Product Registration Number - SCAN 4-2 Instructions For Use Manual

Unpacking
To protect your stove, we recommend not removing the plastic pack-
aging from the stove until you have completed the assembly.
Service package
The service package contains the following:
• Fitting for flue collar
• Seal for flue collar
• Safety fitting
• Plastic plugs for transport safety hole at the bottom of the
stove
• Various tools
• Glove
• Fire starters for first lighting
• Springs for side panels (Scan Basic 4-2 K)
Load bearing underlay
All of the products in our portfolio are classified as light-duty firepla-
ces; in most cases, there is no need to reinforce the floor, so that
you can typically use the normal floor.
However, you should make sure that the load bearing underlay can
bear the weight of the wood-burning stove and possibly of the steel
chimney, as needed.
Floor plate
If you are setting up the stove on a flammable floor, observe national
and local regulations on the size of the non-flammable underlay that
covers the floor around the stove.
The idea behind the floor plate is that it protects the floor and flam-
mable material against sparks.
As a general rule, the floor plate should cover the floor 300 mm in
front of and 150 mm to the side of the wood-burning stove door. The
floor plate can be made of steel or glass, and the stove can be set
up on brick, natural stone or similar materials.
This Scan wood-burning stove has an integrated floor plate, and
can thus be set up on any flammable material without a protective
underlay.
Adjusting screw
Your Scan wood-burning stove has two adjusting screws at the base
which you can use to level the stove.
Type plate
All Scan wood-burning stoves are fitted with a type plate, that
specifies the approval standards and the distance to flammable
materials.

Product registration number

Open the wood-burning stove door; you can then read, and make a
note of, the product registration number (see front).
Product registration number
A S S E M B LY
Accessories
The follwing accessories are avaialable for the Scan Basic 4-2 K
model:
• Soapstone side panels
• Soapstone baking tray
The follwing accessories are avaialable for the Scan Basic 4-2 &
4-2 K models:
• Soapstone cover plate top outlet
• Soapstone cover plate rear outlet
Side panels
Fitting the side panels for the Scan Basic 4-2 K, see below.
Setting up the stove for using a rear out-
let
Flue collar connection piece rear outlet
1. Use the tools provided to
remove the cover plate at the
rear of the wood stove.
3
2. Use pliers to cut off the
anchoring points on the inter-
nal plate.
