Code Types by Serial Command
Command Title cmds
Narrow Margins/Sym-
Ko
bology ID
Background Color Kx
Code 39 Kp
Codabar Kq
Interleaved 2 of 5 Kr
UPC/EAN Ks
PDF417 K[
Code 128 Kt
UCC/EAN-128
Kt
(subset of Code 128)
Code 93 K!
AIAG KZ
Code Type Status
KW?
Request
MS-820 Industrial Bar Code Scanner User's Manual
Format
<Konarrow margins status,symbology identifier>
<Kxbackground color>
<Kpstatus,check digit status,check digit output status,large
intercharacter gap,fixed code length status,fixed code length>
<Kqstatus,start & stop match status,start & stop output sta-
tus,large intercharacter gap,fixed code length status,fixed code
length,check digit type,check digit output>
<Krstatus,check digit,check digit output,length 1,length 2>
<KsUPCstatus,EAN status,supplementals status,separator sta-
tus,separator character>
<K[status,[usused],fixed code length status,fixed code length>
<Ktstatus,fixed length status,fixed code length>
<Kt,,,UCC/EAN-128 status,output format,application record
separator status,application record separator character,appli-
cation record brackets,application record padding
<K!status,fixed code length status,fixed code length>
<KZAIAG status, ID1, status1, ID2, status2, ID3, status3, ID4,
status4, *ID5a,ID5b,ID5c, status5, ID6, status6, ID7, status7, ID8,
status8, ID9, status9, ID9, status10, ID11, status11, ID12,
status12>
<KW?>
