5.3.3 MATCHING STRING & LOCATION
By default, no matching string is specified, and therefore, it is disabled. Enable this
feature by specifying a matching string; up to four characters are allowed.
When the Matching String Location is zero, the scanner will only check for the
existence of the matching string in the barcode data.
Specify a value to indicate where the matching string starts in the barcode data.
1) Read the barcode to specify a matching string.
2) Read the "Hexadecimal
3) Read the "Validate" barcode to complete this setting.
4) Read the barcode to specify the location of the matching string.
5) Read the "Decimal
6) Read the "Validate" barcode on the same page to complete this setting.
166
User Guide
Value" barcode on page 194 for the desired character string.
Value" barcode on page 193 for the desired location.
Matching String...
Location of Matching
String...
End Programming Format
