6-2. VIDEO OUTPUTS (continued)
• COMPOSITE VIDEO
Connector:
Standard:
Level:
Impedance:
• SDI (available on the DSV1600 only)
Connector:
Signal:
Impedance:

6-3. GENLOCK

Connectors:
Input signal type:
Impedance:
Output:

6-4. REMOTE PORT

Connector:
Level:
Data Rate:

6-5. ENVIRONMENTAL

Power Supply:
Storage Temperature:
Operating temperature:
Hygrometry:
Dimensions:
Weight:
BNC female.
PAL : 15.625 kHz / 50 Hz - 625 lines.
NTSC : 15.734 kHz / 60 Hz - 525 lines - 7.5 IRE.
NTSC J : 15.734 kHz / 60 Hz - 525 lines - 0 IRE.
1 Vp/p (0.7 V Luma + 0.3 V Sync.).
75 Ohm.
BNC female.
270 Mbps serial digital output according to SMPTE 259M.
75 Ohm.
2 BNC female.
Black Burst PAL or NTSC.
75 Ohm or Hi-Z.
Passive loop-through.
DB9 female.
RS-232.
9600 bauds, 8 bits data, 1 bit stop, no parity bit, no flow control.
DSV1600 : 100VAC-250VAC ; 50-60Hz ; I = 0.5A Max.
SSV1600 : External adapter (CE / UL / CSA / IEC950 approved)
Input (AC): 100-240 VAC, 1 A, 50-60 Hz.
Output (DC): 5 V, 4A, 20 W max.
- 25 °C to + 85 °C (- 13 °F to + 185 °F)
0 °C to + 50 °C (32 °F to 122 °F)
10% to 80% (without condensation)
Compatible with the 19" standard, height = 1 unit.
DSV1600: W 482 mm (19") x D 265 mm (10.4") x H 44 mm (1.74").
SSV1600: W 221 mm (8.7") x D 265 mm (10.4") x H 43 mm (1.69").
DSV1600: 3 kg (6.6 Lbs).
SSV1600: 1.2 kg (2.64 Lbs)
