S550 Barbecue
Assembly Manual
199-4758-2 (G55101) Propane
199-4759-0 (G55102) Natural Gas
1 YEAR LIMITED WARRANTY
READ AND SAVE MANUAL FOR FUTURE REFERENCE.
If pre-assembled, leave this manual with unit for
consumer's future reference.
For product inquiries, parts, warranty and
troubleshooting support, please call 1-877-707-5463.
Manual Revision #: 26122012 PD
ANS Z21.58b-2012-CSA 1.6b-2012
ANS Z21.58b-2012-CSA 1.6b-2012
ANS Z21.58b-2012-CSA 1.6b-2012
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for Master Chef S550
Summary of Contents for Master Chef S550
- Page 1 S550 Barbecue Assembly Manual 199-4758-2 (G55101) Propane 199-4759-0 (G55102) Natural Gas 1 YEAR LIMITED WARRANTY READ AND SAVE MANUAL FOR FUTURE REFERENCE. If pre-assembled, leave this manual with unit for consumer’s future reference. For product inquiries, parts, warranty and troubleshooting support, please call 1-877-707-5463.
- Page 2 H E A V Y A R T I C L E N E E D S 2 T O L I F T THIS MANUAL MUST REMAIN WITH THE PRODUCT AT ALL TIMES To ORDER non-warranty replacement parts or accessories, or to register your warranty, please visit us on the web at www.masterchefbbqs.com CAUTION...
-
Page 3: Tools Needed For Assembly
HARDWARE PACK TOOLS NEEDED FOR ASSEMBLY KEY # DESCRIPTION PART NUMBER QUANTITY 1/4” 13mm Screw 20120-13013-036 • #2 Phillips screwdriver (long and short) 1/4”-20UNC Nut 31220-13000-036 #8X3/8” Self Tapping Screw 24200-42008-136 • ¼” Slotted screwdriver (long and short) φ7 Fiber Washer G431-0018-9000 •... - Page 4 PARTS LIST PROPANE FOR 199 4758 2 G55101 KEY # QUANTITY DESCRIPTION PART NO. Top lid assembly G551-0100-01 Thermometer and bezel G432-000K-01 Lid handle brackets G352-0015-01 Top lid handle G551-0001-01 Lid bumpers-back G303-0038-01 Lid bumpers-front G430-00B8-01 Screws for lid G430-0024-02 Burner box assembly G551-0300-01 Burner...
- Page 5 EXPLODED DIAGRAM PROPANE FOR 199 4758 2 G55101 SAFETY ASSEMBLY AND CARE MANUAL MANUAL HARDWARE PACK...
- Page 6 PARTS LIST NATURAL GAS FOR 199 4759 0 G55102 KEY # QUANTITY DESCRIPTION PART NO. Top lid assembly G551-0100-01 Thermometer and bezel G432-000K-01 Lid handle brackets G352-0015-01 Top lid handle G551-0001-01 Lid bumpers-back G303-0038-01 Lid bumpers-front G430-00B8-01 Screws for lid G430-0024-02 Burner box assembly G551-0300-01...
- Page 7 EXPLODED DIAGRAM NATURAL GAS FOR 199 4759 0 G55102 SAFETY ASSEMBLY AND CARE MANUAL MANUAL HARDWARE PACK...
-
Page 8: Assembly Instructions
ASSEMBLY INSTRUCTIONS Assemble the Upper Front Panel (DD) and Lower Front Panel (DE) to the the left and right cart side panels (DB and DA) as shown. YOU WILL NEED: Assemble the two back braces (DC) to the left and right cart side panels (DB and DA) as shown. YOU WILL NEED: Back View... - Page 9 ASSEMBLY INSTRUCTIONS Note: Turn Cart assembly upside down. a. Place wheel (DG) and wheel spacer (#5) onto the wheel axle (DH). “Cone” side of wheel should be against cart side panel. Figure B b. Insert wheel axle assembly (DH) through wheel axle hole in the front and rear of the left cart side panel (DB), as shown.
- Page 10 ASSEMBLY INSTRUCTIONS PROPANE MODEL ONLY. Assemble the gas tank support (DK) to left cart side panel (DB). Back View Close up Note: TWO PEOPLE required for this step. Ensure that the regulator hose (CC) (Propane models only) is hanging outside of cart. a.
- Page 11 ASSEMBLY INSTRUCTIONS RIGHT SIDE SHELF ASSEMBLY a. Insert the right side shelf assembly (EA and EB) into the support brackets located on the right side of the burner box assembly (BA). Front, right side view b. A x the right side shelf table (EA) to the burner box assembly (BA) as shown in gure B and C.
- Page 12 ASSEMBLY INSTRUCTIONS LEFT SIDE SHELF ASSEMBLY a. Insert the left side shelf assembly (EC and ED) into the support brackets located on the right side of the burner box assembly (BA). Front, left side view b. A x the left side shelf table (EC) to the burner box assembly (BA) as shown in gure B and C.
- Page 13 ASSEMBLY INSTRUCTIONS a. Assemble the control knob bezel (#9) to the left side shelf fascia (ED) and the side burner valve (CD) as shown in gures A and B. YOU WILL NEED: Left side view Front view b. Position the Side Burner (EF) through the opening in the Left Side Burner Drip Pan (EE).
- Page 14 ASSEMBLY INSTRUCTIONS d. Assemble the side burner (EF) to the side burner drip pan (EE) as shown in gure E. YOU WILL NEED: View, under left side shelf e. Use the side burner Venturi clip (#12) to connect the side burner (EF) to the side burner valve (CD) as shown in gure F.
- Page 15 ASSEMBLY INSTRUCTIONS a. Position the side burner cooking grate (EH) onto the side burner drip pan (EE). b. Assemble the side burner control knob (#8) to the side burner valve (CD). YOU WILL NEED: Place the ame tamer (BE) into the burner box assembly (BA).
- Page 16 ASSEMBLY INSTRUCTIONS Place the cooking grates (BF) into the burner box assembly (BA). To assemble the warming rack (BG), insert the stationary wire into the holes on the sides of the lid. Insert warming rack pivot legs into the holes on the inside of the burner box assembly, as Stationary Wire shown.
- Page 17 For your safety, do not attempt to light this BBQ until you have reviewed pages 4-8 of the Master Chef® Safety & Care Manual. All safety and leak tests must be performed by the end user, prior to lighting this BBQ.
- Page 18 ASSEMBLY INSTRUCTIONS NATURAL GAS MODELS ONLY Attach the natural gas hose (CE) to the side burner valve (CD) as shown. ATTENTION In order to complete installation of your natural gas BBQ a 1/2” or 3/8” adapter may be required to connect your BBQ’s natural gas hose to your home gas supply.
- Page 19 Visit www.masterchefbbqs.com Visit www.masterchefbbqs.com to complete product registration Master Chef® Customer Service 1-877-707-5463 Trileaf Distributions Trifeuil Toronto, Ontario M4S2B8...
