SCAN 1600 / DIGI SCAN 1600
3-5. FUNCTIONS DESCRIPTION (continued)
3 [IMAGE] + ENTER.
3-1 [Flicker filter] + ENTER.
Select one of the 8 levels of the anti-flicker with
3-2 [Black Level] + ENTER. (Available for analog input source only).
Adjust the Black level with
3-3 [RGB Levels] + ENTER. (Available for analog input source only).
Select an item with
• [Red] : Adjust the level of the Red with
• [Green] : Adjust the level of the Green with
• [Blue] : Adjust the level of the Blue with
3-4 [H. smooth] + ENTER. (Available for the analog input source only).
Select an item with
• [ON] : Active the horizontal filter.
• [OFF] : Inactive the horizontal filter.
3-5 [Position status] + ENTER.
Displays the image position status.
3-6 [Under/over] + ENTER.
Select an item with
• [underscan] : The output image is full screen.
• [overscan] : The output is 10% bigger than in underscan mode.
3-7 [Zoom status] + ENTER.
Displays the image zoom status.
3-8 [Preset] + ENTER.
This function allows to set all the image parameters (flicker filter, Black level, RGB level, under/overscan,
position & size) to the factory settings.
FUNCTION
3-1 Flicker Filter
3-2 Black level.
3-3 RGB levels.
4 [CONTROL] + ENTER.
4-1 [Panel locking] + ENTER.
This function allows to lock the front panel buttons. Select an item with
• [lock] : allows to lock the front panel push button.
• [unlock] : doesn't lock the front panel button.
NOTE: To unlock push simultaneously on ENTER and EXIT.
4-2 [Version] + ENTER.
Status of the internal firmware.
4-3 [Erase memories] + ENTER.
This function allows to erase all the image settings memorized.
4-4 [Default value] + ENTER.
This function allows to clear the following adjustments and set them to the factory value:
FUNCTION
1-2 Input type
1-3 SOG input
1-4 H sync load
1-5 Genlock load
1-6 Genlock H Ph
1-7 Genlock Sc. Ph.
+ ENTER.
+ ENTER.
+ ENTER.
+ ENTER.
+ ENTER.
POSITION
level 1.
0
0
POSITION
analog
no.
Hi-Z.
Hi-Z.
0
0
Chapter 3 : FRONT PANEL DISPLAY MENU DESCRIPTION (continued)
and validate with ENTER.
+ ENTER.
+ ENTER.
FUNCTION
3-4 H smooth
3-6 under/over
Position & size
FUNCTION
2-2 Output standard
2-3 Output rate
2-4 RGB/YUV out
2-5 test pattern
4-1 panel locking
POSITION
off.
underscan.
0
+ ENTER.
POSITION
NTSC
internal.
YUV
no.
unlock.
