE Annual Maintenance Completely clean out entire unit Annually Inspect air tubes, baffles and bricks Replace any damaged parts. Adjust door catch / latch If unable to obtain a tight seal on the door - replace door gasket seal. Readjust latch after new gasket installed. Inspect condition and seal of: Glass Gasket Door Gasket... -
Page 21: Parts List
PARTS LIST MAIN ASSEMBLY Part # Description 948-163 Cane Bolt Latch 940-356/P Glass - Replacement 948-467 Hinge Pin Lower 936-238 Adhesive Tape Gasket 210-554 Glass Retainer Clips / Screws (set of 4) Screws - 10-24 x 3/8" 210-550 Door Handle Assembly 10) 210-561 Door Assembly Metallic Black (no glass) 210-565... -
Page 22: Cast Faceplate
PARTS LIST CAST FACEPLATE Part # Description 210-921 Metallic Black Faceplate 210-925 Timberline Brown Faceplate Top Surround Left Side Surround Right Side Faceplate * Not available as a replacement part. FIREBRICK Part # Description 170-960 Complete Brick Set 70) * Brick Regular Full Size: 1-1/4"... -
Page 23: Warranty
At no time will FPI be liable for any consequential damages which exceed the purchase price of the unit. FPI has no obligation to enhance or modify any unit once manufactured. ie. as products evolve, fi eld modifi cations or upgrades will not be performed. - Page 24 Installer: Please complete the following information Dealer Name & Address: ______________________________________________ ___________________________________________________________________ Installer: ___________________________________________________________ Phone #: ___________________________________________________________ Date Installed: ______________________________________________________ Serial No.: __________________________________________________________ © Copyright 2011, FPI Fireplace Products International Ltd. All rights reserved. Printed in Canada...
