Chapter 3 : FRONT PANEL DISPLAY MENU DESCRIPTION

3-1. INTRODUCTION

The front panel display menu presents 2 modes: the STATUS MODE and the CONTROL MODE.
• The STATUS MODE indicates the input and output status of the device.
• The CONTROL MODE allows selecting and adjusting the parameters of the device.

3-2. CONTROL BUTTONS

The front panel display is controlled by 2 buttons and 1 knob:
knob:
ENTER button:
EXIT / MENU button:

3-3. STATUS MODE

When switching ON, the front panel display shows the product's name and firmware versions as follows:
DEVICE MODEL
DEVICE VERSION
INPUT FORMAT
HORIZONTAL FREQUENCY (in kHz) / VERTICAL FREQUENCY (in Hz).
OUTPUT STANDARD.
OUTPUT RATE TYPE / OUTPUT FREQUENCY
PAGE 14
• In the CONTROL MODE, turn this knob to scroll thru the different menus.
• From the STATUS MODE, press this button to enter in the CONTROL MODE.
• From the CONTROL MODE, press this button to confirm a selected item.
• From the STATUS MODE, press this button to enter in the CONTROL MODE.
• From the CONTROL MODE, press this button to:
- return to the previous menu without safeguarding the selection.
- return to the STATUS MODE (press several times).
DSV1600
Version _._
Input :
H = 37.9K
Output :
Internal
SVGA
V= 60 Hz
NTSC
59.94
SCAN 1600 / DIGI SCAN 1600
DEVICE STATUS
INPUT STATUS
OUTPUT STATUS
