Chapter 1 Quick Start
Step 6 — Connect with Auto Connect
After clicking the Start button in the Connecting to... dialog, allow time for the auto
connect routine to test all of the combinations. You will see a blue progress bar fill
across the Connecting to... dialog.
When connected, the CONNECTED message will appear in a green box in the status
bar on the bottom right of the dialog.
Tip: If you do not see either the CONNECTED or DISCONNECTED message at the bot-
tom of your dialog, try expanding the ESP window horizontally.
Tip: If connection fails, enable a different Com port and try again.
1-7
MS-820 Industrial Bar Code Scanner User's Manual
