Master Label Database
Enter Master Label Data
Definition: Allows you to enter master label data for a specific master label index
number (1 to 10), provided the index number is not larger than the
number of labels enabled by the Master Label Database Size (see
page 7-11). For example, if Master Label Database Size is set to 2,
you will not be able to enter data for labels 3 through 10.
ESP: 1. Open the
menu.
2. Set the number of
master labels you want
to create in
Size.
3. Double-click
label number you want
to setup and copy or
type in your data.
4. With your cursor in the
label row you have
just edited, right-click
and choose
Send Save.
Serial Cmd: <Mmaster label number,master label
Default: 1, blank
Options: 1 to 10, data (any combination of ASCII text up to the maximum indicated
in "Maximum Characters for Master Label Database" on page
For example, to enter data for master label 9, after making certain that
master label database size is enabled for 9 or more labels (see
Label Database Size" on page
Caution: Since the total number of characters available for the master label database
is 2045, changes to the Master Label Database Size will re-allocate the number of
characters available for each master label and could cause existing master labels to
be deleted (except master label #1 unless it also exceeds the size limitation).
The table below specifies the maximum number of characters available to each label
according to the number of master labels defined, from 1 through 10. See
Label Database Size" on page 7-11.
7-12
MS-820 Industrial Bar Code Scanner User's Manual
Utilities
Database
on each
Send or
data>
7-11), send <M9,data>.
7-13).
"Master
"Master
