6.16. Replacing parts - General information

The replacement of the fuses and the light bulbs
can be carried out by the owner according to the
indications provided below.
Battery recharge fuse - Replacement
(§1.13.1.)
Fuses - Replacement (§1.13.1.)
Low beam bulb - Replacement
(§1.13.2.)
High beam bulb - Replacement
(§1.13.3.)
Turn indicator bulb - Replacement (§1.13.4.)
6
License plate light bulb - Replacement (§1.13.5.)
MAINTENANCE
6.16.1.

Replacing the fuses

The recharge fuse is located under the driver's
saddle, in the position shown in the figure.
- 158 -
6
Spare fuse
(40A)
Recharge fuse
(40A)
