S482 Barbecue
Assembly Manual
85-3024-4 (G43215) Propane
85-3025-2 (G43216) Natural Gas
1 YeAr liMited WArrAntY
reAd And sAve MAnuAl for future reference.
if pre-assembled, leave this manual with unit for
consumer's future reference.
for product inquiries, parts, warranty and
troubleshooting support, please call 1-877-707-5463.
Manual Revision #: 01112010 PD

Advertisement

loading
Need help?

Need help?

Do you have a question about the S482 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Master Chef S482

Summary of Contents for Master Chef S482

  • Page 1 S482 Barbecue Assembly Manual 85-3024-4 (G43215) Propane 85-3025-2 (G43216) Natural Gas 1 YeAr liMited WArrAntY reAd And sAve MAnuAl for future reference. if pre-assembled, leave this manual with unit for consumer’s future reference. for product inquiries, parts, warranty and troubleshooting support, please call 1-877-707-5463.

  • Page 2: Hardware Pack

    HARDWARE PACK tools needed for AsseMBlY KeY # descriPtion PArt nuMBer QuAntitY 1/4”-20UNCX13mm screw 20120-13013-036 • #2 Phillips screwdriver (long and short) 1/4”-20UNCX38mm screw 20120-13038-036 1/4”-20UNC nut 31220-13000-036 • ¼” Slotted screwdriver (long and short) #8X3/8” self tapping screw 24200-42008-136 •...
  • Page 3 PARts List (PRoPANE) foR 85-3024-4 (G43215) EXPLoDED DiAGRAM (PRoPANE) foR 85-3024-4 (G43215) KeY # QuAntitY descriPtion PArt no. Top lid assembly G432-B000-01 Thermometer and bezel G432-R200-01 Logo Plate G451-0001-01 Lid handle brackets G432-0030-01 Top lid handle G432-0029-01 Lid bumpers- back G303-0038-01 Lid bumbers-Front G430-00B8-01...
  • Page 4 PARts List (NAtuRAL GAs) foR 85-3025-2 (G43216) EXPLoDED DiAGRAM (NAtuRAL GAs) foR 85-3025-2 (G43216) KeY # QuAntitY descriPtion PArt no. Top lid assembly G432-B000-01 Thermometer and bezel G432-R200-01 Logo Plate G451-0001-01 Lid handle brackets G432-0030-01 Top lid handle G432-0029-01 Lid bumpers- back G303-0038-01 Lid bumbers-Front G430-00B8-01...

  • Page 5: Assembly Instructions

    AssEMBLY iNstRuCtioNs AssEMBLY iNstRuCtioNs ProPAne Model onlY Assemble the front panel (DD) to the left and right cart side panels (DB, DA), as shown. Ensure that the slots on the tank exclusion (DJ) Note: You will need two people for this step. align with the slots on the front panel (DD).
  • Page 6 AssEMBLY iNstRuCtioNs AssEMBLY iNstRuCtioNs riGHt side sHelf AsseMBlY Note: tWo PEoPLE required for this step. Ensure that the regulator hose (CC) (Propane a. Insert the right side shelf assembly hooks (EA models only) is hanging outside of cart. & EB) into the support brackets located on the right side of the burner box assembly (B).
  • Page 7 AssEMBLY iNstRuCtioNs AssEMBLY iNstRuCtioNs left side sHelf AsseMBlY Place the flame tamers (BE) into the burner box. a. Insert the left side shelf assembly hooks (EC and ED) into the support brackets located on the left side of the burner box assembly (BA). b.
  • Page 8 AssEMBLY iNstRuCtioNs AssEMBLY iNstRuCtioNs ProPAne Model sHoWn To assemble the warming rack (BG), insert the stationary wire into the holes on the sides of the lid. Insert warming rack pivot legs into the AttENtioN: LP Cylinder is sold separately. holes on the inside of the burner box assembly, Stationary Wire use only LP tanks that are equipped with an as shown.
  • Page 9 AssEMBLY iNstRuCtioNs Electronic ignition battery not included. Unscrew the electronic ignition button (CF2) and insert one AA battery into the electronic ignition battery compartment (CF1), with the positive end facing outward.
