Summary of Contents for Bodyworx JX324
-
Page 2: Table Of Contents
INDEX 1. OVERVIEW DRAWING................2 2. IMPORTANT SAFETY INSTRUCTIONS ..........3 3. GROUNDING INSTRUCTIONS ..............4 4. PRE-ASSEMBLY CHECK LIST ..............6 5. ASSEMBLY STEPS ..................7 6. CAUTION ....................9 7. MAINTENANCE ..................9 8. COMPUTER OPERATION INSTRUCTIONS ............. -
Page 3: Overview Drawing
1. OVERVIEW DRAWING Computer Console Safety Key / Clip Grip Pulse Sensor On-off Switch Frame Circuit Breaker Rear End Cape... -
Page 4: Important Safety Instructions
2. IMPORTANT SAFETY INSTRUCTIONS When using this product, basic precautions should always be followed, including the following: Please read the instruction carefully before starting to use this product. Danger – To reduce the risk of electric shock： Always unplug this product from the electrical outlet immediately after using and before cleaning. -
Page 5: Grounding Instructions
3. GROUNDING INSTRUCTIONS The products must be grounded first. If malfunction or breakdown occurs, grounding will provide a path of least resistance for electric current to reduce the risk of electric shock. The product is equipped with a cord having an equipment-grounding conductor and a grounding plug. -
Page 6: Pre-Assembly Check List
4. PRE-ASSEMBLY CHECK LIST ITEM Description Computer Console Frame Upright (L) Upright (R) - Page 7 ITEM Description Allen Bolt M8xP1.25x15 Washer ø8x16x1.5t Allen Bolt M8xP1.25x40(nylok) Allen Wrench 5mm Allen Wrench 6mm(80mmx80mm) SLILCON Bottle Safety Key/Clip...
-
Page 8: Assembly Steps
5. ASSEMBLY STEPS Two persons are required to finish the assembly steps. (Caution!! Please follow exactly the assembly steps below to avoid injury. ) 1. After pull out Control Wire with Guide Thread in right Upright (D), cap it into the wire clip and fix it inside hole of right Upright. -
Page 9: Caution
6. CAUTION: CAUTION： Note: The Cylinder is made of high pressure, so it must be extra careful not to impact with other objective to avoid deformation. Note: When the cylinder is hit, possibly will cause the damage and make the usage not smooth. -
Page 10: Maintenance
7. MAINTENANCE When running belt is off the center, stop the treadmill immediately, use Allen Wrench to adjust the hex head screw. For example, the running belt is offset to the left it should adjust 1/4 circle clockwise; if the running belt is offset to the right, adjust 1/4 circle counterclockwise. -
Page 11: Computer Operation Instructions
COMPUTER OPERATION INSTRUCTION General Operation： 1. Turn on the treadmill. 2. Put the safely key in the recess of the console. The beeper will sound and all windows will display values, the initial values are 0, and not blinking, this present treadmill is under START/READY position, under this situation, user can hold the grip pulse sensor to detect heart rate value directly. - Page 12 3. Press to start treadmill, the treadmill will start with a speed of 1.0km/hr, at this time press 、 、 、 、 to increase/ decrease speed( also can press fast speed buttons to instantly choose the speed you need), press once to pause your workout( press one time, all values stop to change, treadmill pause 4 minutes and back to START/ READY condition, after...
- Page 13 、 At this time you can press to choose LEVEL, after finished, press then the treadmill will begin to operate, or press to enter into PROGRAM time setting. 、 After into the time setting, you can press to set up time, after finished, press directly to operate, or press back to PROGRAM option again.
- Page 14 III. Body fat mode: 1. Under START/READY condition, press , you can see the Body Fat LED light is blinking, present you are in to Body Fat function. When you choose this function, program will require you enter following values. Age ：...
